FMI FGPN Installation Instructions Manual

Unvented (vent-free) universal firebox

Advertisement

WARNING: If the information in this manual is
not followed exactly, a fire or explosion may result
causing a property damage, personal injury or
loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service or the gas supplier.
This firebox may be installed in an after market* manufactured (mobile) home, where not prohibited by state or
local codes.
Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer (i.e. Installation of this product is permitted after the manufactured (mobile) home is
sited).
Model FGPN
36" Peninsula Heat-Circulating Firebox
Save this manual for future reference.
UNVENTED (VENT-FREE)
UNIVERSAL FIREBOX

INSTALLATION INSTRUCTIONS

WARNING:
adjustment,
maintenance can cause injury or property
damage. Refer to this manual for correct
installation and operational procedures. For
assistance or additional information consult
a qualified installer , service agency or the
gas supplier.
WARNING: For use only with decorative
type unvented room heaters. Do not build a
wood fire.
This firebox has been tested and approved
by I.A.S. under their REQ. 2-97 for use with
any ANS Z21.11.2 approved gas logs.
D1115
Improper
installation,
alteration,
service
or

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FGPN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FMI FGPN

  • Page 1: Installation Instructions

    UNVENTED (VENT-FREE) UNIVERSAL FIREBOX INSTALLATION INSTRUCTIONS D1115 Model FGPN 36” Peninsula Heat-Circulating Firebox WARNING: Improper installation, WARNING: If the information in this manual is adjustment, alteration, service not followed exactly, a fire or explosion may result maintenance can cause injury or property causing a property damage, personal injury or damage.
  • Page 2: Safety Information

    4,500 feet could cause pilot added items can cause sooting. outage. 5. You must operate this fireplace with 16. Do not use the firebox if it has been the provided fireplace screens, hoods and under the water due to shock hazard...
  • Page 3: Specifications

    OWNER’S MANUAL PRODUCT PRODUCT FEATURES SPECIFICATIONS OPERATION This firebox is designed for use with approved ANS Z21.11.2 decorative type unvented multi-sided room heaters. (Physical size limitations apply. Refer to minimum firebox requirements supplied with log heater.) The maximum size log this firebox will accept is: width of 32”, depth of 19”...
  • Page 4: Locating Firebox

    UNVENTED (VENT-FREE) FIREBOX AIR FOR COMBUSTION However, in buildings of unusually tight LOCATING FIREBOX construction, must provide AND VENTILATION Planning additional fresh air. WARNING: This firebox shall Unusually tight construction is defined Plan where you will install the firebox. not be installed in a confined space as construction where: This will save time and money later or unusually tight construction...
  • Page 5 OWNER MANUAL AIR FOR COMBUSTION AND VENTILATION Continued DETERMINING FRESH-AIR FLOW FOR FIREBOX LOCATION Determining if You Have a Confined or Unconfined Location Use this work sheet to determine if you have a confined or unconfined space. Space: Includes the room in which you will install firebox plus any adjoining rooms with odorless passageways or ventilation grills between the rooms.
  • Page 6: Ventilation Air From Inside

    UNVENTED (VENT-FREE) FIREBOX AIR FOR COMBUSTION AND VENTILATION Continued VENTILATION AIR Ventilation Air From Inside Building This fresh air would come from an adjoining unconfined space. When ventilating to an adjoining unconfined space, you must provide two permanent openings: one within 12” of the ceiling and one within 12”...
  • Page 7: Installation Clearances

    OWNER’S MANUAL INSTALLATION directly against wall framing D. Clearances from the bottom of the materials. firebox to the floor is 0 inches. E. Clearances from the open end of the NOTE: This firebox in combination dimensions shown rough firebox to the facing wall should not be with unvented log sets are intended openings to create the easiest installation less than 36 inches.
  • Page 8 UNVENTED (VENT-FREE) FIREBOX material other that wood flooring, the INSTALLATION vent-free firebox must be installed upon Continued a metal or wood panel extending the full width and the depth of the vent-free Mantel Clearances for firebox. Projected Built-In Installation If placing custom mantel above built-in firebox, you must meet the minimum allowable clearance between mantelshelf and top of the firebox hood shown in...
  • Page 9 OWNER’S MANUAL INSTALLATION Continued 3. If a raised platform is to be constructed, ceiling clearances must be maintained. 4. Install gas piping to firebox location. See Installing Gas Line on page 9 and Connecting to Gas Supply in log set owners manual.
  • Page 10: Installing Gas Line

    UNVENTED (VENT-FREE) FIREBOX INSTALLATION A manual shut-off valve, AGA certified A 36” long ½” NPT SCHD 40 flexible and complying with the National Fuel gas connector line complying with the Gas code, ANSZ223.1-lastest edition, National Fuel Gas code ANS Z223.1- Continued must be included within (6’) six feet of lastest edition, may run from the...
  • Page 11: Electrical Installation

    This blower is designed to be be tested for leaks after the connect vent-free heater installed on the wall side of the FGPN before pressure testing gas installation completed. firebox, when provisions for a 120 VAC supply connection are made at the end of...
  • Page 12: Optional Blower

    5. Apply gentle force between hook the louvers on each side of the fireplace NOTE: Periodically check the louvers and loop mounting strips to seat blower.
  • Page 13 INSTRUCTIONS fireplace openings on all three sides for away to avoid burns or the safe operation of the unit as shown in Figure 19. When lit for the first time, a vent free log clothing ignition.
  • Page 14: Replacement Parts

    Manufacturer’s Part Department warranty. 1-800-343-3473 for referral information. If so, contact Fireplace Manufacturer Incorporated at 1-888-542-7832. PARTS UNDER WARRANTY When calling Fireplace Manufacturer, have ready Contact authorized dealers of this • Model number of your firebox product.
  • Page 15 (#02347) FGAL17 (For End) FGA6017 (For End) (#02242) An optional blower is available for use (#02240) with the FGPN fireboxe for heat FGAL41 (For Side) FGA6054 (For Sides) (#02241) (#02239) circulation and may be be installed Replaces the starndard black louvers to Replaces the standard black hoods to during or after firebox installation.
  • Page 16: Illustrated Parts Breakdown

    UNVENTED (VENT-FREE) FIREBOX ILLUSTRATED PARTS BREAKDOWN Model FGPN...
  • Page 17: Parts List

    OWNER’S MANUAL PARTS LIST This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 13 of this manual. Model FGPN PART NUMBER DESCRIPTION QTY. FGPN 26767 Firebox Assembly 26750...
  • Page 18 GAS APPLIANCE LIMITED ONE YEAR WARRANTY THE WARRANTY Fireplace manufacturers, Inc. (hereafter referred to as FMI), warrants the FMI Gas Appliance to be free from defects in materials and workmanship at the time of manufacture. REMEDY AND EXCLUSIONS The coverage of this Warranty is limited to all components of the gas appliance manufactured by FMI.

Table of Contents
