Louroe Electronics VERIFACT A Installation And Operating Instructions

6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
techsupport@louroe.com / www.louroe.com
DESCRIPTION
The Model Verifact™ A is an omni-directional, low
impedance, electret condenser microphone with built-in
preamp. It can pick up normal sounds approximately
15 ft. away, or within a 30 ft. diameter circle. Verifact™
A produces line level output (0 dB @ 1000W
be located up to 1,000' from the Louroe base station. It
is primarily designed for ceiling mounting but can also
be installed on any type of flat surface. The Verifact™
A is compatible with all Louroe Audio Base Stations or
Louroe Audio Interface Adapters.
NOTE:
Verifact™ A Microphone is NOT recommended
for outdoor use or in areas with high moisture
content.
SPECIFICATIONS
Sensitivity
(microphone & preamp)
Frequency response
Output
Current drain
Supply voltage
Microphone housing
Dimensions
Weight
®
INSTALLATION AND OPERATING INSTRUCTIONS
80 dB SPL input
provides 0.254V rms
40 Hz to 15 kHz ± 1 dB
Line Level (0 dB @ 1000Ω
4 mA
12 Vdc
High impact ABS
US 4" dia x 1 ½ H "
metric
(10cm dia x 3.8cm H)
0.5 Lb (0.2 Kg)
VERIFACT™ A
AUDIO MONITORING SYSTEM
) and can
)
PAGE 1 OF 4
VERIFACT™
A
Microphone
WIRING REQUIREMENTS
2 Conductor shielded cable, 22
gauge with a 24 gauge drain
wire.
NOTE: Unshielded cable is not
satisfactory for audio
systems.
Microphone
Element
Housing and
pre-amp
A_mic-inst_4/11
