Page 1 Copyright © 2010, DVTel Inc., All Rights Reserved. All text and figures included in this publication are the exclusive property of DVTel Inc., and may not be copied, reproduced or used in any way without the express written permission of DVTel Inc. Information in this document is subject to change without notice.
Page 2: Table Of Contents
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Contents Overview ........................ 1 Features ........................1 Package Contents ....................2 Introduction of the CF-4221-00 Fixed IP Camera ..........2 CF-4221-00 Camera Dimensions ................3 Camera’s Connectors ....................4 System Requirements ................... 5 Indoor Installation ....................
Page 3 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.15 View Log File ....................75 6.3.16 View User Information ................... 76 6.3.17 View Parameters ................... 78 6.3.18 Factory Default ....................79 6.3.19 Software Version ................... 80 6.3.20 Software Upgrade ..................81 6.3.21...
Page 4: Overview
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Overview The DVTel CF-4221-00 Fixed IP Camera provides real-time H.264 multi-streaming at the highest image quality. With its compact, sophisticated mechanical design and snap-in camera chassis, the DVTel CF-4221-00 Fixed IP Camera is easily installed and aesthetic.
Page 5: Package Contents
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 1.2 Package Contents Please check the package contains the following items listed below. IP Camera Package Contents Back focus adjuster Full HD Multiple Streaming IP Camera Quick Install Guide (bundled software and...
Page 6: Cf-4221-00 Camera Dimensions
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 2.1 CF-4221-00 Camera Dimensions The DVTel CF-4221-00 Fixed IP Camera’s dimensions are shown below. Dimensions Related Link Appendix A: Technical Specifications...
Page 7: Camera's Connectors
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 2.2 Camera’s Connectors The diagram below shows the CF-4221-00’s reset button and various connectors. Definition for each connector will be given as follows. DC 12V/ AC 24V/ PoE Definition Remarks LINE OUT & LINE IN /...
Page 8: System Requirements
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Definition Remarks Network LEDs Network connection and activity indication Output＋ Output－ D－ (Future use) DC 12V Input＋ D＋ (Future use) AC 24V Input－ DC VIDEO VIDEO (BNC connector) For video output...
Page 9: Indoor Installation
Use of Category 5 Ethernet cable is recommended for network connection; to have best transmission quality, cable length shall not exceed 100 meters. Connect one end of the Ethernet cable to the RJ-45 connector of the CF-4221-00 camera, and the other end of the cable to the network switch or PC.
Page 10: Lens Mounting
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Check the status of the link indicator and activity indicator LEDs; if the LEDs are unlit, please check LAN connection. Green Link Light indicates good network connection. Orange Activity Light flashes for network activity indication.
Page 11 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide To mount a lens on the CF-4221-00 camera. 1.) Remove the plastic insert covering the threaded camera lens mount. Tip: Do not touch the sensor or allow dust to accumulate in the lens-mount.
Page 12: Camera Initial Configuration
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 4.3 Camera Initial Configuration To Make the Camera Initial Configuration 1.) Plug the CAT5 cable into the camera Ethernet port and if the network doesn’t provide PoE 802.3af, wire a properly rated AC 24V/DC 12V power supply into the terminal- block plug and plug it into the power terminals.
Page 13: Mounting The Dvtel Cf-4221-00 Fixed Ip Camera
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 4.4 Mounting the DVTel CF-4221-00 Fixed IP Camera To mount a DVTel CF-4221-00 Fixed IP Camera Warning: The HD Series Indoor Camera must be kept in a clean and dry indoor environment or in a protective camera housing.
Page 14 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Loosen the screws or unlatch the camera housing lid, open the housing and loosen the plastic cable glands (cable fittings) Thread the cables through the cable glands into the camera housing.
Page 15: Adjusting And Framing Up The Camera View
 Log in using the default user name “Admin” and password “1234”.  Allow the ActiveX to download and choose to install the DVTel Web Player. Tip: To view greater image detail for more accurate high-definition focusing, on the Web Base Viewer homepage click and use the full screen view for checking adjustments.
