LED Control
STATUS
Power Off
Power Off
Failure
Aging
Picture Off
SLEEP TIMER
ON TIMER
The units in this manual contain a self-diagnostic function. If an error occurs, the POWER LED will automatically begin to fl ash. The number of times
the LED fl ashes translates to a probable source of the problem. A defi nition of the POWER LED fl ash indicators is listed in the instruction manual for
the user's knowledge and reference. If an error symptom is diffi cult to reproduced use the Remote Commander to display the record that is stored at
the internal NVM to specify the cause of the failure.
Diagnostic Test Indicators
When an error occurs, the POWER LED will fl ash a set number of times to indicate the possible cause of the problem. If there is more than one error,
the LED will identify the fi rst of the problem areas. If the errors occur simultaneously, the one that corresponds to the fewest fl ashes is identifi ed fi rst.
Results for all of the following diagnostic items are displayed on screen. No error has occurred if the screen displays a "0".
Number of Times
POWER LED Blinks
KDL-26S2000/32S2000/40S2000
POWER LED TIMER LED
Off Off
Lights Green Off
Blinks Red Off
Blinks Green Off
Lights Green Off
Lights Green Lights Red
Lights Green Lights Red
Off Lights Red
Lights Green Lights Red
Lights Green Lights Red
1 Time Abnormal AU Power Voltage (DCALERT 3)
2 Times Abnormal D5V/A9V Power Voltage (DCALERT 2)
3 Times Abnormal Panel Voltage (DCALERT 1)
4 Times Backlight Failure
5 Times Abnormal Main Power Voltage
6 Times Abnormal Speaker Voltage
7 Times Internal Temperature Rise (mainly on the panel side)
PICTURE OFF
LED
Power off using the power switch or
remote control. NOTE: Standby
state does not exist in this model;
Off
however, the microcomputer does
enter into sleep mode.
Off Microcomputer working normally.
Failure causes are classified by the
Off
number of time the red light blinks.
Aging mode is classified by a blinking
Off
green light.
Lights Green No display (black screen).
When SLEEP TIMER is set during
Off power on.
When SLEEP TIMER is set in
Picture Off mode.
Lights Green
When ON TIMER is set and power is
off.
Off
When ON TIMER is set and power is
Off on.
When ON TIMER is set in Picture Off
Lights Green mode.
Monitoring Item
KDL-26S2000/32S2000/40S2000
REMARKS
