C o n v e c t i o n O v e n
E l e c t r i c
Model:
ASC-2E
ASC-4E
ASC-2E
Manual
with
Mobile Stand Option 5004687
Control
• INSTALLATION
• OPERATION
• MAINTENANCE
ASC-4E
with
Stand Option 5003489
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 USA
PHONE: 262.251.3800 • 800.558.8744
/
FAX: 262.251.7067 • 800.329.8744
.
.
.
USA
CANADA
U
S
A
ONLY
www.alto-shaam.com
.
.
.
p r i n t e d i n u
s
a
MN-28666 (REV 1) • 06/13
