With grill and convection

Advertisement

T h i n g s
y o u
SHOULD KNOW!
+
WARNING
When heating liquids, e.g. soups,
sauces and beverages in your
microwave oven, overheating the
liquid beyond boiling point can
occur without evidence of
bubbling.
This could result in a sudden boil
over of the hot liquid.
To prevent this possibility the
following steps should be taken:
Avoid using straight sided
containers with narrow necks.
Do not overheat.
Stir the liquid before placing
the container in the oven and
again halfway through the
heating time.
After heating, allow to stand
in the oven for a short time,
stir or shake them again
carefully and check the
temperature of them before
consumption to avoid burns
(especially, contents of
feeding bottles and baby food
jars).
Arcing
If you see arcing, press
STOP/CLEAR button and correct
the problem.
Arcing is the microwave term for
sparks in the oven.
Arcing is caused by:
• Metal or foil touching the side
of the oven.
• Foil not molded to food
(upturned edges act like
antennas).
• Metal, such as twist-ties,
poultry pins, or gold rimmed
dishes, in the microwave.
• Recycled paper towels
containing small metal pieces
being used in the microwave.
When you unpack your microwave oven from its box, please check it immediately for
damage. If the door is damaged or bent, if there are dents inside the oven etc., get in
touch with your retail outlet immediately.
Using a microwave oven safely
WARNING: If the door or door seals are damaged, the oven must
not be operated until it has been repaired by a trained person.
WARNING: It is hazardous for anyone other than a trained person
to carry out any service or repair operation which involves the
removal of any cover which gives protection against exposure to
microwave energy.
WARNING: Liquids or other foods must not be heated in sealed
containers since they are liable to explode.
WARNING: Only allow children to use the oven without
supervision when adequate instructions have been given so that the
child is able to use the oven in a safe way and understands the
hazards of improper use.
This microwave oven contains no user-serviceable components. Any
adjustments or repairs must be performed by a qualified technician.
Never use the oven with the door open. There is the risk of being
exposed to dangerous microwave energy. Never manipulate or
tamper with the safety locks and the hinges of the door.
Keep the seals and seal surfaces clean and free of contamination
like food remains and cleaner residue.
Microwave heating of beverages can result in delayed eruptive
boiling, therefore care has to be taken when handling the container.
Use the microwave oven for cooking purposes only.
Do not use it to dry animals, clothing, paper or other objects or for
sterilisation or as a storage space for books, cooking utensils etc.
Utensils should be checked to ensure that they are suitable for use
in microwave ovens.
When heating food in plastic or paper containers, check the oven
frequently due to the possibility of ignition.
If smoke is observed, switch off or unplug the appliance and keep
the door closed in order to stifle any flames.
The right place for your microwave oven
The microwave oven can be used as 'free standing' or 'built in'. For 'built
in', please refer to Daewoo Ltd for fitting instructions and Trim Kit.
The area immediately around the oven should be free to allow the
circulation of fresh air for cooling.
Do not place the microwave oven near a radio or television set etc.
This might cause interference.
Never place the oven where it is exposed to convection, steam or
humidity.
The minimum height of free space necessary above top surface of
the oven is 150mm.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOC-875TSL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Daewoo KOC-875TSL

  • Page 1 The microwave oven can be used as ‘free standing’ or ‘built in’. For ‘built sparks in the oven. Arcing is caused by: in’, please refer to Daewoo Ltd for fitting instructions and Trim Kit. • Metal or foil touching the side The area immediately around the oven should be free to allow the of the oven.
  • Page 2: Table Of Contents

    Faulty connections can start fires and create other risks and prevent the oven from working correctly. DAEWOO is not liable for any damage due to faulty connection. A defective power cable must be replaced by a qualified technician with an new special replacement cable from DAEWOO.
  • Page 3: Cooking Safely With Microwaves - The Microwave Oven

    MICROWAVES When preparing ready-to-serve food (like TV dinners) always carefully follow the instructions provided by the food manufacturer on the package and also the tips and O V E N a n d guidelines contained at the end of this manual. Cooking safely with microwaves Microwaves are high frequency electromagnetic waves like radio waves.
  • Page 4 M I C R O WAV E S O V E N a n d The microwave oven Safety door lock The oven will only operate with the door fully closed. When the door is open the oven turns off and will only start again after the door is closed. This special oven window is transparent to light, but prevents microwaves escaping.
  • Page 5: The Controls - Setting The Clock - Child Lock