Page 16 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide For Indoor/Outdoor installations using a protective camera housing: Support the camera housing and loosen the tension bolt on the bracket pan/tilt assembly enough that it allows you to reposition the camera housing.
Page 17: Searching And Accessing Camera - Device Search
If you are working with DVTel Latitude, you will want to configure the unit with a static IP rather than with DHCP to assure the IP address will not automatically change in the future and interfere with configurations and communication.
Page 18 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide To configure the communication settings of the CF-4221-00 camera 1.) Connect the CF-4221-00 camera to the network on the same VLAN/LAN as the workstation. (You can use a cross cable to connect it to the machine directly).
Page 19 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Click “Device Search” again, and all the finding IP devices will be listed in the page, as shown in the figure below. The IP Camera’s default IP address is: 192.168.0.250. 5.) Right-click on the IP Camera that you would like to change its network property and from the menu that opens, select “Network Setup.”...
Page 20 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.) Do the one of the following: For DHCP (not supported by Latitude) Select “DHCP” (Do not use for Latitude.) Click “Apply”, when prompted with instructions to search again after one minute, click After a minute click “Device Search”.
Page 21 NOTE: If you change the password, and you are using the DVTel Latitude AdminCenter Discovery feature, you will need to deselect all other proprietary types and select only DVTel HD Series so that you can configure the new password in the Discovery tab settings.
Page 22: Configuration & Operation
In this chapter, information about main page introduction, system related settings and camera settings will be described in detail. Additionally, if you have DVTel Latitude many of the configurations and features of DVTel’s NVMS provide configuration and automation of the DVTel CF-4221-00 Fixed IP Camera.
Page 23: Browser-Based Viewer Introduction
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.1 Browser-based Viewer Introduction The figure below shows the main page of the IP Camera user interface.
Page 24 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide There are five tabs: Home, System, Streaming, Camera and Logout on the top panel. Home Page  Users can monitor live video of the targeted area. System Settings  The administrator can set host name, system time, root password, network related settings, etc.
Page 25: Home Page
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.2 Home Page In the Home page, there are several function buttons right down the displayed image. Multiple Languages Support Multiple languages are supported, including English, Deutsch (German), French, Italian, Simplified Chinese, Russian, or Korean for the viewer window interface.
Page 26 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Talk button (on/off) Talk function allows the local site to talk to the remote site. Click on the button to switch it to on/off. Please refer to section 7.3.2 Security: Add user >> Talk/Listen for further details.
Page 27: System Related Settings
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3 System Related Settings The figure below shows all categories under the “System” tab. Each category in the left column will be explained in the following sections. NOTE: The “System” configuration page is only accessible by Administrator.
Page 28: Host Name And System Time Setting
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.1 Host Name and System Time Setting Press the first category: <System> in the left column; the page is shown as below. Host Name The name is for camera identification. If alarm function (see section...
Page 29 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Sync With Computer Time Select the item, and video date and time display will synchronize with the PC’s. Manual The Administrator can set video date, time and day manually. Entry format should be identical with that shown next to the enter field.
Page 30: Security
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.2 Security Click the category: <Security>, there will be a drop-down menu with tabs including <User>, <HTTPS>, <IP Filter>, and <IEEE 802.1X>. Related Links User HTTPS IP Filter IEEE 802.1X...
Page 31: User
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.2.1 User Click the <User> tab under the category <Security> and the page is shown as the figure below. Root password Change the administrator’s password by inputting the new password in both text boxes. The input characters/numbers will be displayed as dots for security purposes.
Page 32 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Add user Type the new user's name and password and click <Add> to add the new user. Both user name and password can be up to 16 characters. The new user will be displayed in the user name list.
Page 33 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide NOTE: It is required to enter the User password as well as select the function open to the user. When finished, click <Save> to modify the account authority.
Page 34: Https
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.2.2 HTTPS <HTTPS> allows secure connections between the IP Camera and web browser using <Secure Socket Layer (SSL)> or <Transport Layer Security (TLS)>, which ensure camera settings or Username/ Password info from snooping. It is required to install a self-signed certificate or a CA-signed certificate for implementing <HTTPS>.
