PLED-W600/PLED-W800
LED Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://www.
viewsonic.com in English, or in specific languages using the Regional selection box in the
upper right corner of our website. "Antes de operar su equipo lea cu idadosamente las
instrucciones en este manual"
Model No. VS15897/VS15898
Advertisement
Table of Contents
Related Manuals for ViewSonic PLED-W600
Summary of Contents for ViewSonic PLED-W600
-
Page 1: User Guide
Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www. viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website. - Page 2 Thank you for choosing ViewSonic With over 25 years as a world leading provider of visual solutions, ViewSonic is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic product you have chosen will serve you well.
-
Page 3: Compliance Information
Compliance Information FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/ EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum...
-
Page 5: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this unit near water. 6. Clean with a soft, dry cloth. 7. Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s instructions. -
Page 6: Copyright Information
PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 7: Product Registration
ViewSonic’s website to register your product online. The ViewSonic CD also provides an opportunity for you to print the product registration form. Upon completion, please mail or fax to a respective ViewSonic office. To find your registration form, use the directory “:\CD\Registration”. -
Page 8: Table Of Contents
Table of Contents Viewing System Settings ...... 24 Introduction USB Display ......... 25 Package Overview ......... 7 Wi-Fi Display ........26 Product Overview ........8 Configure Wireless Connection Remote Control ........9 (via AP mode) ........27 Installation Configure Wireless Connection (via Client mode) ........ -
Page 9: Introduction
Copyright © 2011, ViewSonic Corporation. All rights reserved. All trademarks, registered or otherwise, are the property of their respective companies. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial reeors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this meterial, or the performance or use of this product. -
Page 10: Product Overview
AUDIO AV IN HDMI/MHL AUDIO SERVICE HDMI/MHL COMPUTER PLED-W800 PLED-W600 1. Kensington Lock 12. A/V Input Connector 2. Focus Dial 13. SD Card Slot 3. Left Button / Audio - ( ) 14. HDMI/MHL Connector 4. Power Button ( ) 15. -
Page 11: Remote Control
Remote Control 1. Power 2. My Button HDMI* Computer* Media/USB* 6. Auto Sync* Source* 8. Up / Keystone 9. Enter 10. Left 11. Right 12. Down / Keystone 13. Menu 14. Pattern 15. Exit Rewind* Previous* Next* 19. Fast Forward* Pause* Play* Stop*... -
Page 12: Installation
Installation Power On/Off 1. Connect the power cord to the DC input jack of the projector. 2. Inset the plug at the end of the power cord into a power outlet. The status LED lights red in standby mode. 3. Press the Power button ( ) to turn the projector on or off. -
Page 13: Adjust The Projected Image
Adjust the Projected Image SCREEN SIZE PROJECTION DISTANCE 16:10 Screen (inch) (meter) (inch) (meter) 0.61 28.5 0.72 0.81 38.0 0.96 1.02 47.5 1.21 1.22 57.0 1.45 1.42 66.5 1.69 1.63 76.0 1.93 1.83 85.5 2.17 2.03 95.0 2.41 2.54 118.7 3.02 Adjust the focus until the image is clear. -
Page 14: Connect Input Source - Hdmi/Mhl Or Computer
Connect Input Source - HDMI/MHL or COMPUTER HDMI/MHL Connection Connect to Notebook/Computer Connect to Mobile Devices COMPUTER Connection (PLED-W800 only) Connect to Notebook/Computer 1. Connect the COMPUTER / HDMI device using an appropriate cable. 2. After powering on the projector, press the SOURCE button on the control panel or the HDMI/COMP. -
Page 15: Connect Input Source - Composite Av In (Pled-W800 Only)
Connect Input Source - Composite AV IN (PLED-W800 only) *AV cable is an For video and optional accessory audio input Connect to DVD player Connect to iPod Touch 5 1. Connect the AV input source. 2. After powering on the projector, press the SOURCE button on the control panel to select the appropriate input source. -
Page 16: Insert Usb Flash Drive (Pled-W800 Only)
Insert USB Flash Drive (PLED-W800 only) Plug a USB flash drive into the USB connector at the back of projector. Supports USB flash drive with FAT32 and NTFS formats. Mount the Projector Screw a standard tripod into the screw hole on the projector. Screw hole for tripod *Standard Tripod The tripod is an optional accessory. -
Page 17: Using Multimedia Menu (Pled-W800 Only)
Using Multimedia Menu (PLED-W800 only) How to Use the Multimedia Menu Remote Control Home menu Up Button Enter Button Right Button Left Button Down Button Press to select the menu item that you want to Menu Button Exit Button access and press Enter/ to enter the menu screen. -
Page 18: Internal Memory
