For Parts Call K&T 606-678-9623 or 606-561-4983
IMPORTANT MANUAL
OWNER'S MANUAL
MODEL:
PR20PH42STC
LAWN TRACTOR
Always Wear Eye Protection During Operation
www.mymowerparts.com
Do Not Throw Away
WARNING:
Read this Owner's Manual and
follow all Warnings and Safety
Instructions. Failure to do so
can result in serious injury.
183284 Rev. 1 09.20.02 RD/MH
Printed in U.S.A.
