1" Multi-use Miller Grip Anchorage
Spoons
Cleaning Bushing
Conical End Fitting
Users should be familiar with pertinent regulations governing this equipment.
All individuals who use this product must be correctly instructed on how to use this device.
Miller's 10,000 lb Multi-Use Miller Grip can be used in either concrete or rock substrate.
This product is to used in concrete or rock substrate only.
* Horizontal surfaces
* Vertical surfaces
* Overhead / ceiling surfaces
1. Follow all manufacturer's instructions.
2. Use only locking snap hooks or locking carabineers.
3. Always inspect your units prior to use.
4. Use the proper method of coupling to anchorage.
5. Patch all holes with concrete when job is complete.
6. Pregnant women and minors must not use this product.
7. Designed safe working load is 2,000 lbs ( 8.8 KN ).
All persons using this equipment must read and understand all instructions. Failure to do so may result in serious
injury or death. All persons using this equipment must know the weight or load being applied to this unit.
Operations and Instruction Manual
Trigger
Return Wire
Stop Sleeve
Wire Guide
IMPORTANT!!
DO NOT use in steel, wood or any other substrate.
Miller Grips can be placed in:
WARNING!!
DO NOT use this Product - Model #499 for fall protection.
Use for lifting, hoisting or scaffold tie back only.
Multi-Use Miller Grip Anchorage - Model #499
Portable Anchorage Connector
2,000 lbs / 8.8 KN Safe Working Load
Made in the USA
Swag
Spring
Main Cable
Galvanized Thimble
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Miller 499
Summary of Contents for Miller 499
- Page 1 All individuals who use this product must be correctly instructed on how to use this device. Miller’s 10,000 lb Multi-Use Miller Grip can be used in either concrete or rock substrate. DO NOT use in steel, wood or any other substrate.
- Page 2 The concrete substrate must be at least 20” wide and 10” thick. Inspection: Make sure unit is straight and operates smoothly. It is important that you drill your Miller Grip hole to the Make sure trigger stop is not bent or damaged. manufacturer’s required depth and hole structure. All Make sure cables are not kinked, frayed or damaged.
- Page 3 1 cubic foot of concrete weights approximately ( 140 lbs - 150 lbs ) When placing a Miller Grip, Place your thumb inside the anchor loop and your first two fingers around the trigger. Retract the trigger until the spring bottoms out. With your other hand, pinch the two spoons between your thumb and index finger. IMPORTANT; Make sure the cleaning bushing is not wedged between the two spoons.
