Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This book has important information for the use and safe operation of this machine.Read and understand all warnings before you start working. WARNING WHEN USING THIS MACHINE, BASIC PRECAUTIONS SHOULD BE FOLLOWED. Read all the instructions before using the machine. To reduce risk of injury, close supervision is necessary when the machine is used near children. -
Page 3: Product View
OUTLET INLET CHEM • CONTROL DEVICES Before connecting the machine to the water and electrical supplies, it is necessary to know the function of the controls on the machine. This must be done in accordance with the descriptions in the Instruction Manual, taking reference to the relevant instructions and illustrations. - Page 4 STANDARD EQUIPMENT EQUIPEMENT STANDARD ON/OFF switch Interrupteur Marche/Arrêt Pressure adjusting knob Bouton de régulation de la pression Pressure indicator Indicateur de pression Oil level indicator Indicateur de niveau d’huile High pressure hose connection (OUTLET) Raccord de tuyau haute pression (OUTLET) Inlet hose connection with water filter (INLET) Raccord d’alimentation eau et filtre (INLET) Outer chemical port...
-
Page 5: Table Of Contents
ENGLISH TABLE OF CONTENTS Technical specifications of the TSX series high pressure cleaner... pag. 13 Product use....................pag. 14 2.1 • Designated use................. pag. 14 Preliminary operations................pag. 14 3.1 • Unpacking..................pag. 14 3.2 • Identification label..............pag. 15 Installation.................... -
Page 6: Technical Specifications Of The Tsx Series High Pressure Cleaner
1 - HYDRO PRESSURE CLEANER TECHNICAL CHARACTERISTICS SERIES TSX 15.150 17.130 10.130 12.100 12.140 14.120 13.180 MODEL SINGLE SINGLE TRIPLE TRIPLE TRIPLE TRIPLE TRIPLE SINGLE SINGLE TRIPLE SINGLE TRIPLE PHASE PHASE PHASE PHASE PHASE PHASE PHASE PHASE PHASE PHASE PHASE PHASE l/min. -
Page 7: Product Use
CAREFULLY READ BEFORE PROCEEDING WITH INSTALLATION, START-UP AND USE. This booklet contains important safety information and instructions for use and maintenance of the high pressure cleaners series TSX and should be kept in a safe place. 2. PRODUCT USE 2.1 DESIGNATED USE... -
Page 8: Identification Label
3.2 - IDENTIFICATION LABEL Before using the machine, make sure that it is provided with the identification Label. In case the Identification Label is missing, do not use the machine and consult your dealer immediately. The Identification Label with the technical specifications is fixed to the motor. -
Page 9: Connection High Pressure Outlet
3- Since the water flow decreases according to the length of the hose, make sure that the quan- tity of water supplied to the machine is not less than the quantities indicated in the chart below. 4- The pressure of the inlet water must not exceed 10 bar. FLOW RATE OF TSX SERIES WATER SUPPLY MODEL L/min. -
Page 10: Connection To Electric System
5 - Insert the plug only after checking that the machine switch is in the OFF position. The TSX cleaners series are supplied without electric plug. The assembly of the electrical plug must be done in conformity with IEC rule n. 60634 and must... -
Page 11: General Warnings
3 - Open the gun with nozzle end up and keep in open position to allow air to escape from the hose. 4 - Regulate water pressure by rotating the regulator knob. ATTENTION: in the cleaners high pressure with “TOTAL STOP” device, the motor stops approximately 20 seconds after the gun is closed. - Page 12 • Wear protective goggles and rubber slip- proof boots • Avoid dispersing substances that are pollut- ing, toxic or harmful in any way. This machine has been built in conformity with current safety regulations. Use of electric appliances requires the observations of a few simple rules: Do not touch electric parts when the machine is on.
- Page 13 Do not start the unit if the high pressure hose, connectors and the gun are damaged. By replacement make sure that the new components have at least the same rating as the original components.The technical specifications of the hose should be printed on the hose itself (max pressure, production date, manufacturer).
-
Page 14: Chemical Product Use
6 - HOW TO USE CHEMICAL PRODUCTS The TSX series high pressure cleaners have been constructed to permit the suction and mix- ing of detergents and other liquids from the internal tank. 6.1 - SUCTION FROM INTERNAL TANK Fill the tank, as shown in Fig. 1. Select the low pressure by operating the Rototek or Multireg 99 (Fig. -
Page 15: Use Of "Rototek" Or "Multireg 99
7 - USE OF ROTOTEK OR MULTIREG 99 Pressure selection must be carried out with closed pistol (1) A - selection of the pressure B - selection of the jet • High pressure (2) • straight pin jet (4) • Low pressure (3) •... -
Page 16: Inlet Filter
9.2 - INLET FILTER Before using the machine it is IMPORTANT to make sure that the filter is clean. Wash the fil- ter under running water and/or with an air pressure gun to totally eliminate any deposits in the filter. Remember that a clean filter guarantees the good of the machine operation. -
Page 17: Trouble Shooting
11 - TROUBLE SHOOTING (FOR QUALIFIED PERSONNEL) CAUSE REMEDY TROUBLE The pump is running but Air suction Check suction hose and fittings maximum pressure is Worn or dirty valves Clean or substitute not obtained Unloader packings worn Check and/or substitute Nozzle worn or incorrect Check and/or substitute Piston packings worn... -
Page 18: Declaration Of Conformity
DECLARATION OF CONFORMITY The manufacturer INTERPUMP GROUP S.p.A. - Via E. Fermi, 25 - 42040 S. ILARIO D’ENZA (RE) - Italy DECLARES that the machine identified and described below: Type of machine: High Pressure Cleaner Factory mark: INTERPUMP GROUP Model:...
