Page 1: Service Manual
Domestic Air Conditioner SERVICE MANUAL Model HW-05LN03 Feature Anti-mold filter Mechanical control Easy clean filters Slide chassis 4-way airflow direction 2 cool settings, 2 fan settings Serial Number: Version:00.00 Edition: 2007-7-5... -
Page 2: Table Of Contents
Haier air conditioner Edition: 10070705 Content Product Code Illumination And Series introduction ---------------------------- 2 Specifications -------------------------------------------------------------------------------- 3 Safety and Precaution ----------------------------------------------------------------------4 4 Warning and Cautions ----------------------------------------------------------------------5 5 Net Dimention ---------------------------------------------------------------------------------6 6 Installation and Accessory Parts -------------------------------------------------------7 7 Parts and Functions... -
Page 3: Product Code Illumination And Series Introduction
1. Product Code Illumination and Series introduction 1). Model code rule description Model identification: H W - A: Abbreviation of Haier B: Abbreviation of Window C: Nominal cooling capacity (BTU/h) with the first two numbers based on one thousand unit. D: Function code... -
Page 4: Specifications
Haier air conditioner Edition: 10070705 2. Specification Item Unit HW-05LN03 Cooling capacity BTU/h 5000 Heating capacity BTU/h Power supply 1, 220, 50 Power input Cooling Running current BTU/(hW) 2.82 Power input Heating Running current BTU/(hW) Indoor side dB(A) 56/55 Sound Level... -
Page 5: Safety And Precaution
Haier air conditioner Edition: 10070705 3. Safety and Precaution... -
Page 6: Warning And Cautions
Haier air conditioner Edition: 10070705 4. Warning and Cautions... -
Page 7: Net Dimention
Haier air conditioner Edition: 10070705 5. Net Dimention... -
Page 8: Installation And Accessory Parts
Haier air conditioner Edition: 10070705 6. Installation and Accessory Parts... - Page 9 Haier air conditioner Edition: 10070705 Installation and Accessory Parts HW-05LN03 ASSEMBLE CURTAINS/TOP RAIL Install top rail with 3 short screws13/32". Insert the side curtains into the top and bottom rails of the air conditioner. Fasten the curtains to the unit with 8 short screws...
- Page 10 Haier air conditioner Edition: 10070705 INNER SILL 1. This unit is designed for installation in standard double hung windows with actual opening widths of 22 to 36 . The upper and lower sash must open sufficiently to allow a clear vertical opening of 14 from the OUTER bottom of the sash to the window stool.
- Page 11 Haier air conditioner Edition: 10070705 Installation and Accessory Parts INSTALL THE AIR CONDITIONER WINDOW FRAME IN THE WINDOW UPPER GUIDE Carefully lift the air conditioner and slide it into the open window. Make sure the bottom guide of the air conditioner ABOUT 1/ 4 drops into the notches of the basepan angle.
- Page 12 Haier air conditioner Edition: 10070705 wood screws 31/ 32" top rail window seal gasket short screws 13/ 32" Model:HW-05LN03 Installation and Accessory Parts...
-
Page 13: Parts And Functions
Haier air conditioner Edition: 10070705 7. Parts and Functions MODEL: HW-05LN03 2. MODE Set Switch... -
Page 14: System Flow Chart
Haier air conditioner Edition: 10070705 8.System Flow Chart Indoor Outdoor heat exchanger heat exchanger Compressor Capacillary tube Cooling... -
Page 15: Maintenance Service And Trouble Shooting
Haier air conditioner Edition: 10070705 9.Maintenance Service and Trouble Shooting Alwa ys unplug your air conditioner before clea ning. The air filter behind the front grille should be checked a nd cleaned a t least once every 2 weeks or more often if necessa ry. -
Page 16: Trouble Shooting
Haier air conditioner Edition: 10070705 Maintenance Service and Trouble Shooting Trouble Shooting If air conditioner does not operate: Check if unit is plugged in.The plug may have come loose. Check if the unit is in “off” mode. The fan control may be in “off” position. -
Page 17: Wiring Diagram
Haier air conditioner Edition: 10070705 10.Wiring Diagram WIRING DIAGRAM 0010552091 FAN MOTOR CAPACITOR SWITCH 1 HIGH SWITCH 2 ON 1 ROOM THERMOSTAT COMPRESSOR (Plain) CAPACITOR (Ribbed) OVERLOAD POWER SUPPLY RELAY G:GREEN Y:YELLOW B:BLACK R:RED BL:BLUE GR:GREY Note: Because of the difference of compressor, Y/G:YELLOW/GREEN the dotted line part may not exist. -
Page 18: Compressor Performance Diagram
Haier air conditioner Edition: 10070705 11. Compressor performance diagram... - Page 19 Haier air conditioner Edition: 10070705 Sincere Forever Haier Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com...
- Page 20 HW-05LN03 The End Sincere Forever Haier Group Haier Industrial Park, No.1, Haier Road Edited by: zhujie 266101, Qingdao, China E-mail: hractech@haier.com Signed by: yangbifei Tel: +86 532 87636957 Http://www.haier.com Approved by: zhuzhenxue Domestic Air Conditioner...
