Initial Setup - RC Aerodyne 450 scale fuselage Airwolf Instruction Manual

INITIAL SET UP
1. Assemble the control arms and add the ball links to the arms. Attach the ball links to the control rods.
2. Attach the control arms to the control rods. Attach the small rod to the nose control arm. Attach the nose
gear to the control arms with the smaller carbon fiber rod. Ensure that the metal spacers and the mounts are on
the rod as shown above.
3. Attach the nose gear to the fuselage using the bolts and nuts provided. Bolt from the underside of the
fuselage.
4
