Wenger 1-Column Owner's Manual

Media storage systems mobile media cabinets
Hide thumbs

Advertisement

Quick Links

Download this manual
Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Component Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Hardware Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Weight Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Digital Lock Accessory Note . . . . . . . . . . . . . . . . . . . . . . . . . .4
Visit the Media Storage Cabinet web page at www.wengercorp.com.
Note: Please read and understand these instructions before starting the installation.
Note: Examine the illustrations on the following pages. If you need additional information,
contact Wenger Corporation using the information below.
©Wenger Corporation 2014
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 1-800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Media Storage Systems
1-Column
Mobile Media
Storage Cabinet
Printed in USA 08/14
Mobile Media Cabinets
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Template for Mounting Power Strip . . . . . . . . . . . . . . . . . . . . .10
Owner's Manual
2-Column
Mobile Media
Storage Cabinet
Part #258A997-02

Advertisement

loading

Summary of Contents for Wenger 1-Column

  • Page 1: Table Of Contents

    Note: Examine the illustrations on the following pages. If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2014 Printed in USA 08/14 Part #258A997-02 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: 1-800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com...

  • Page 2: Important User Information

    Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual.

  • Page 3: Component Identification

    Component Identification Structural Components Work Full Width Surface Slide-Out Rear Access Shelf Door Cord Wrap Wire Clamp Fixed Adjustable Shelf Shelf 4” (10 cm) Drawer Rackmount File Drawer Cable Pass Through Accessories Small Plastic Bin Medium Plastic Bin Medium Divided Plastic Bin Accessory Accessory Accessory...

  • Page 4: Hardware Parts List

    Hardware Parts List X003599 X003632 Shelf Clip Cage Nut X003600 Wire Clamp X000482 #8 x 5/8 Sheet Metal Screw *Quantities may vary, extras can be discarded. Weight Limits These structural components are rated at the maximum load capacities. · 4” (10 cm) Drawer - 40 lbs (18 kg). · File Drawer - 65 lbs (29 kg).

  • Page 5: Installation

    Installation IMPORTANT: The following procedures are shown using the 2-Column Mobile Media Cabinet, the procedures for the 1-Column Mobile Media Cabinet are similar unless indicated otherwise. Position the Adjustable Shelves 1. Remove any screws that held the Adjustable Shelves in place during shipping.
  • Page 6 Installation (continued) Position the Adjustable Shelves (continued) 4. Fitting the grooves in the Shelves over the Rails, tilt the Shelves into position to rest on the Shelf Clips. Groove in Shelf Clip Shelf...

  • Page 7: Operation

    Screws and Clips to secure them into place. d. Reinstall the Drawer or the Shelf and Stop Bracket. Only 1-Column Slide-Out Shelf can be repositioned. The 2-Column Slide-Out Shelf is shown below only to reference the Stop Bracket location. Stop...
  • Page 8 Operation (continued) Rackmount Electronics 1. Electronic components can be accessed by tipping out the Rackmount. 2. Additional electronic components can be added but must be done so according to their manufacturer’s specifications. Place deeper components at the bottom of the Rackmount. 3.
  • Page 9 Operation (continued) Cable Management Cable Pass Throughs are located at the top and sides to route cables through the Cabinet. Notches in the Shelves and Dividers allow cables to be routed at the back of the Cabinet. Wire Clamps assist in routing cables throughout the Cabinet. The Clamps can be repositioned or more can be added as needed.

  • Page 10: Template For Mounting Power Strip

    Template for Mounting Power Strip The Power Strip Accessory may be placed at any location in the Cabinet. Secure the Power Strip mounting holes using two #8 x 5/8 Sheet Metal Screws and the template on the following page.
  • Page 11 IMPORTANT: Be sure that this page is printed at 100% actual size before using template.
  • Page 12 This page is intentionally blank.

This manual is also suitable for:
