Glen Dimplex Dimplex 18 OV Installation And Servicing Instructions

Open vented condensing boilers
Hide thumbs Also See for Dimplex 18 OV:
Table of Contents

Advertisement

Quick Links

Enlarged version
751287 OV MANUAL
19/10/10
08:46
Page 1
Glen Dimplex Boilers is continually improving its products and therefore
reserve the right to change product specifications without prior notice.
SALES AND SERVICE: 0844 371 1111
Part No: 751287 - Issue 4 - 07/07/10
Glen Dimplex Boilers
Stoney Lane
Prescot
Merseyside. L35 2XW
For all telephone enquiries call:
0844 371 2222
website:
www.glendimplexboilers.com
Part of the Glen Dimplex Group
Errors & omissions excepted.
© Dimplex Boilers 2008
Dimplex 18 OV
Dimplex 32 OV
Open Vented Condensing Boilers
© Dimplex Boilers 2008
Installation and
Servicing Instructions
These instructions should be left with the user
