- Page 1 Operation / Installation Manual Microwave Oven RO-M3411-ST Rinnai Corporation...
- Page 2 TABLE OF CONTENTS English Page 1 - 16...
-
Page 3: Table Of Contents
Troubleshoot ------------------------------------------------------------------------------------------------------------- ----------------14 Installation ----------------------------------------------------------------------------------------------------- ---------------------------15 IMPORTANT Please paste the serial number labels enclosed with the packaging on your warranty card to register your product warranty. Please contact your local Rinnai Customer Care Centre should you require further assistance. Version: 2013 03... -
Page 4: Safety Warnings
SAFETY WARNINGS Please read this user manual thoroughly before attempting to use appliance for the first time. This manual contains important information on safe installation, use and care of the appliance. Do keep these instructions for reference and pass them on to future user. Unpacking ... - Page 5 Technical safety Before setting up the appliance, check it for Installation and repair should only be attempted external visible damage. Do not install or by qualified technician. attempt to use a damaged appliance. It is dangerous to modify any part of this ...
- Page 6 Canned foods Do not cook or heat up food and Remove food from sealed liquids in sealed containers/cans containers/cans. Transfer as pressure can build up and they suitable utensil/dish. may explode posing a severe risk of injury. ...
- Page 7 Suitable cooking utensils for microwave ovens To cook or defrost food in a microwave oven, the microwave energy must be able to pass through the cooking utensils to penetrate the food. The material and shape of containers affect cooking results and durations. Heat distribution is more even in round/oval shaped containers than in square/oblong containers as the food in the corners tend to overcook.
-
Page 8: Appliance Specifications
APPLIANCE SPECIFICATIONS 220V – 240V / 50Hz Voltage and frequency of power supply Fuse Power consumption (Microwave) 1400W Power consumption (Grill) 1250W Power consumption (Convection) 2050W Microwave Power output 900W Operation Frequency 2450MHz Appliance dimension 595(W) x 527(D) x 460(H) mm Cut-out dimension 560 (W) x 505(D) x 455(H) mm Volume... -
Page 9: Guide To The Appliance
GUIDE TO THE APPLIANCE Fixing the turntable ① Door safety lock ② Oven window ③ Turntable support / roller ring Turntable ④ Turntable ⑤ Grilling rack Turntable support / roller ring ⑥ Universal pan ⑦ Control panel Turntable shaft 1. Place the turntable support on the cavity bottom. Accessories provided: 2. -
Page 10: Microwave Functions
MICROWAVE FUNCTIONS Microwave solo mode Suitable for defrosting, reheating and cooking. Grill mode Suitable for grilling thin cuts of meat. Convection mode Heated air is circulated throughout the oven cavity to brown and crisp food evenly and quickly. Combination mode (Microwave & Grill) Suitable for browning dishes with toppings. -
Page 11: Operation
OPERATION Note : Each time cooking programme ends, the oven produces a beep signal sound and ‘End’ is Press PAUSE/CANCEL key to stop programme displayed on the screen. The signal continues to during operation. sound every two minutes. Clear the display setting before starting a new Open the oven door or press PAUSE/CANCEL key programme. - Page 12 Combination mode (Microwave and Grill) Rotate TIME selector to set the cooking time (30:00 is displayed in the window) This program uses a combination of grill and microwave power. The maximum cooking time is 95 Press START/QUICK START key to start minutes.
- Page 13 Combination mode (Microwave + Convection) Menu Cooking mode This oven has three pre-programmed settings Potato (230g/each) Microwave making it easy to cook automatically with both Coffee (200ml/cup) Microwave convection heat and microwave. Popcorn (99g) Microwave Suppose you want to set cooking for 25 minutes on ℃...
- Page 14 Multi-stage Cooking Your oven can be programmed up to 3 stages. Speed Defrost Suppose you want to set the following cooking Speed defrost can defrost food according to the time program. you entered. The maximum time is 95 minutes. Microwave cooking (100%) Grill cooking ...
-
Page 15: Maintenance And Care
Do not attempt to replace the oven light by a non- dull the door surface. qualified person. Please contact your local Rinnai To loosen stubborn deposits, boil a cup of water Customer Care Service for service. -
Page 16: Troubleshoot
Check that the main switch is turned on and the plug is properly inserted in the electrical outlet. If the problem persists despite observing the above checks, please contact your local Rinnai Check if the circuit breaker is in working order. -
Page 17: Installation
If there is any damage, do not operate the appliance. Please contact your local Rinnai Customer Service for assistance. Fit the appliance in appropriate cabinet This appliance is designed to be built into a column unit. ... - Page 18 Securing the appliance Connecting the supply cable to the power mains Install a standardized plug corresponding to the Fit the appliance into column unit until the front load indicated on the rating label attached to the frame of the oven is aligned to the cupboard appliance.
- Page 19 Tel 电话 : (86) 20 3821 7976 Email 邮箱 : grrjdq@gzrinnai.com.cn URL 网址 : www.gzrinnai.com.cn Indonesia Singapore Customer Care of PT. Rinnai Indonesia Rinnai Holdings (Pacific) Pte Ltd Jl. Raya Pejuangan No.21, 47 Tannery Lane #05-01/02, Komp. Ruko Sastra Graha No.11 -13...
