Summary of Contents for Eurocave INOA
- Page 1 Operating instructions - INOA cellar conditioners...
- Page 2 ANGEMENT TORAGE YSTEMS EGALSYSTEME ISTEMAS DE OLOCACIÓN Modulothèque Modulocube Modulorack ERVICE DU IN AU ERRE LIMATISEURS DE YSTEM TO SERVE WINES BY THE GLASS ELLAR ONDITIONERS FFENAUSSCHANKSYSTEM EINKELLERKLIMAGERÄTE ISPENSADOR DE VINO POR COPA LIMATIZADORES PARA ODEGA Inoa* Vin au Verre*...
- Page 3 Natural aeration: A constant supply of air from the outside is also indispensable. All of these specific features can be found in the EuroCave INOA conditioner you have bought. We thank you for the confidence you have placed in us.
-
Page 4: Table Of Contents
ONTENTS 1 • C p. 5 ONDITIONER DESCRIPTION 2 • I p. 6 MPORTANT SAFETY RECOMMENDATIONS 3 • E p. 6 LECTRICAL POWER SUPPLY 4 • C p. 6 ARE FOR THE ENVIRONMENT AND ENERGY SAVING 5 • I p. 7 NSTALLING YOUR CONDITIONER 6 •... -
Page 5: Conditioner Description
1 - C ONDITIONER DESCRIPTION COLD AIR HOT AIR Evaporator, to be cleaned regularly Distance between ceiling / conditioner: 200 mm min. 10 - Condenser, to be cleaned regularly Ceiling 11 - Inside of cellar Cellar wall 12 - Remote control Metal mounting frame 13 - Grid securing screws (quantity: 24) -
Page 6: Mportant Safety Recommendations
You should therefore never dispose of electrical or electronic equipment with unsorted municipal waste. When buying a new EuroCave product (wine cabinet, cellar conditioner,Vin au Verre), you can take advice about the recycling of your old appliance from your EuroCave dealer. -
Page 7: Installing Your Conditioner
- When your appliance is delivered, ensure, after unpacking, that your conditioner shows no apparent damage to exterior appearance (impacts, buckling, etc.). - In the event of a problem, contact your EuroCave dealer. - Important: insulation of your cellar is crucial for your conditioner to perform at its best.The quality of your insulation will determine the stability of the programmed temperature. -
Page 8: Onditioner Operation
- The air outlets (hot and cold) must not be obstructed by any obstacle (minimum distance: door conditioner 1500 mm). Direct the cold air outlet so it is facing the bottles (see diagram D). The installation (wall drilling and fitting) of your conditioner must be carried out by a EuroCave CELLAR approved fitter. bottles... -
Page 9: Commissioning Your Conditioner
7 - C OMMISSIONING YOUR CONDITIONER I- Connection Check that the plug is connected to a power supply (presence of correct amp fuses, functioning 30 mA* differential circuit breaker - not applicable to certain countries).Wait 48 hours before plugging in your conditioner. II- Switching on - Place the switch, located under the conditioner, in position 1. -
Page 10: Iv- Installing The Remote Control
It is also possible to place the remote control outside the cellar. In this case, an external sensor (supplied) must be connected to the remote control and then the remote control must be reprogrammed. For further details, contact your EuroCave retailer. V- Setting the temperature... -
Page 11: Vi- Silent Function
VII- Heating function The EuroCave INOA conditioner has a heater (650 W) allowing the internal temperature in your cellar to be maintained at an optimal level. As soon as the temperature drops below the programmed temperature, the heating function is automatically activated. -
Page 12: Veryday Maintenance
Electrical Heating Refrigerant External in mm supply volume m capacity W power W resistance W temperatures Inoa 25 W385 x D322 230 V up to 600 W** 43 Kg 550 W** 650 W R134a -5°C to 35°C x H1250 / 50 Hz... - Page 13 The information in this document is subject to modification without prior notice. EuroCave offers no guarantee on this equipment item if it is used for any specific purpose other than that for which it was designed. EuroCave cannot be held responsible for any errors in this manual, nor for any damage linked to or following the provision, performance or use of the equipment item.
- Page 14 - info@eurocave.com...