Page 35 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Create Self-signed Certificate Before a CA-issued certificate is obtained, users can create and install a self-signed certificate first. Click <Create> button under “Create self-signed certificate” and provide the requested information to install a self-signed certificate for the IP Camera. Please refer to the last part...
Page 36 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Create Certificate Request Click the “Create Certificate Request” button to create and submit a certificate request in order to obtain a signed certificate from CA. Provide the request information in the create dialog. Please refer to the following...
Page 37 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide...
Page 38 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Provide the Certificate Information To create a Self-signed HTTPS Certificate or a Certificate Request to CA, please enter the information as requested:...
Page 39 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Country Enter a 2-letter combination code to indicate the country the certificate will be used in. For instance, type in “US” to indicate United States. State or province Enter the local administrative region.
Page 40: Ip Filter
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.2.3 IP Filter Using the IP filter, access to the IP Camera can be restricted by denying/allowing specific IP addresses. General Enable IP Filter Check the box to enable the IP Filter function. Once enabled, the listed IP addresses (IPv4) will be allowed/ denied access to the IP Camera.
Page 41: Ieee 802.1X
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Add/ Delete IP Address Input the IP address and click the <Add> button to add a new filtered address. The Filtered IP Addresses list box shows the currently configured IP addresses. Up to 256 IP address entries may be specified.
Page 42 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide...
Page 43 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide CA Certificate The CA certificate is created by the Certification Authority for the purpose of validating itself. Upload the certificate for checking the server’s identity. Client Certificate/ Private Key Upload the Client Certificate and Private Key for authenticating the IP Camera itself.
Page 44: Network
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.3 Network Click the category: < Network>, there will be a drop-down menu with tabs including <Basic>, <QoS>, <SNMP>, and <UPnP>. Related Links Basic QoS (Quality of Service) SNMP (Simple Network Management Protocol)
Page 45: Basic
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.3.1 Basic Users can choose to connect to the IP Camera with fixed or dynamic (DHCP) IP address. The IP Camera also provides PPPoE (Point-to-Point Protocol over Ethernet) support for users who connect to the network via PPPoE.
Page 46 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide NOTE: Please make the record of the IP Camera’s MAC address, which can be found in the label of the camera, for identification in the future. Use fixed IP address To setup static IP address, select “Use fixed IP address” and move the cursor to the IP address blank (as indicated below) and insert the new IP address, ex.
Page 47 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide When using static IP address to login to the IP Camera, users can access it either through “DeviceSearch” software (see Accessing Camera) or input the IP address in the URL bar and press “Enter”.
Page 48: Qos (Quality Of Service)
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide NOTE: Be aware to assign a different port number for each separate service mentioned above. IPv6 Address Configuration With IPv6 support, users can use the corresponding IPv6 address for browsing. Enable IPv6 by checking the box and click “Save”...
Page 49 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide DSCP Settings The DSCP value range is from 0 to 63. The default DSCP value is 0, which means DSCP disabled. The IP Camera uses the following QoS Classes: Video, Audio and Management.
Page 50: Snmp (Simple Network Management Protocol)
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.3.3 SNMP (Simple Network Management Protocol) With Simple Network Management Protocol (SNMP) support, the IP Camera can be monitored and managed remotely by the network management system.
Page 51 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide SNMP v1/ v2 Enable SNMP  Select the version of SNMP to use by checking the box. Read Community  Specify the community name that has read-only access to all supported SNMP objects.
Page 52: Upnp
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.3.4 UPnP...
Page 53 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide UPnP Setting Enable UPnP  When the UPnP is enable, whenever the IP Camera is presented to the LAN, the icon of the connected IP Cameras will appear in My Network Places to allow for direct access as shown below.|...
Page 54: Ddns
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.4 DDNS Dynamic Domain Name System (DDNS) allows a host name to be constantly synchronized with a dynamic IP address. In other words, it allows those using a dynamic IP address to be...