Multi-Media submenu Photo menu Video menu Audio menu Document menu Internal Memory Internal Memory is a form of computer data storage. File Transfer File Transfer can transfer your computer's data to the projector's internal memory by using a single USB cable (A type to A type). Your computer will detect the projector's "Internal Memory"... -
Page 19: Viewing Photos
Viewing Photos To view photos from the USB flash drive or SD card, do the following: Select Data Source Enter Home Menu Change data source COLOR COLOR MENU/ MENU/ EXIT EXIT AUDIO AUDIO COLOR MENU/ EXIT AUDIO Select [Photo] COLOR MENU/ EXIT AUDIO... -
Page 20: Photo Settings
Full Screen Display If the slide show function is enabled, photos are played continuously at specified intervals. The button guide disappears when the keypad is not used for 3 seconds. To display the button guide, press any key. To change the slideshow settings, ... -
Page 21: Playing Videos
Playing Videos To play videos from the USB flash drive or SD card, do the following: Select Data Source Enter Home Menu Change data source COLOR COLOR MENU/ MENU/ EXIT EXIT AUDIO AUDIO COLOR MENU/ EXIT AUDIO Select [Video] COLOR MENU/ EXIT AUDIO... -
Page 22: Video Settings
Video Playback Mode The button guide disappears when the keypad is not used for 3 seconds. To display the button guide, press any key. During video playback, press on the remote control or on the control panel to adjust the ... -
Page 23: Playing Music
Playing Music To play music from the USB flash drive or SD card, do the following: Select Data Source Enter Home Menu Change data source COLOR COLOR MENU/ MENU/ EXIT EXIT AUDIO AUDIO COLOR MENU/ EXIT AUDIO Select [Audio] COLOR MENU/ EXIT AUDIO... -
Page 24: Music Settings
Music Playback Mode During music playback, press on the remote control or on the control panel to adjust the volume. Press Exit to return music file list. Play Stop Pause Fast forward Rewind Next audio file Previous audio file Repeat Music Settings Enter Home Menu Select [Audio] COLOR... -
Page 25: Viewing Documents
Viewing Documents To view documents from the USB flash drive or SD card, do the following: Select Data Source Enter Home Menu Change data source COLOR COLOR MENU/ MENU/ EXIT EXIT AUDIO AUDIO COLOR MENU/ EXIT AUDIO Select [Document] COLOR MENU/ EXIT AUDIO... -
Page 26: Viewing System Settings
View Mode The button guide disappears when the keypad is not used for 3 seconds. To display the button guide, press any key. Use t/u to navigate between the button options. Press Enter to select the menu item. ... -
Page 27: Usb Display
USB Display To project your computer screen, do the following: Enter Home Menu When using USB Display function for the first time, install the software and execute: For Windows OS: vPresenter_USB_Win.exe. For Macintosh OS: vPresenter_USB_Mac-And-Driver-Installer. Extend display is not available on Windows 8/8.1. ... -
Page 28: Wi-Fi Display
Wi-Fi Display When using Wi-Fi Display function for the first time, download and install the vPresenter application into your mobile device. Download and install vPresenter application from Play Store, APP Store, or PLED-W800 server. Extend display is not available on Windows 8/8.1. ... -
Page 29: Configure Wireless Connection (Via Ap Mode)
Configure Wireless Connection (via AP mode) To access the SmartDisplay on your device via AP mode connection, do the following: Plug in the Wi-Fi Dongle Enter Home Menu (Wi-Fi dongle is an optional accessory) COLOR MENU/ EXIT AUDIO Select [WiFi] Select [AP Mode] Select [Settings] COLOR... -
Page 30: Configure Wireless Connection (Via Client Mode)
Configure Wireless Connection (via Client mode) To access the SmartDisplay on your device via Client mode connection, do the following: Plug in the Wi-Fi Dongle Enter Home Menu (Wi-Fi dongle is an optional accessory) COLOR MENU/ EXIT AUDIO Select [WiFi] Select [Client Mode] Select [Settings] COLOR... -
Page 31: Media Streaming
Media Streaming When using media streaming function for the first time, download and install the BubbleUPnP (Play Store) or iMediaShare (App Store) application into your mobile device. Plug in the Wi-Fi Dongle Enter Home Menu Select [Smart Display] COLOR MENU/ EXIT AUDIO COLOR... -
Page 32: Screen Mirroring
Screen Mirroring With Screen Mirroring function, you can mirror the compatible mobile device screen onto the projected screen wirelessly. This function only works with compatible mobile devices that support Miracast, Media Output, or Screen Mirroring options. The configuration on the connection procedures vary depending on the mobile device UI design. ... -
Page 33: Adjust Menu Settings For External Input Source
Adjust Menu Settings for External Input Source Selecting Input Source Once a video source device is connected and turned on, press Source on the remote control or SOURCE on the control panel to automatically switch the input source. Available sources are in the following order: 1. - Page 34 Menu Items (PLED-W800) DISPLAY menu PICTURE menu SETTING menu OPTIONS menu Menu Items (PLED-W600) DISPLAY menu PICTURE menu SETTING menu OPTIONS menu...
