Summary of Contents for AMC SUB2
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using this electronic device, basic precautions should always be taken, including the following: 1. Read all instructions before using the product. 2. Do not use this product near water (e.g., near a bathtub, washbowl, kitchen sink, in a wet basement or near a swimming pool etc). -
Page 3: Table Of Contents
CONTENTS: Before you start What's in the box Features Hints on installation Controls and connections Rear panel Connectors Cable wiring examples Specifications Specifications... -
Page 4: What's In The Box
SUB 2 - active subwoofers for public address and home installations. Black coloured body with front mounted 10” speaker. 200 W power amplifier, 20 Hz - 130 Hz frequency range. Low pass filter, volume and phase control, ground lift switch. Built-in limiter. Line level stereo inputs. Simple device’s connecting to the sound system. -
Page 5: Rear Panel
Rear Panel 1. VOLUME CONTROL 8. LINE LEVEL XLR OUTPUT This knob is designed for the The audio signal in this balanced volume level adjusting. Please pay XLR output is linked from internal attention: The lowest input sensitivity crossover’s high pass section, so level which can be set is -30dB. -
Page 6: Connectors
Connectors TR connector TRS connector XLR male connector XLR female connector RCA connector Cable wiring examples Cable to balanced input from balanced output. TRS connectors. - Page 7 Cable to unbalanced input from balanced output. TRS and TS connectors. Cable to balanced input from unbalanced output. TS and TRS connectors. Cable to unbalanced input from unbalanced output. TS connectors. Cable to balanced input from balanced output. XLR connectors. Cable to unbalanced input from balanced output.
- Page 8 Cable to balanced input from balanced output. TRS and XLR connectors. RCA cable. Cable to unbalanced input from RCA output. RCA and TS connectors. Cable to balanced input from RCA output. RCA and XLR connectors. Cable to balanced input from RCA output. RCA and TRS connectors. Cable to RCA input from balanced output.
-
Page 9: Specifications
Specifications Power supply AC 230V, 50 Hz Rated power 200 W Frequency response 20 Hz - 130 Hz Low pass filter 50 Hz - 130 Hz Driver dimensions 10" (254 mm) Input gain control - 6 dBu - +3 dBu Input impedance 10 kΩ... - Page 10 NOTES: ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________...
- Page 12 AMC is a registered trademark of AMC Baltic www.amcpro.eu...
