Louroe Electronics VERIFACT B Installation And Operating Instructions

6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
techsupport@louroe.com / www.louroe.com

DESCRIPTION

®
The Model Verifact B is an omni-directional, low
impedance, electret condenser microphone with built-in
preamp. It can pick up normal sounds approximately
15 ft. away, or within a 30 ft. diameter circle. Verifact
B produces line level output (0 dBV @ 600 ) and can
be located up to 1,000' from the Louroe base station.
The Microphone element is suspended from the pre-
amp and dome housing by a 3' extension cable and is
designed for high ceiling applications. The Verifact B
is compatible with all Louroe Audio Base Stations or
Louroe Audio Interface Adapters.
NOTE:
Verifact B Microphone is NOT
recommended for outdoor use or in areas
with high moisture content.

SPECIFICATIONS

Sensitivity
Frequency response
Output
Current drain
Supply voltage
Microphone housing
Dimensions
Weight
Shipping Weight
®
LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.
Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.
This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .
This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation
instructions provided by LOUROE ELECTRONICS.
Returned shipments to LOUROE ELECTRONICS shall be at customer's expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL (818) 994-6498 FAX
®
INSTALLATION AND OPERATING INSTRUCTIONS
®
-45 dBV/Pa
1 Pa = 94 dB SPL
50 Hz to 15 kHz
Line Level (0 dBV, 600
10 mA
12 Vdc
High impact ABS
4" dia x 1 ½ H "
4 oz
1 Lb
®
®
®
website: www.louroe.com
VERIFACT B
MICROPHONES
®
Microphone Extension
Cable for High Ceiling
applications
®
@1kHz)

WARRANTY

®
®
®
e-mail: sales@louroe.com
Page 1 of 4
®

IMPORTANT NOTICE

When this equipment is used as part of an
audio monitoring system, the law requires
that the public be given notice of AUDIO
MONITORING ON THE PREMISES. A
decal notice is included with each
microphone shipped.
AUDIO
MONITORING
On
These Premises
®
Federal Law References:
Federal Regulations, US Code, Title 18.
Crime and Criminal Procedure, Sec 2510.
Microphone
Element
(818) 994-6458
B_mic_inst_11/14
