- Page 1 4CH STANDALONE DVR 2008 JUL. Ver 1.0 Remote MOTION MOTION...
-
Page 2: Hdd Support List
HDD SUPPORT LIST Warning： Should you wish to install a new hard drive in this unit, a list of tested hard drives shown to be compatible can be found below. SATA Maxtor Seagate HITACHI Brand 250GB 250G 250GB Capacity/ Model Number STM3250310AS ST3250824AS HDT725025VLA380... -
Page 3: Table Of Contents
CONTENTS 1、FEATURES 2、SPECIFICATIONS 3、INSTALLATION 4、FRONT PANEL 5、OPERATING MANUAL 6、BACKUP 7、 RECORDING PROCEDURE 8、 4-CH CONTINOUS RECORDING HOURS ON SATA 400GB HDD 9、DVR VIEWER USER GUIDE 10、 CONTROL REMOTE GUIDE... -
Page 4: Features
1、FEATURE 、 1 Triplex (Recording, Playback, Network simultaneously) 2、Up to 60fps Recording Speed。 3、USB flash disk backup。 4、Adjust Up/Down/Left/Right screen position。 5、Record in quad mode or single channel。 6、Video Input Signal: NTSC / PAL。 7、Video Compression: Modified MJPEG 8、Manual, Motion, & Programmed。 9、Motion Detection with Adjustable Time Duration。... -
Page 5: Specifications
2、SPECIFICATIONS Video Format NTSC/PAL Operating System Embedded RTOS VGA Output D-SUB 15Pin VGA Video Input BNC x 4 (1Vp-p 75Ω) Audio Input RCA x 1, Line-In Video Output BNC x 1(Main Monitor) Audio Output RCA x 1, Line-Out Display GUI, Multi-Language NTSC 120 fps (4 ×... -
Page 6: Installation
3、INSTALLATION REAR PANEL AUDIO IN DEFAULT DC12V VIDEO OUT AUDIO OUT VIDEO IN (1) XGA Output (Optional) (2) Video Output: BNC x 1 (3) Video IN: BNC x 4 (4) Audio Input: RCA x 1, Line-In (5) Audio Output: RCA x 1, Line-Out (6) Host USB (7)Power Input: For safety reasons, always use the original factory power adaptor attached. -
Page 7: Front Panel
4、FRONT PANEL Up Arrow/CH1: Navigate up through menu options/ Camera 1 full screen display Down Arrow/CH2: Navigate down through menu options/ Camera 2 full screen display Left Arrow/CH3: Navigate left through menu options/ Camera 3 full screen display Right Arrow/CH4: Navigate right through menu options/ Camera 4 full screen display Menu: Main menu/ Show percentage of the hard drive used. -
Page 8: Operating Manual
5、OPERATING MANUAL (MAIN MENU) Setup Setup Camera Record motion Detection Screen Audio System Search Language English Exit 2008/07/01 13:21:14 Press to select items to enter Press MENU to exit Camera Setup Camera Channel Display Brightness Contrast Saturation 2008/07/01 13:21:20 Press to select items to enter Press MENU to exit... - Page 9 Record Setup Record Record Speed Record Quality High Event Rec Duration Record Schedule 2008/07/01 13:21:24 Press to select items to enter Press MENU to exit (1)Record Speed： Set the number of frame per second (fps). NTSC：default: 15 fps，maximum total frame: 60 fps. PAL ：default: 12 fps，maximum total frame:50 fps.
- Page 10 Motion Detection Setup Motion Detection Setup Channel Sensitivity Alarm Duration Motion Area 2008/07/01 13:21:36 Press to select items to enter Press MENU to exit (1)Channel：The diagram above shows Channel 1. (2)Sensitivity：To set Off, or 1 to 4， default: Off. (3)Alarm Duration：To set alarm duration when alarm is triggered by a moving object: Off, 5, 10, 15, 20, 25, 30 seconds, or continuous.
- Page 11 Audio Audio Record Mute Input Volume Output Volume 2008/07/01 13:21:50 Press to select items to enter Press MENU to exit (1) Record： On/Off (2) Mute ： On/Off (3) Input Volume： A djust input volume (4) Output Volume： Adjust output volume. System System Hard Disk Setup...
- Page 12 (1) Hard Drive Disk Setup Hard Drive Disk Setup Overwrite Enable Format HDD Size : 238463MB Used: 4737MB DISK0: 238463MB ST3250824AS PRESS (Ch4) TO STOP RECORDING FIRST 2008/07/01 13:21:50 Press to select items to enter Press MENU to exit (1.1) Overwrite Enable: Enable overwrite when HDD capacity is full: Yes: When HDD overwrite is taking place, the data is stored in duration of 4 hours per event and being recorded continuously.
- Page 13 (3) Time Set Time Set Time Set 2008/07/02 14:08:37 Apply 2008/07/02 14:21:50 (3.1)Time Set：YYYY/MM/DD HH:MM:SS (3.2)Apply：Update and save all changes. (4) Even List Even List 005 08/07/01 13:24:32 REC START 005 08/07/01 09:42:32 REC STOP 005 08/07/01 09:42:32 REC START 005 08/07/01 09:42:32 REC STOP 005 08/07/01 09:42:32 REC START...
- Page 14 (6) F/W Upgrade: F/W Upgrade Current Ver 1.04.1 0701 1.04.1 0701 Press [Play] Start, [MENU] Cancel 2008/07/01 13:36:46 Please save updated firmware on a USB flash drive. Stick it into USB port. The screen will show both current version and new version of firmware. ●...
-
Page 15: Backup
Exit Exit Exit & Save Changes Exit & Discard Changes Load Setup Default 2008/07/02 13:31:30 ：Save and exit changes. Exit & Save Changes (2) Exit & Discard Changes：Exit without saving changes. (3) Load Setup Default: Load factory default setup 6、BACKUP Start 2008/07/01 13:31:20 2008/07/01... -
Page 16: Recording Procedure
7、RECORDING PROCEDURE (1)Press button to start recording. The symbol, will appear on the top right hand corner of each channel in the screen that indicates it is recording live regardless the recording mode is set on continuous or motion recording. 8、4-CH CONTINOUS RECORDING HOURS ON SATA 400GB HDD Recording Results in NTSC Standard... -
Page 17: Dvr Viewer User Guide
9、DVR VIEWER USER GUIDE 1.Playback Recorded File (1.1)Start VVF SLPlayer (1.2)Point the cursor in the screen and right-click “Open File”. Pick and choose the file you want to view in ( .vvf) and play. 2.Capture an image (2.1) During the playback of the backup file, click “Pause”, located on the bottom of the screen. - Page 18 3. Convert File to AVI Format (3.1) Point the mouse cursor to the screen, and press the right button on the mouse, pick and choose「Export」/「AVI」 (3.2) Set Input/Output File 、Compression、Export Channel and Audio. (3.3) Click “OK” to start converting file to AVI format. 4.
-
Page 19: Remote Control Guide
10、REMOTE CONTROL GUIDE (OPTION) CH2 display CH1 display Record CH3 display Quad display/ Sequence Switch CH4 display MUTE MENU Navigator Fast Reverse Fast Forward Play Stop record/ Stop playback Pause... - Page 20 4CH STANDALONE DVR H12C460V01...
