In the interests of user-safety (Required by safety regulations in some countries ) the set should be restored to its
original condition and only parts identical to those specified should be used.
» ELECTRICAL SPECIFICATIONS ......................................................................................................... 1
» IMPORTANT SERVICE SAFETY PRECAUTION ................................................................................. 2
» LOCATION OF USER'S CONTROL ..................................................................................................... 4
» INSTALLATION AND SERVICE INSTRUCTIONS ................................................................................ 5
» SERVICE ADJUSTMENT ..................................................................................................................... 9
» CHASSIS LAYOUT ............................................................................................................................. 12
» BLOCK DIAGRAM .............................................................................................................................. 13
» DESCRIPTION OF SCHEMATIC DIAGRAMS & WAVEFORMS ........................................................14
» SCHEMATIC DIAGRAMS ................................................................................................................... 15
» PRINTED WIRING BOARD ASSEMBLIES ........................................................................................ 22
» PARTS LIST ........................................................................................................................................ 27
» PACKING OF THE SET ...................................................................................................................... 36
POWER INPUT ..................................................... 120V AC, 60 Hz
POWER RATING ................................................................... 155W
PICTURE SIZE .......................................... 3,073 cm
CONVERGENCE ............................................................. Magnetic
SWEEP DEFLECTION .................................................... Magnetic
FOCUS ............................................... Hi-Bi-Potential Electrostatic
INTERMEDIATE FREQUENCIES
Picture IF Carrier Frequency ...... 45.75 MHz (Analog Terrestrial)
Sound IF Carrier Frequency....... 41.25 MHz (Analog Terrestrial)
Color Sub-Carrier Frequency ..... 42.17 MHz (Analog Terrestrial)
IF Center Frequency ........................ 44 MHz (Digital Terrestrial)
AUDIO POWER
OUTPUT RATING .............. 3.0W + 3.0W (at 10% distortion and

SHARP CORPORATION

SERVICE MANUAL

MODEL
CONTENTS

ELECTRICAL SPECIFICATIONS

SPEAKER
SIZE .......................................................... 12 x 5 cm oval (2 pcs.)
2
(476sq inch)
VOICE COIL IMPEDANCE ............................ 16 ohm at 400 Hz
ANTENNA INPUT IMPEDANCE
VHF/UHF ..................................................... 75 ohm Unbalanced
TUNING RANGES
VHF-Channels ............................................................... 2 thru 13
UHF-Channels ............................................................ 14 thru 69
CATV Channels ........................................................... 1 thru 125
Digital Terrestrial Broadcast (VHF/UHF) .......................2 thru 69
(Nominal)
Specifications are subject to change without
Dual CH Operate)
prior notice.
This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
COLOR TELEVISION
Chassis No. GB-3D(1W)
32SC260
(EIA, Channel Plan U.S.A.)