Page 55: Mail
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Enable DDNS Check the item to enable DDNS. Provider  Select one DDNS host from the provider list. Host name  Enter the registered domain name in the field. Username/E-mail ...
Page 56: Ftp
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Two sets of SMTP can be configured. Each set includes SMTP Server, Account Name, Password and E-mail Address settings. For SMTP server, contact your network service provider for more specific information.
Page 57 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide user name, and password in the fields. <Alarm> triggered and <Motion Detection> notifications can be sent to the specified <HTTP> server. Click “Save” when finished. Please refer to: 7.3.8 Application: Send HTTP notification/ 7.3.9 Motion Detection for HTTP...
Page 58: Application
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.8 Application The IP Camera has one alarm input and one relay output for connection to external alarm devices. Refer to alarm pin definition below to connect alarm devices to the IP Camera if needed.
Page 59 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Alarm Switch The Administrator can enable or disable the alarm function. Alarm Type Select an alarm type, “Normal close” or “Normal open,” that corresponds with the alarm application. Alarm Output Define alarm output signal “high” or “low” as the normal alarm output status according to the current alarm application.
Page 60 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Enable Alarm Output  Select the item to enable alarm relay output. Send Alarm Message by FTP/E-Mail  The Administrator can select whether to send an alarm message by FTP and/or E-Mail when an alarm is triggered.
Page 61 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Record Stream to SD Card  Select the item, and the alarm-triggered recording will be saved into your Micro SD card. NOTE: Please make sure the local recording (with Micro SD/ SDHC card) is activated so that this function can be implemented.
Page 62 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Upload Image by E-Mail  Select this item, and the Administrator can assign an e-mail address and configure various parameters as shown in the figure below. When the alarm is triggered, event images will be sent to the appointed e-mail address.
Page 63 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Send HTTP notification  Check this item, select the destination HTTP address, and specify the parameters for event notifications by <Alarm> triggered. When an alarm is triggered, the notification can be sent to the specified HTTP server.
Page 64 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Add sequence number suffix (no maximum value)  File name: imageXXXXXXX.jpg X: Sequence Number Add sequence number suffix (limited value)  File Name: imageXX.jpg X: Sequence Number The file name suffix will end at the number being set. For example, if the setting is up to “10,”...
Page 65: Motion Detection
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.9 Motion Detection Motion Detection function allows detecting suspicious motion and triggering alarms when motion volume in the detected area reaches/exceeds the determined sensitivity threshold value. In the Motion Detection setting page, there is a frame (Motion Detection Window) displayed on the Live View Pane.
Page 66 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide If Motion Detection function is activated, the pop-off window (Motion) with indication of motion will be shown. When motion is detected, the signals will be displayed on the Motion window as shown below.
Page 67 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Triggered Action (Multi-option) The Administrator can specify alarm actions that will take when motion is detected. All options are listed as follows: Enable Alarm Output  Check the item and select the predefined type of alarm output to enable alarm relay output when motion is detected.
Page 68 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide for further details. Send HTTP notification  Check this item, select the destination HTTP address, and specify the parameters for event notifications by <Motion Detection> triggered. When an alarm is triggered, the notification can be sent to the specified HTTP server.
Page 69: Tampering
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.10 Tampering Tempering Alarm function helps the IP Camera against tampering such as deliberate redirection, blocking, paint spray, and lens cover, etc through video analysis and reaction to such events by sending out notifications or uploading snapshots to the specified destination(s).
Page 70 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Tampering Duration Minimum Tampering Duration is the time for video analysis to determine whether camera tampering has occurred. Minimum Duration could also be interpreted as defining the Tampering threshold; longer duration represents higher threshold. Settable Tampering Duration time range is from 10 to 3600 seconds.
Page 71: Storage Management
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Upload Image by E-Mail  Select this item, and the Administrator can assign an e-mail address and configure various parameters as shown in the figure below. When tampering is detected, event images will be sent to the appointed e-mail address.
