OWNER'S MANUAL
RFCS - RJ45 Foot Control
1.

Safety

2.

Typical Connections

2
3
READ SAFETY BLOCKS in welding power
source Owner's Manual before proceeding.
1
OM-237 679A
2008−02
1
2
3
4
If desired, route cord through strain
relief. Remove screw as shown
from welding power source, and
use screw to secure strain relief.
Plug one end of cord into receptacle
on welding power source. Plug
remaining end into receptacle on
back of foot control.
4
Welding Power Source Foot
Control Receptacle
Strain Relief (Optional
Installation)
Cord
Foot Control
Tools Needed:
Torx T25
805 166-A
