ASPEN Digital Processor
Important
Safety Instructions
This symbol, wherever it appears, alerts
you to the presence of uninsulated
dangerous voltage inside the enclosure
-- voltage that may be sufficient to
constitute a risk of shock.
This symbol, wherever it appears, alerts
you to important operating and mainte-
nance instructions in the accompanying
literature. Please read the manual.
FCC Part 15 Compliance
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired op-
eration.
CAUTION: Changes or modifications not expressly
approved by Lectrosonics, Inc. could void the user's
authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence when the equipment is operated in a commercial
environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at this
own expense.
2

Table of Contents

Overview ................................................................................. 3
What is Dante? .................................................................... 3
About the DNT Processors .................................................. 3
Switched and Redundant Modes ......................................... 3
DNT16i Front Panel ................................................................ 4
DNT16i Rear Panel ................................................................. 4
DNT0212 Front Panel ............................................................. 5
DNT0212 Rear Panel .............................................................. 5
DNT Control Panel Software ................................................. 6
DNT Software Installation ..................................................... 6
About Dante Software ........................................................... 7
Dante Software
TM
Installation ...................................................................... 7
Mandatory Settings ............................................................... 8
Dante Controller Software - Network Settings ..................... 8
DNT Control Panel Software - Signal Flow Configuration .... 9
DNT Software - USB Connection ......................................... 9
DNT Software - Ethernet Connection .................................. 9
Hardware Connections ....................................................... 10
Installing the chassis into a rack ........................................ 10
Connecting via USB for the First Time ............................... 10
Setup and Control Port Connections ................................. 10
Programmable Inputs ......................................................... 11
RS-232 Serial Port Wiring .................................................. 11
Crestron RS-232 Port Wiring ............................................ 11
®
Programmable Outputs ...................................................... 11
Network and PC Connections ............................................ 12
Signal Routing ..................................................................... 13
Replacement Parts and Accessories ................................. 14
Service and Repair .............................................................. 15
Returning Units for Repair ................................................. 15
LECTROSONICS, INC.
