PARTS LIST 16/20 SP
Key Part No. Qty
1 16200 1
2 16201 1
3 16202 1
4 16203 1
5 16209 2
6 16205 1
7 16207 1
8 16208 1
9 16353 1
10 16211 2
11 16212 1
12 16213 1
13 16215 1
72646 1
14 16216 1
15 16217 1
16 16219 1
17 16220 1
18 16221 1
19 16222 1
20 16223 1
21 16224 1
22 16225 1
23 16226 1
24 16227 1
25 16228 2
26 16229 2
27 16230 1
28 16231 1
29 16232 1
30 16233 1
31 16234 1
32 16235 1
33 16236 1
34 16237 1
35 16238 3
36 16239 1
37 16240 1
38 16241 1
39 16242 1
40 16243 1
41 16244 1
42 16245 1
43 16246 1
44 16247 1
45 16249 1
46 16250 1
47 16251 2
48 16252 1
49 16253 1
16365 1
50 16354 1
51 16255 1
52 16256 1
53 16257 1
54 16258 1
55 16356 1
56 16260 6
57 16261 6
58 16262 12
59 16263 6
60 16265 3
61 16264 3
62 16266 1
63 16267 1
64 16268 1
65 16269 1
66 16270 2
67 16271 1
68 16272 1
69 16273 2
70 16275 1
71 16276 1
72 16281 1
73 16284 2
74 16285 3
Description
Main Frame. 1620
Taper Bushing, 1.18
Cutting Wheel Pulley
Idler, Main Drive
Main drive Belt, Single
Electric Clutch, 1.437
Clutch Bracket
Idler Pulley, 3"
Frame Control Handle
J-Bolt, Battery Hold Down
Red, Positive Cable
Black, Negative Cable
Tach/Hour Meter thru S/N
Tach/Hour Meter S/N 61497/up
Gas Cap
Gas Tank, Includes Cap
Adjustment Tool
Inner Belt Guard
Curtain Mount, Left
Curtain, Left
Curtain Mount, Rear
Curtain, Rear
Rt. Curtain Mnt, Long
Rt. Curtain Mnt, Short
Right Curtain
Rear Side Curt. Mount
Rear Side Curtain
Outer Rear Belt Guard
Outer Front belt Guard
Battery Hold Down (2)
Gas Tank Strap
Info Tube thru S/N 61496 on y l
Tube Strap thru S/N 61496 only
Male Fuel Coupling
Female Fuel Coupling
Spring, Kill Switch
Dump Valve Handle
Presence Handle
Clutch Switch
Brake Handle
Brake Cable
Kill Switch
Shut Off Rod
Spring, Handle Lock
Transmission Gasket
Forward/Reverse Cable
Hydro Control Arm
Pillow Block Bearing
Cable Support
Clutch Stabilizer
Clutch Stabilizer (1624 only)
Idler Arm
Belt Tensioner Bracket
Cutter Shaft
Hydro Brake Bracket
Shut Off Rod
Cutter Wheel
Threaded Tooth Pocket
Counter Bore Tooth Pocket
Pocket Bolt
Straight Tooth
Left Hand Tooth
Right Hand Tooth
1 ½" Muffler Clamp
Eaton Hydro Transmission
Peerless Transaxle
12 Tooth Gear
Wheel Hub
Wheel Assembly, RH
Wheel Assembly, LH
Snap Ring
Pulley, 3" x 1.437 Bore
Pulley, 3" x 17MM Bore
Hydro Valve Control Lever
Woodruff Key, Axle
Woodruff Key, Transmission
16
Key Part No. Qty Description
75 16286 1 Dump Valve Knob
76 16287 2 Presence Handle Spacer
77 16288 1 Info Tube Pad thru S/N 61496 only
78 16289 2 Info Tube End Caps thru S/N 61496 only
79 16291 1 3/8" Clutch Bushing
80 16292 1 LH Wheel Spacer, Short
81 16293 1 RH Wheel Spacer, Long
82 16294 1 Adj. Pin Handle Grip
83 16295 2 Tension Adj. Spacers
84 16296 1 Transmission Gear Spacer
85 16297 1 Retaining Ring, M17
86 16298 1 Pin, Handle Lock
87 16299 1 Idler Spacer
88 18105 1 Belt, AX-35
89 18123 1 Battery
90 20118 1 Engine, 20HP Kohler (1620 SP)
16336 1 Engine, 24HP Honda (1624 SP)
72673 1 Engine 31HP Briggs Van. (1631 SP)
91 20119 1 Muffler Kit, 20HP Kohller (1620 SP)
16337 1 Muffler Kit, 24HP Honda (1624 SP)
16359 1 Muffler w/Shield 31HP Va. (1631 SP)
92 28801 2 1" x 4" Clevis Pin
93 28839 2 Fuel Line Clamp
94 5001002 8 ½" Lug Nuts
95 5001225 8 ½" Wheel Hub Stud
96 16310 1 Fuel Line, 48"
97 16313 2 Wire Stop
98 16314 1 Ball Joint
99 16316 1 Handle Fold-Up Link
100 16318 1 Shield, Right Curtain
101 16320 1 Main Idler Bushing
102 16325 1 1/8" Clutch Bushing
103 16326 1 Guard Lock Tab
104 72522 1 Clutch Retainer
105 72523 1 Retainer Bolt
106 16338 1 Cover Plate S/N 61497/up only
107 16339 1 Manual Pack S/N 61497/up only
108 16355 1 Axle curtain, RH
109 16357 1 Wheel Slot Cover
110 5000408 1 ½-12 x 1" Shoulder Bolt
111 5000406 1 ½-12 x ¾ Shoulder Bolt
16290 Complete Decal Set
16290A Decal, Clutch Switch
16290B Decal, Transmission Valve
16290C Decal, Caution Stumps Only
16290D Decal, Warning Don't Move
16290E Decal, Belt Tension
16290F Decal, Danger Cutter Wheel
799021 Brake Pad
162171 Float Assembly, 3&6 gal. tank
162172 Pick-Up Assembly, 3&6 gal.tank
Optional Accessories
120 16300 Counter Bore Mnt.,Std Angle
121 16301 Counter Bore Mnt., Straight
123 16303 Tooth, Deep Dish, Hard Carbide
124 16304 Threaded Mnt., Std. Angle
125 16305 Threaded Mnt., Straight
127 16327 Transport Wheel Assembly
128 16327A Caster Tube, Transport Wheel
129 45060A Caster Yoke
130 68050 Pneumatic Wheel
131 45061 Nylon Washer
132 16218 Clevis Pin, 3/8" s 2 ¼"
133 7500802 ¾" Flat Washer
134 16328 Gauge Wheel Assembly
135 16328A Mount Arm, Gauge Wheel
136 16328B Adjustment arm, Gauge Wheel
137 16328C Wheel Spacer, Gauge Wheel
138 32104 Wheel
139 85226 Bent Pin
140 500126 Bolt, ½" -13 x 3 ¼"
141 16352A Mirror Mount Arm
142 16352B Mirror, Convex
143 16352 Sight Mirror Assembly
