Ricoh B121 Service Manual page 402

BIT SWITCHES
System Switch 02
No
0-1 Not used
2 Communication stall fail safe.
0: Disabled
1: Enabled
3-4 Not used.
5 Not used
6 Memory read/write by RDS
to Bit 7 6
7 0 0
0 1
1 0
1 1
System Switch 03
No
0 Length of time that RDS is
to temporarily switched on when
7 bits 6 and 7 of System Switch
02 are set to "User selectable"
System Switch 04
No
0-2 Not used
3 Printing dedicated TX
parameters on Quick Dial Lists
0: Disabled
1: Enabled
⇒
4 Not used
5 Memory file transfer operation
0: User level
1: Service level
B620
FUNCTION
Setting
Always disabled
User selectable
User selectable
Always enabled
FUNCTION
FUNCTION
COMMENTS
Do not change the settings.
If enabled, the machine cuts communication within
one hour of a communication error but the
connection remains established.
Do not change the settings.
Do not change the setting.
(0,0): All RDS systems are always locked out.
(0,1), (1,0): Normally, RDS systems are locked out,
but the user can temporarily switch RDS on to allow
RDS operations to take place. RDS will
automatically be locked out again after a certain
time, which is stored in System Switch 03. Note that
if an RDS operation takes place, RDS will not switch
off until this time limit has expired.
(1,1): At any time, an RDS system can access the
machine.
COMMENTS
00 - 99 hours (BCD).
This setting is only valid if bits 6 and 7 of System
Switch 02 are set to "User selectable".
The default setting is 24 hours.
COMMENTS
Do not change the settings.
1: Each Quick dial number on the list is printed with
the dedicated TX parameters (10 bytes each).
The first 10 bytes of data are the programmed
dedicated TX parameters; 34 bytes of data are
printed (the other 24 bytes have no use for service
technicians).
Do not change the setting.
If the machine is unable to print fax messages due
to a mechanical problem, change this bit to 0 to
transfer all messages in the memory (including
confidential rx messages) to another terminal.
Always reset this bit to 1 after transfer. However,
this bit can be left at 0, if the customer's key-
operators want to transfer the files themselves.
This machine does not support the confidential RX.
Refer to Memory File Transfer Operation Procedure
on page 29
...continued
22
Rev.09/2005
SP No. 1-101-003
SP No. 1-101-004
SP No. 1-101-005
B620