Page 72 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide NOTE: Please format the Micro SD/SDHC card when using for the first time. Formatting will also be required when a memory card already being used on one camera and later transferred to another camera with different software platform.
Page 73 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Device setting Press the “Format” button to format the memory card. Disk cleanup setting Users can enable automatic recordings cleanup by specifying the time and storage limits Recording List Each video file on the Micro SD/SDHC card will be listed in the Recording list as shown below.
Page 74 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Download  To open/download a video clip, select the file first, and then press the “Download” button below the Recording list field. The selected file window will pop up as shown below. Click on the AVI file to directly play the video in the...
Page 75: Recording
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.12 Recording In the Recording setting page, users can specify the recording schedule that fits the present surveillance requirement. Activating Micro SD/SDHC Card Recording Two types of schedule mode are offered: Always and Time Frame setting. Users can setup the time frame to fit the recording schedule or choose “Always”...
Page 76: File Location
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.13 File Location Users can specify a storage location for the snapshots and web recording. The default setting is: C:\. Once confirm the setting, press “Save,” and all the snapshots and recording will be saved in the designate location.
Page 77: Iris Adjustment
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.14 Iris Adjustment For users who use Auto-iris lens, when it is required to implement iris adjustment, please refer to the Iris adjustment procedure in the setting page to adjust iris.
Page 78: View Log File
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.15 View Log File Click on the link to view the system log file. The content of the file provides useful information about configuration and connections after system boot-up.
Page 79: View User Information
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.16 View User Information The Administrator can view each added user’s login information and privileges (see Security). View User Login Information All the users in the network will be listed in the “User information” zone, as shown below. As...
Page 80 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide View User Privilege Press “Get user privacy” down the page, and the Administrator can view each user’s privileges. As the figure above shows: User: 1:1:0:1 1:1:0:1= I/O access : Camera control : Talk : Listen (see Security)
Page 81: View Parameters
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.17 View Parameters Click on this item to view the entire system’s parameter setting.
Page 82: Factory Default
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.18 Factory Default The factory default setting page is shown as below. Follow the instructions to reset the IP Camera to factory default setting if needed. Set Default Click on the “Set Default” button to recall the factory default settings. Then the system will restart in 30 seconds.
Page 83: Software Version
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.19 Software Version The current software version is displayed in the software version page, which is shown as the figure below.
Page 84: Software Upgrade
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.20 Software Upgrade Software upgrade can be carried out in the “Software Upgrade” page, as shown below. NOTE: Make sure the upgrade software file is available before carrying out software upgrade.
Page 85 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide To upgrade the firmware 1.) Click “Browse” and select the binary file to be uploaded, ex. Userland.IMG. NOTE: Do not change the upgrade file name, or the system will fail to find the file.
Page 86 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 2.) Pull down the upgrade binary file list and select the file you want to upgrade; in this case, select “Userland.IMG.” 3.) Press “Upgrade”. The system will first check whether the upgrade file exists or not, and then begin to upload the upgrade file.
Page 87: Maintenance
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.3.21 Maintenance Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the IP Camera.
Page 88: Video And Audio Streaming Settings
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Export Users can save the system settings by exporting the configuration file (.bin) to a specified location for future use. Press the “Export” button, and the popup File Download window will come out as shown below.
Page 89: Video Resolution And Rotate Type
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.4.1 Video Resolution and Rotate Type The video setting page is shown below:...
Page 90 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide H.264 + H.264 Video Resolution: H.264 + H.264 H.264-1 H.264-2 BNC SUPPORT √ 720 x 480 (30fps)* √ 1920 x 1080 (30fps) 640 x 480 (30fps) √ 352 x 240 (30fps) √...
Page 91: Text Overlay Settings
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide MJPEG + H.264 Video Resolution: H.264 + MJPEG H.264 MJPEG BNC SUPPORT √ 720 x 480 (30fps) √ 1920 x 1080 (30fps) 640 x 480 (30fps) √ 352 x 240 (30fps) √...
