PEL TOR
PROFESSIONAL SERIES
UHF TWO-WAY RADIO HEADSET.
EXCLUSIVE ALL-IN-ONE
COMMUNICATION
NO MORE WIRES OR
EXPENSIVE BELT RADIOS
CHECK OUT
THESE ADVANTAGES: ADVANTAGES:
• Compatible with existing in plant UHF 2-way radio systems
• Custom programmable to user specifications
• Earcup microphones pick-up warning signals and
prevent "wearer isolation"
• Removable and rechargeable battery pack included
or uses 2 "AA" batteries
• Noise canceling boom microphone
• Programmable hands-free voice activated PTT
• Attenuation test data conform to OSHA requirements
MUST BE PROGRAMMED. Some frequencies require
•
FCC or Industry Canada license.
Stop complicating communications. Simplify them
with the PowerCom Plus II Radio Headset from Peltor.
For more information on the smarter way in two-way
visit www.powercomplusoffer.com, call 1-800-225-9038 or
e-mail peltor_communications@aearo.com
POWERCOM PLUS
™
®
CSA
Model NRR Class:
MT53H7A4720
25 dB B
Headband model
MT53H7B4720
25 dB A
Neckband model
MT53H7P3E4720
24 dB A
Hardhat mount model
FL6CS Cell phone cable, 2.5 mm mini stereo plug
FL6CT Receive only patch cord for entertainment devices, 3.5mm stereo plug
TK56 Remote ring finger Push-to-talk button, 48" straight cable (shown below)
M995 Boom microphone wind sock
FL5503 Remote lapel PTT, 12" straight cable
MT90-01 Throat microphone
II
OCTAVE BAND ATTENUATION DATA (dB) - ANSI S3.19 TEST DATA
Freq 125 250 500 1000 2000 3150 4000 6300 8000
Mean 18.6 23.6 31.8 36.6 31.2 36.4 39.5 38.3 39.0
sd 4.3 3.1 2.8 2.2 2.4 3.6 2.7 3.6
Mean 19.1 22.3 31.7 34.7 33.5 37.9 40.8 38.8 40.4
sd 2.6 2.3 2.7 2.4 2.9 2.5 3.1 2.5
Mean 18.1 21.7 31.5 35.5 30.7 36.8 39.7 38.6 39.0
sd 3.1 2.9 2.8 2.7 2.7 2.7 2.5 2.1
ACCESSORIES
SPECIFICATIONS
GENERAL SPECIFICATIONS
Channel Capacity
Weight (Without Batteries)
Battery life LOW power @ 5/5/90 duty cycle
using 2 standard high capacity AA batteries
Battery life HI power @ 5/5/90 duty cycle
using 2 standard high capacity AA batteries
FCC description
IC description
Approvals/ratings
TRANSMITTER SPECIFICATION
Frequency range
Channel Spacing
Coded Squelch Settings
Channel raster
Freq stability
Power
Modulation Limiting 12.5 kHz
Modulation Limiting 25 kHz
FM Hum & Noise 12.5 kHz
FM Hum & Noise 25 kHz
Radiated emissions <1 GHz
Radiated emissions, 1-4 GHz
Adjacent channel power, 12.5 kHz
Adjacent channel power, 25 kHz
Audio response 300-3000 Hz
Audio Distortion
FM Modulation
RECEIVER SPECIFICATION
Frequency range
Channel Spacing
Coded Squelch Settings
Channel raster
Freq stability
Sensitivity (12 dB SINAD)
Intermodulation
Adjacent channel selectivity 12.5 kHz
Adjacent channel selectivity 25 kHz
Spurious rejection
2.6
Rated audio
Audio distortion
2.9
Hum and noise 12.5 kHz
Hum and noise 25 kHz
2.8
Radiated spurious emission <1 GHz
Radiated spurious emission 1-4 GHz
INTR
INSICALLY SAFE APPROVALS
**Factory Mutual (FM) Class I Groups C & D; Class II, Groups, E, F & G; Class III,
Canadian Standards Association (CSA) Class I Groups A, B, C & D; Class II, Group G; Class II
UHF
30 Channels
14 oz/400 g
36 hours
30 hours
To Be Determined
To Be Determined
Intrinsically Safe **
UHF
430-470 MHz
12.5/25 kHz
83 Digital, 38 analogue
6.25/12.5/25 kHz
+/- 2ppm
10 mW/20 mW/200 mW
+/- 2.5 kHz
+/- 5 kHz
-34 dB
-40 dB
< 0.25 uW
< 1 uW
-60 dBc
-70 dBc
+/- 2 dB
3%
16K0F3E, 8K50F3E
UHF
430-470 MHz
12.5/25 kHz
83 Digital, 38 analogue
6.25/12.5/25 kHz
+/- 1ppm
-122 dBm typical
70 dB
60 dB
70 dB
70 dB
10 mW
3%
-35 dB
-35 dB
< 2 nW
< 20 nW
