Summary of Contents for AMC SBS 10
- Page 1 User SBS 10 Manual Active Subwoofer With Satellite Outputs...
- Page 2 ON. When the power switch is turned ON, the main power is turned ON.The only operation to disconnect the power supply from the grid, unplug the power cord. USER MANUAL SBS 10 Active subwoofer with satellite outputs...
-
Page 3: Table Of Contents
Table of contents Before you start Introduction ..............................2 Features ................................2 Operation Rear panel................................3 Rear panel functions ...........................4 Specifications General specifications ..........................5 USER MANUAL SBS 10 Active subwoofer with satellite outputs... -
Page 4: Before You Start
Before you start SBS 10 is an active subwoofer with satellite speaker outputs for public address and home audio installations. Separate 160 W subwoofer and 2 x 60 W speaker amplifiers, 20 Hz - 20 kHz frequency response, two band equalizer, low pass filter and volume controls. -
Page 5: Operation
9. 100 V signal input 10. Indicators for subwoofer amplifier 11. Indicators for satellite speakers amplifier 12. Standby power indicator 13. Satellite speaker outputs 14. Power switch 15. Mains power socket and fuse box USER MANUAL SBS 10 Active subwoofer with satellite outputs... -
Page 6: Rear Panel Functions
Power connector for mains power, combined with fuse holder. 100 V SIGNAL INPUT Use only the same type of fuse that is written on the device. Input for 100 V audio signal. USER MANUAL SBS 10 Active subwoofer with satellite outputs... -
Page 7: General Specifications
General Specifications SBS 10 active subwoofer with satellite speaker outputs Hi level input gain +42 dBu Power supply AC 230 V, 50 Hz Full power: 320 W Power (subwoofer) 160 W Power consumption Idle: 26 W Power (satellite speakers) 2 x 60 W Standby: 0.7 W...
