User's Manual
Backup Parking Sensor System
4 Rear In-Bumper Type Sensors
Wireless LED Display with Built-in Audible Alert
For Cars, VANs, SUVs, and Trucks
MODEL 4015N
ISO9001
http://parkingsensors.net
HY Technologies Milpitas California USA
All Rights Reserved
Advertisement
Related Manuals for HY Technologies 4015N
Summary of Contents for HY Technologies 4015N
- Page 1 User’s Manual Backup Parking Sensor System 4 Rear In-Bumper Type Sensors Wireless LED Display with Built-in Audible Alert For Cars, VANs, SUVs, and Trucks MODEL 4015N ISO9001 http://parkingsensors.net HY Technologies Milpitas California USA All Rights Reserved...
- Page 2 Backup Parking Sensor System 4 Rear In-Bumper Type Sensors Wireless LED Display with Built-in Audible Alert For Cars, VANs, SUVs, and Trucks Included in the Box 4x Sensors with attached cable and 2-pin 1x Wireless LED Display with attached mini plug. Cable Length: 2.5m (8.2ft) power cable (2.0m or 6.5ft) and cigarette lighter type plug, double-sided 4x Wedge-Shaped Plastic Sensor...
- Page 3 How the System Works The Backup Parking Sensor System determines obstacle distance by measuring the time needed for the ultrasonic wave emitted by a sensor to reach an obstacle and for the sensor to receive the ultrasonic wave reflected from the obstacle. Given the speed of the ultrasonic wave, the system can then calculate and display the distance between the sensor and the obstacle.
- Page 4 Installation and Wiring IMPORTANT: (a) Read this manual thoroughly before proceeding to installation. You can also have the system installed by a professional installer such as your local auto mechanic/auto electrician/car stereo store. (b) Turn off the engine and ACC during installation. (c) Double check that all wiring is correct before powering on the system.
- Page 5 3. Wiring Power to the Wireless LED Display There are two methods for powering the wireless LED display: a) Method [1]: The wireless display comes with attached power cable and a cigarette lighter type plug. Simply Insert the plug into the cigarette lighter jack.(Fig. 4). b) Method [2]*: If you want to route and hide the power cable of the display, you may cut off the cigarette lighter type plug from the power cable, and wire the cable directly to ACC or "ON"...
- Page 6 Installing Sensors in Metal Bumpers If you have a continuous beeping or false alert problem after installation of the system, unplug all sensors from the control box, and then plug back in one sensor at a time and test to find out which specific sensor(s) is causing the problem.
-
Page 7: Troubleshooting
Detection Range of the System The parking sensor system detects obstacle by emitting ultrasonic wave and receiving reflected ultrasonic wave from an obstacle. Different materials have different reflection and absorption of the ultrasonic wave, and the actual detection distance varies depending on what materials an obstacle is composed of. - Page 8 For more installation related questions and Frequently Asked Questions (FAQs) with http://parkingsensors.net answers, and product photos, visit our Web site at Terms & Conditions, Return Policy, and Warranty IMPORTANT: the parking sensor systems and parts sold and distributed by us are only devices used to assist a driver while parking.
- Page 9 Shipping and Handling fee is not refundable. Returns are not acceptable if the packaging is not in its original condition or the item has been used or installed. International orders are not returnable. If a domestic or international shipment is refused by the customer or customs and returned back to us, a 15% restocking fee will apply less the shipping cost and any other fees incurred if any to the customer.
- Page 10 Customer Service and Technical Support For customer service and technical support, visit our Web site as listed below, then click on the link Contact Us. http://parkingsensors.net HY Technologies Milpitas California USA All Rights Reserved - 9 -...
- Page 11 Spare and Replacement Parts To order spare and replacement parts for your system, visit our Web site as listed below, then click on the link Spare and Replacement Parts. http://parkingsensors.net HY Technologies Milpitas California USA All Rights Reserved - 10 -...
- Page 12 The specifications and features of the system, Terms & Conditions, Return Policy, and Warranty included in this User's Manual are subject to change without prior notice. http://parkingsensors.net HY Technologies Milpitas California USA All Rights Reserved Made In China - 11 -...
