OPERATION MANUAL
MODELS VSD 270, 292, 351, 385, 419, 424, 503, 608, 658, AND 704
MODELS LVD 270, 292, 351, 385, 419, 424, 503, 608, 658, 704, AND 900
VSD MODELS
270 HP – 60 HZ, 400 VAC
292 HP – 50 HZ, 400 VAC
292 HP – 50 HZ, 415 VAC
351 HP – 60 HZ, 460 VAC
385 HP – 60 HZ, 400 VAC
419 HP – 50 HZ, 400 VAC
419 HP – 50 HZ, 415 VAC
424 HP – 60 HZ, 575 VAC
503 HP – 60 HZ, 460 VAC
608 HP – 60 HZ, 575 VAC
658 HP – 50 HZ, 400 VAC
704 HP – 50 HZ, 415 VAC
LIQUID COOLED OPTISPEED™
COMPRESSOR SPEED DRIVE
Supersedes: 160.00-O4 (415)
LVD MODELS
270 HP – 60 HZ, 380 VAC
270 HP – 60 HZ, 400 VAC
292 HP – 50 HZ, 400 VAC
292 HP – 50 HZ, 415 VAC
351 HP – 60 HZ, 460 VAC
385 HP – 60 HZ, 380 VAC
385 HP – 60 HZ, 400 VAC
419 HP – 50 HZ, 400 VAC
419 HP – 50 HZ, 415 VAC
424 HP – 60 HZ, 575 VAC
503 HP – 60HZ, 460 VAC
608 HP – 60HZ, 575 VAC
Issue Date:
December 19, 2017
Form 160.00-O4 (1217)
00633VIP
658 HP – 50 HZ, 400 VAC
704 HP – 50 HZ, 415 VAC
900 HP – 50 HZ, 400 VAC
900 HP – 50 HZ, 415 VAC
