Louroe Electronics VERIFACT E-AGC LE-575 Installation And Operating Instructions

6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
techsupport@louroe.com

DESCRIPTION

The Verifact E-AGC is an omni-directional, low
®
impedance, electret condenser microphone with built-in
preamp and automatic gain control. It can pick up
normal sounds approximately 30 ft. away, or within a 60
ft. diameter circle. It's built-in limiter prevents the output
signal to be overdriven thus minimizing distortion.
Verifact E-AGC produces line level output (0 dB) and
®
can be located up to 1,000' from the Louroe base
station. The output gain of the microphone can be adjusted
through a potentiometer up to +10dB. The microphone
preamp is mounted inside a singe gang Bell Box
housing that is designed for outdoor use or in moist
environments. The Verifact E-AGC is compatible with
all Louroe Audio Base Stations or Louroe Audio
Interface Adapters.
Louroe
Microphone
IP67
RATED
Line Level

SPECIFICATIONS

Microphone Sensitivity
Frequency response
Output
Audio AGC Processing
Current drain
Supply voltage
Output gain
Microphone housing
Dimensions
Hardware
Weight
Color
LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship. Should a
defect appear within two years (24 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment. This equipment shall
This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation instructions provided by
Returned shipments to LOUROE ELECTRONICS shall be at customer's expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL: (818) 994-6498 FAX:
®
INSTALLATION AND OPERATING INSTRUCTIONS
/ www.louroe.com
®
Automatic gain control
(AGC) allows Louroe's
microphone preamp to
automatically adjust and
AGC
compensate for variations
AUDIO
in volume from different
audio sounds and
distances relative to the
microphone pickup.
-45dB
50 Hz to 8 kHz
Line Level, Adjustable (0 dB, 1K at 1Khz )
Level slope of between 6 dB and 10 db
10 mA
12 Vdc
+10dB
Standard single gang Bell Box
4 1/2" H x 2 3/4" W x 2 3/16" D
1 lb
Grey
not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .
website: www.louroe.com
VERIFACT E-AGC
Outdoor Line Level (Gain Control) Microphone
Face Plate
®
VERIFACT E-AGC
Bottom View
Microphone
(Included Hardware)
Manufactured

WARRANTY

LOUROE ELECTRONICS.
e-mail: sales@louroe.com
Page 1 OF 4
®
Front View
(LE-575)
1" Hole Plug with IP67 Wiring Gland
Removable Power &
Audio Connector
1" Hole Plug
IMPORTANT NOTICE
When this equipment is used as part of an
audio monitoring system, the law requires
In the
that the public be given notice of AUDIO
MONITORING ON THE PREMISES. A
decal notice is included with each
microphone shipped.
Federal Law References:
Federal Regulations, US Code, Title 18.
Crime and Criminal Procedure, Sec 2510.
(LE-575)
Mounting Tabs and
Screws for
Wall Mounting
AUDIO
MONITORING
On
These Premises
®
(818) 994-6458
