- Page 1 High Wall Inverter YVHC 09 to 12 SERVICE MANUAL YVHC 09 · YVHC 12 TI-YVHC-09-12GB 03-07...
- Page 2 Fig. 1 > 15 cm > 15 cm >15 cm > 70 cm AUTO CALEFACCIÓN REFRIGERACIÓN / DESHUMIDIFICACIÓN HEAT COOL / DRY SWING LIGHT AIR CHAUD FROID / DÉSHUMIDIFICATION AQUECIMENTO REFRIGERAÇÃO / DESHUMIDIFICAÇÃO RISCALDAMENTO RAFREDAMENTO / DEUMIDIFICAZIONE HEIZEN KÜLEN / ENTFEUCHTEN VERWARMING KOELING / ONTVOCHTIGING OPPVARMING...
- Page 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 Panel frontal Cable de interconexión Cinta vinilo Front panel Vinyl tape Interconnecting cable Câblage d'interconnexion Panneau frontal Ruban de vinyle Cabo de interligação Painel frontal Fita de vinilo Cavo di collegamento Pannello frontale Nastro vinilico Verbindungskabel Frontblende...
- Page 4 Dimensiones generales / General dimensions mm / Dimensions générales / Dimensões gerais Dimensioni d'ingombro / Algemeine abmessungen / Algemene afmetingen / Generelle dimensjoner YVKC09DS-AAA, YVKC12DS-AAA Datos físicos / Physical data / Données physiques / Dados físicos Dati tecnisi / Physikalische Angaben / Fysieke gegevens / Fysiske data YVKC09DS-AAA YVKC12DS-AAA Modelo / Model / Modèle / Modelo / Modello / Modell / Model / Modell...
-
Page 5: Installation Instructions
Installation Instructions of the indoor unit on the upper edge of the Cable section mounting plate (see Fig. 2). Inspection Make sure the unit is installed properly, YVKC09DS YVKC12DS Sizes Upon reception, inspect the equipment and moving it first to the left and then to the notify both the carrier and the insurance right. - Page 6 Wiring Fig. 8 GROUND TERMINAL CLAMP BLUE BROWN CONNECTING CABLE Models YVKC09DS YVKC12DS POWER SUPPLY 230/1 Ph/50 Hz MA AM/V BROWN INDOOR AM/V: YELLOW/GREEN N(1) UNIT BLUE YELLOW MA AM/V BLACK OUTDOOR N(1) UNIT All data subject to change without notice.
-
Page 7: Connection Schema
Connection Schema Indoor units YVKC 09-12 Outdoor units YVJC 09-12 All data subject to change without notice. -
Page 8: Spare Parts
Spare parts Indoor unit YVKC 09 All data subject to change without notice. -
Page 9: Indoor Unit
Spare parts Indoor unit YVKC 09 Description Part Code P P r r o o d d u u c c t t C C o o d d e e YVKC 09 Wall Mounting Frame 01252001 Pipe Clamp 24242001 Rear Case 22202327 Motor FN20Y... - Page 10 Spare parts Indoor unit YVKC 12 All data subject to change without notice.
- Page 11 Spare parts Indoor unit YVKC 12 Description Part Code E E x x p p l l o o d d e e d d V V i i e e w w YVKC 12 P P r r o o d d u u c c t t C C o o d d e e Wall Mounting Frame 01252001 Pipe Clamp...
- Page 12 Spare parts Outdoor unit YVJC 09 All data subject to change without notice.
-
Page 13: Outdoor Unit
Spare parts Outdoor unit YVJC 09 Description Part Code E E x x p p l l o o d d e e d d V V i i e e w w YVJC 09 P P r r o o d d u u c c t t C C o o d d e e Front Panel 01533005 Clap Board... - Page 14 Spare parts Outdoor unit YVJC 12 All data subject to change without notice.
- Page 15 Spare parts Outdoor unit YVJC 12 Part Code Description E E x x p p l l o o d d e e d d V V i i e e w w YVJC 12 P P r r o o d d u u c c t t C C o o d d e e Front Panel 01533005 Clap Board...
- Page 16 Operating and maintenance instructions Infrared ray remote control unit COOL FAN SPEED HEAT HORIZONTAL SWING: AUTOMATIC ROTATION OF VERTICAL LOUVERS AUTO AUTOFAN OPER AUTO SLEEP °C RE-BACTERIA AUTO PURIF AUTO FAN HUMID FAN SPEED TIMER ON/OFF VERTICAL SWING: AUTOMATIC ROTATION OF HORIZONTAL LOUVERS DISPLAY LIGHT...
-
Page 17: Timer Operations
of any trouble. 3. Adjusting ambient temperature and Heat, is a program that controls the ambient temperature at night. Press the buttons to change the Operation of the system in Emergency ambient temperature set point. This should Cool mode mode remain between 16 and 30°C. -
Page 18: Troubleshooting
Trouble shooting Problem Possible cause and correction A. Air conditioning unit inoperative. 1. Make sure fuse is not blown out or main switch has not been activated. 2. Is main switch set to OFF? 3. Has any mistake been made when programming? B. - Page 19 LED codes in High Wall and cassette units Error code Failures description or protection behavier Indoor LED Behavier on display The LED extinguishs for 3 seconds then flicker 1 times. HP Protection. When inner tube temperature is low, the preset program will cut The LED extinguishs for 3 seconds then flicker 2 times.
- Page 20 DECLARACION CE DE CONFORMIDAD SOBRE MAQUINAS FABRICANTE: CLIMA ROCA YORK, S.L. DIRECCIÓN: Paseo Espronceda, 278, 08204 SABADELL La máquina corresponde a las exigencias básicas de la Directiva de la CE sobre máquinas (Directiva "CE" 89/392/CEE), incluidas las modificaciones de la misma y la correspondiente transposición a la ley nacional.
- Page 21 www.johnsoncontrols.com TI-YVHC-09-12GB 03-07...
