User's Manual
Backup Parking Sensor System
Wireless Digital Display with Built-in Audible Alert
4 Rear Heavy-Duty Under-Bumper Type Sensors
Waterproof Main Control Box
For Buses, RV's, Commercial Trucks, and Long Vehicles
MODEL C-2682-04
CE ISO9001
HY Technologies
http://parkingsensors.net http://parking-sensors.hyt.com
Copyright 8 2006
HY Technologies Milpitas California USA
All Rights Reserved
Advertisement
Table of Contents
Related Manuals for HY Technologies C-2682-04
Summary of Contents for HY Technologies C-2682-04
- Page 1 Wireless Digital Display with Built-in Audible Alert 4 Rear Heavy-Duty Under-Bumper Type Sensors Waterproof Main Control Box For Buses, RV's, Commercial Trucks, and Long Vehicles MODEL C-2682-04 CE ISO9001 HY Technologies http://parkingsensors.net http://parking-sensors.hyt.com Copyright 8 2006 HY Technologies Milpitas California USA All Rights Reserved...
- Page 2 Backup Parking Sensor System Wireless Digital Display with Built-in Audible Alert For Buses, RV's, Commercial Trucks, and Long Vehicles MODEL C-2682-04 Included in the Box 4x Black Sensors with bracket, attached cable 1x Power Cable for Wireless Digital Distance and BNC type connector. Cable Length: 26ft (8m) Display with 3-pin mini plug.
- Page 3 How the System Works The Backup Parking Sensor System determines obstacle distance by measuring the time needed for the ultrasonic wave emitted by a sensor to reach an obstacle and for the sensor to receive the ultrasonic wave reflected from the obstacle. Given the speed of the ultrasonic wave, the system can then calculate and display the distance between the sensor and the obstacle.
- Page 4 Installation and Wiring IMPORTANT: (a) Read this manual thoroughly before proceeding to installation. You can also have the system installed by a professional installer such as your local auto mechanic/auto electrician/car stereo store. (b) Turn off the engine and ACC during installation. (c) Double check that the wiring is correct before power on the system. (d) During installation, avoid flatting, perforating, cutting, and extending the wires of sensors to reduce unnecessary signal loss.
- Page 5 bracket. Use a 1/8” drill bit to drill the holes at the marks. c) Secure the sensor brackets underneath the bumper with the screws included. d) Run the sensor wires to the main control box. Do not cut the sensors wires. Attach sensor wires to the vehicle body with cable/wire ties so that they will not get in the way of any moving parts and there are no loose wires hanging down.
- Page 6 needs to be reset as follow: Power on the main control box. Make sure no other main control boxes are working nearby. Power on the display, press the wireless ID code setting button on the bottom of the display with a small flat head screw driver until you hear one beep followed by two beeps indicating the display is set successfully.
- Page 7 IMPORTANT The Parking Sensor Systems sold and distributed by HY Technologies are only a device used to assist a driver while parking. They should not be considered as a substitute for driver responsibility when operating a vehicle. No warranty as to operational efficiency is granted. We don't guarantee or assume liability for collisions or damages that take place when parking your vehicle with the use of the Parking Sensor System.