Page 92 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Video Rotate Type Users can change video display type if necessary. Selectable video rotate types include Normal, Flip, Mirror and 180 degree. Differences among these types are illustrated as below. Suppose the displayed image of the IP Camera is shown as the figure below.
Page 93: Video Compression
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Click “Save” to confirm the setting. GOV Settings Users can set the GOV length to determine the frame structure (I-frames and P-frames) in a video stream for saving bandwidth. The setting range is from 2 to 64. Longer GOV means decreasing the frequency of I-frames.
Page 94 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide H.264-1/ H.264-2 bit rate The default setting of H.264-1/ H.264-2 is 4096 kbps; the setting range is from 64 to 8192 kbps. Display Compression Information Users can also decide whether to display compression information on the Home page.
Page 95: Video Ocx Protocol
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.4.3 Video OCX Protocol In the Video OCX protocol setting page, users can select RTP over UDP, RTP over TCP, RTSP over HTTP or MJPEG over HTTP, for streaming media over the network. In the case of multicast networking, users can select the Multicast mode.
Page 96: Video Frame Rate
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.4.4 Video Frame Rate Video frame rate is for setting the frames per second (fps) if necessary. The setting page is shown as below. MJPEG/ H.264-1/ H.264-2 Frame Rate The default setting of MJPEG Frame Rate is 30 fps; the setting range is from 1 to 30.
Page 97 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Active Mask Function Add a Mask  Check a Video Mask checkbox, and a red frame will come out in the Live Video pane at the right side. Use the mouse to drag and drop to adjust the mask’s size and place it on the target zone.
Page 98: Audio Mode And Bit Rate Settings
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Mask Setting Mask color  The selections of Mask color include red, black, white, yellow, green, blue, cyan, and magenta. Click “Save” to confirm the setting. 6.4.5 Audio Mode and Bit Rate Settings The audio setting page is show as below.
Page 99 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Transmission Mode Full-duplex (Talk and Listen simultaneously)  In the Full-duplex mode, the local and remote sites can communicate with each other simultaneously, i.e. both sites can speak and be heard at the same time.
Page 100: Camera Settings
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.5 Camera Settings The figure below is the camera configuration page. Details of each parameter setting are described in the following subsections. Related Links  Exposure Setting  White Balance Setting ...
Page 101: Exposure Setting
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.5.1 Exposure Setting The Exposure pull-down menu is shown as follows: The exposure is the amount of light received by the image sensor and is determined by the width of lens diaphragm opening, the amount of exposure by the sensor (shutter speed) and other exposure parameters.
Page 102: White Balance Setting
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.5.2 White Balance Setting The White Balance pull-down menu is shown as follows: A camera needs to find reference color temperature, which is a way of measuring the quality of a light source, for calculating all the other colors. The unit for measuring this ratio is in degree Kelvin (K).
Page 103: Picture Adjustment
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 6.5.3 Picture Adjustment Brightness  Users can adjust the image’s brightness by adjusting the item. Please select ranging from -12 to +13. To increase video brightness, select a bigger number. Press < √ > to confirm the new setting.
Page 104: Digital Zoom
6.5.6 IR Function With the IR cut filter and supporting lens, the CF-4221-00 fixed IP camera can still catch clear image at night time or in low light conditions. Press <√> to confirm the new setting. Press < √ > to confirm the new setting.
Page 105: Tv System
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide The proprietary Smart Picture Quality (SPQ) video processing method could drastically minimum motion blur and provides clear images even in low-light environment. The combination of SPQ and 3DNR at different level further yields exceptional video performance in various conditions.
Page 106 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide...
Page 107: Appendix
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Appendix The following sections are included: Appendix A: Technical Specifications  Appendix B: Internet Security Settings  Appendix C: Install UPnP Components  Appendix D: Deleting the Existing DC Viewer ...
Page 108 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Operation Image Setting Brightness Manual Exposure Auto Iris Auto/Fixed Shutter Sharpness Manual Contrast Manual White Balance Manual / AWB/ ATW Saturation Manual Manual Digital Zoom Support On/Off + 3 Levels 3D Digital Noise...