    U s i n g t h e Your DAEWOO microwave oven always keeps you well informed: the display tells you which buttons can be pressed next or which settings are required (user guide). The controls Display (flashes to tell you what the oven is doing): —...
  • Page 6 U s i n g t h e Setting the clock When not in use the display shows the present time. When first connected to the mains, the display looks like this (also after power disconnection). Hold the button pressed for a few seconds (4 sec.) Start/Clock for 24 hour clock.
  • Page 7: Easy Cooking

    C o o k i n g w i t h MICROWAVES Cookery books and recipes provide details of power settings and times. Easy cooking Set one of the 10 power — levels. Press button 1 - 10 times. 1-10x Turn the dial to set the cooking time.
  • Page 8: Cooking With Microwaves

    C o o k i n g w i t h M I C R O W AV E S Programmed cooking You need set neither power nor time. Select one of the five menu programs. Program Cook — 2 1-5x Select by pressing the button 1 - 5 times.
  • Page 9: Cooking With Convection

    C o o k i n g w i t h The temperature can be selected between 100˚ C and 210˚ C in 10˚ C steps for C O N V E C T I O N cooking and baking. Easy baking Set one of the 12 temperature levels.
  • Page 10 C o o k i n g w i t h C O M B I N A T I O N This appliance has multiple heating systems to help cook meals uniformly and crisply. The oven does not need to be preheated. Pastry and pie combination program Press the Pie button.
  • Page 11: Defrosting By Time

    D E F R O S T I N G ® G R I L L I N G a n d Defrosting by time TIME Press the button twice. — " " appears below "TIME" in the display. TIME Set the defrost time on the dial.
  • Page 12: Defrosting And Grilling

    D E F R O S T I N G G R I L L I N G a n d Easy grilling with top heaters GRILL Press the button once. " " appears below "GRILL" in the display. GRILL Set the grill time on the dial.
  • Page 13: Tips And Guidelines

    Cooking with microwaves differs in some aspects from normal cooking. The guidelines and tips below will help you get better results using a microwave oven. Tips and guidelines Wait time Microwaves do not usually completely penetrate the food on the rotary plate. The wait —...
  • Page 14: Error Messages

    ® A P P E N D I X Skins, peels, shells ... Some foods have a skin, peel or a shell (eggs, potatoes, apples, liver, sausages). Puncture the skin or peel with for example a fork to allow steam to escape and the food to expand - this releases pressure and prevents the food from bursting.
  • Page 15: Before Calling Technical Service

    No components of this microwave oven are user-serviceable. Any repairs or A P P E N D I X adjustments must always be performed by qualified service technicians. Before calling technical service Before calling your technical service, check the following: —...
  • Page 16: Microwave Suitable Dishes And Utensils - Care And Maintenance - Power Supply

    A P P E N D I X Microwave suitable dishes and utensils Microwave suitable dishes are transparent to microwaves (i.e. made of such materials as plastic, glass and ceramics), especially when also fireproof. Suitable dishes only become slightly warm after one minute microwave cooking at high power.
  • Page 17: Technical Data - Electrical Connection

    A P P E N D I X Technical data Power supply 230 V~, 50 Hz Microwave — Power consumption 1500 Watt Power 900 Watt(IEC 705) Frequency 2450 MHz Grill power consumption 1150 Watt Convection power consumption 1550 Watt Combination power consumption 2600 Watt(simultaneous heating model) Dimensions (w-h-d) 501 x 413 x 320 mm Oven chamber (w-h-d)
  • Page 18: Moulded Plugs

    A P P E N D I X Moulded plugs (for UK only) Should it be necessary to remove a moulded on plug from the mains cable, it should be cut off and replaced with a suitable replacement. The moulded plug cannot be used for any other appliance, therefore remove the fuse and dispose immediately and safely to prevent anyone, especially children from plugging it in to a wall socket, which will create a safety hazard.
  • Page 19: Your Product Guarantee

    Dear Customer, Thank you for buying this Daewoo product. In the unlikely event of a failure all repair work will be carried out by your retailer or Daewoo approved service centre, for a period of 12 months from date of sale.
  • Page 20: Microwave Oven

    Microwave Oven with Grill and Convection — Instruction manual KOC-875T/ KOC-875TSL Helpline number: 01189 252627...