-
Page 35: Using The Main Menu
Using the Main Menu Refer to the below table for details on menu items. Some of the menu options are not available on PLED-W600 projector. Menu Menu option Description Select the aspect ratio of the display. Aspect Ratio Available options: AUTO / 4:3 / 16:9 / 16:10 Enable overscan display (only for HDMI input signal). - Page 36 Menu Menu option Description Select the projector position. Projector Available options: Front Table / Rear Table / Front Ceiling / Rear Position Ceiling Set the display position of the OSD menu. Menu Position Available options: Center / Top-Left / Top-Right / Bottom-Left / Bottom- Right Automatically adjust the trapezoidal (keystone) distortion of the Auto...
-
Page 37: Appendix
Appendix Media File Support List (PLED-W800 only) Image Image Format Profile Color Space Size Limitation YUV400 8000*6000 YUV420 8000*6000 Baseline YUV422 8000*6000 YUV440 8000*6000 YUV444 8000*6000 JPEG YUV400 YUV420 Width <= 8000 & Progressive YUV422 Height <= 6000 YUV440 YUV444 No Limit No Limit 8000*6000... - Page 38 Video File Profile/Level Extensions Audio/Video Codec Explanation Support Up to 1080P 30fps MJPEG 80Mbps Up to High Profile, Support less than 6 Levels 1- 4.1 reference frames H.264/AVC (1080P 30fps Level Prefixparameter 25Mbps) of CAVLCshould<=15 Not supported scan Up to Advance Simple type: profile interlaced...
- Page 39 File Profile/Level Extensions Audio/Video Codec Explanation Support Not Support AC3-HD AAC-LC and HE-AAC MPEG-1 Layer I, II Audio MPEG-1 Layer III (mp3) Not Support DTS-HD LPCM Main profile, Low and Main Levels MPEG1 D-picture not support (1080P 30fps 30Mbps) Video Main profile, Low and Main Levels MPEG2...
- Page 40 Subtitle Format Font Subtitle Size Standard SRT UTF-8 / UTF-16 8bits up to 800*600 SSA/ASS DO NOT support mixed code in subtitle files. Picsel Office Viewer Pages/Lines Size File Format Support Version Comment Limitation Limitation PDF 1.0 PDF 1.1 Up to 1000 pages PDF 1.2 Up to 75MB...
- Page 41 Storage Storage Device type File system File&Dir Level TLC/MLC/SLC Support Max 999 8/12/24/40/60 bit ECC Internal Memory directories and Max FAT16, FAT32 NAND 9,999 Files NTFS, ExFAT USB Flash,USB-HardDisk Support atmost 10th level directory DHC,SDXC SD Card...
-
Page 42: Specifications
Specifications Model Name PLED-W600 PLED-W800 ® Projection system Resolution WXGA (1280 x 800) IBM PC and compatibles, Apple Macintosh, iMac and VESA Computer compatibility standards: SXGA, XGA, SVGA, VGA, WXGA NTSC (3.58/4.43), PAL (B/D/ G/H/I/M/N), SECAM (B/D/G/ Video compatibility K/K1/L), HDTV (480i, 576i,... -
Page 43: Troubleshooting
Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local retailer or service center. Image Problems P No image appears on-screen • Ensure the power cord is correctly and securely connected. •... -
Page 44: Customer Support
Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Mexico) la/soporte/servicio-tecnico Nexus Hightech Solutions, Cincinnati #40 Desp. 1 Col. De los Deportes Mexico D.F. Tel: 55) 6547-6454 55)6547-6484 Other places please refer to http://www.viewsonic.com/la/soporte/servicio-tecnico#mexico Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Peru) la/soporte/servicio-tecnico Macau www.hk.viewsonic.com T= 853 2870 0303 service@hk.viewsonic.com... -
Page 45: Limited Warranty
ViewSonic warrants its products to be free from defects in material and workmanship, under normal use, during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. - Page 46 Exclusion of damages: ViewSonic's liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: Damage to other property caused by any defects in the product, damages based upon...
-
Page 47: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &... - Page 48 Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com Tijuana: FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 14035 Pipeline Ave. Chino, CA 91710, USA Col 20 de Noviembre Tel: 800-688-6688 (English); 866-323-8056 (Spanish); Tijuana, Mexico E-Mail: http://www.viewsonic.com...