Page 109 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide Analytics Motion detection On/Off – Sampling Pixel Interval, Detection level, Sensitivity level, and Time interval settings. Regions of Interest Web Interface: Configurable up to 10 ROI masks. Latitude Interface: Configurable up to 6 ROI masks.
Page 110 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide General Operating -10C ~ 50C Temperature Humidity 0% to 90%, no condensation Power Source DC12V/ AC24V/ PoE Power Consumption Regulatory CE marked, EN55022-1998 Class A, EN55024, FCC part 15 (subpart B, class A) UL, RoHS...
Page 111: Appendix B: Internet Security Settings
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 7.2 Appendix B: Internet Security Settings If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default 1.) Start Internet Explorer (IE).
Page 112 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 3.) In the Internet Options dialog that appears, click the Security tab, and if not selected, click 4.) If the settings are not defined as default, click Default Level and move the Allowed levels for this zone slider to Medium-high and click OK 5.) Close all browser windows, and reopen so that the settings to take effect.
Page 113 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide ActiveX Controls and Plug-ins Settings - Creating a Custom Level From the Command Bar toolbar, click Tools and select Internet Options from the menu that appears. 2.) In the Internet Options dialog that appears, click the Security tab, and if not...
Page 114 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 5.) Click OK to accept the settings and close the <Security> screen. 6.) Click OK to close the Internet Options screen. 7.) Close the browser window, and restart IE again for accessing the IP Camera.
Page 115: Appendix C: Install Upnp Components
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 7.3 Appendix C: Install UPnP Components Please follow the instructions below to enable the UPnP to allow the CF-4221-00 camera to be discovered and display in Network locations under Other Devices: To Enable UPnP Discovery 1.) Click...
Page 116 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 4.) Click on “Change Advanced Sharing Settings”. 5.) Expand the Home or Work node, select Turn on network discovery and click Save Changes. Note: Network discovery requires that the DNS Client, Function Discovery Resource...
Page 117 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide To Check the UPnP Device Host services are running: 1.) Click (Start) and type in the Search programs and files field “services” and then select Services from the displayed Programs. The Services manager dialog appears.
Page 118: Appendix D: Deleting The Existing Dc Viewer
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 7.4 Appendix D: Deleting the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, please first delete the existing DC Viewer from the PC before accessing to the IP Camera.
Page 119: Appendix E: Deleting Temporary Internet Files
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 7.5 Appendix E: Deleting Temporary Internet Files To improve browser performance, it is suggested to clean up the all the files in the Temporary Internet Files. The procedure is as follows: To delete temporary Internet files 1.
Page 120 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 2.) In the Internet options dialog, click Delete, and in the Delete Browser History dialog that appears, select Temporary Internet files (Deselect Cookies and History if you want to keep this data.) and then click the Delete.
Page 121: Appendix F: Back Focus Adjustment
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 7.6 Appendix F: Back Focus Adjustment When to adjust back focus Back Focus refers to the distance from the rear lens element to the camera focal plane. In most cases, it is required to adjust back focus only when the camera’s lens cannot hold focus...
Page 122 DVTel CF-4221-00 Fixed IP Camera User & Installation Guide If the image is not focused (sharp), loosen the back focus ring’s retaining screw with the supplied hex tool (if not already loose) and rotate the lens mount to adjust the back focus as needed to achieve a sharp in-focus picture.
Page 123: Appendix G: Contacting Dvtel
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 7.7 Appendix G: Contacting DVTel DVTel, Inc., multiple award-winning market leader in the development and delivery of intelligent security solutions over IP networks. We provide unified solutions leverage existing network infrastructure while providing unmatched levels of flexibility, scalability, cost- effectiveness—all backed by superior customer support.
Page 124: Appendix H: Accessories
DVTel CF-4221-00 Fixed IP Camera User & Installation Guide 7.8 Appendix H: Accessories The following are accessories available from DVTel for installation of your DVTel CF-4221-00 Fixed IP Camera. For more information on available options, contact your DVTel sales representative or visit www.dvtel.com...
