User's Manual
Front and Rear Parking Sensor System
4 Front and 4 Rear In-Bumper Sensors
Wired Digital Distance Display with Built-in Audible Alert
For Cars, Mini-VANs, SUVs, and Small Trucks
MODEL B-2661-08
CE ISO9001
HY Technologies
http://parkingsensors.net http://parking-sensors.hyt.com
Copyright 8 2006
HY Technologies Milpitas California USA
All Rights Reserved
Advertisement
Table of Contents
Related Manuals for HY Technologies B-2661-08
Summary of Contents for HY Technologies B-2661-08
- Page 1 4 Front and 4 Rear In-Bumper Sensors Wired Digital Distance Display with Built-in Audible Alert For Cars, Mini-VANs, SUVs, and Small Trucks MODEL B-2661-08 CE ISO9001 HY Technologies http://parkingsensors.net http://parking-sensors.hyt.com Copyright 8 2006 HY Technologies Milpitas California USA All Rights Reserved...
- Page 2 4 Front and 4 Rear In-Bumper Sensors Wired Digital Distance Display with Built-in Audible Alert For Cars, Mini-VANs, SUVs, and Small Trucks MODEL B-2661-08 Included in the Box 8x Sensors (in-bumper type) with attached 1x Power Supply Wire for Main Control Box - red cable and 2-pin mini connector.
- Page 3 How the System Works The Parking Sensor System determines obstacle distance by measuring the time needed for the ultrasonic wave emitted by a sensor to reach an obstacle and for the sensor to receive the ultrasonic wave reflected from the obstacle.
- Page 4 Installation and Wiring IMPORTANT: (a) Read this manual thoroughly before proceeding to installation. You can also have the system installed by a professional installer such as your local auto mechanic/auto electrician/car stereo store. (b) Turn off the engine and ACC during installation. (c) Double check that all wiring is correct before power on the system. (d) During installation, avoid flatting, perforating, cutting, and extending the wires of sensors to reduce unnecessary signal loss.
- Page 5 b) Work under the front and rear bumpers to check the internal structure of them before marking the positions for drilling holes. If the view is blocked, you may need to remove the bumpers. c) With chalk or marker, mark the position of sensors on the bumpers. Make sure that the sensors can be pushed all the way in and that you can feed the wires through.
- Page 6 Warning To avoid collision with obstacle because of the inertia of vehicle while backing up/parking, keep your vehicle speed at about 3 miles per hour and stop the vehicle immediately once you hear the continuous beeping. This is because even if you have applied brake, your vehicle will still go for some distance (inertia) before it comes to a complete stop.
- Page 7 IMPORTANT The Parking Sensor Systems sold and distributed by HY Technologies are only a device used to assist a driver while parking. They should not be considered as a substitute for driver responsibility when operating a vehicle. No warranty as to operational efficiency is granted. We don't guarantee or assume liability for collisions or damages that take place when parking your vehicle with the use of the Parking Sensor System.
