Summary of Contents for Copytrax PrintMaster Monet
- Page 2 Version 1.0 03/10/2011 First Release Version 2.0 18/01/2012 Updated...
- Page 3 Waste electrical products should not be thrown away with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. Copytrax reserve the right to amend or modify the specifications and design criteria applying to these products.
-
Page 4: Table Of Contents
PrintMaster Monet. Contents. Page Unpacking Setup Driver Installation and Printing Preferences Basic Operation Maintenance Daily Weekly Monthly Quarterly Annually Control Panel and Printer Operation Troubleshooting Workflow for Ink Flow Problems Name of Parts Warranty & Support... -
Page 5: Unpacking
PrintMaster Monet. Unpacking. Printer Custom Jig (Type and quantity of jig(s) included will depend on the individual order) Power lead and USB cable Syringe set Control panel and cable Unpacking. Prepare a clean and sturdy desk space to place your printer. Allow enough space for the flatbed to extend fully to the front and rear of the printer. -
Page 6: Setup
PrintMaster Monet. Set Up. Open right hand side door to reveal the ink supply bottles and waste bottle Unscrew lids of supply bottles and fill each with ink. The shoulder of the bottle should be the maximum fill level. The minimum fill level should be... -
Page 7: Driver Installation And Printing Preferences
PrintMaster Monet. Driver Installation and Printing Preferences. Insert the CD-ROM into your computer. It should Autorun if this function is enabled on your system. If it does not Autorun explore the disc and double click ‘autorun.exe’ Select Install Printer Driver... -
Page 8: Basic Operation
When the flatbed is at the rear of the printer and the height is set the PrintMaster Monet is ready for printing from the software of your choosing with the template provided for your custom jig. -
Page 9: Maintenance
PrintMaster Monet. Maintenance. Daily A . Nozzle Check: a. Tape down a piece of blank paper on the flatbed b. Press Backwards button to get the PrintMaster into “Ready to print” mode c. Go to “Start” and open “Printers and Faxes”... -
Page 10: Monthly
PrintMaster Monet. Maintenance. Monthly A . Clean the horizontal encoder strip (seen below) in the front of the printer frame with rubbing alcohol and cotton buds. B . Cleaning vertical e ncoder: a. Located at rear of printer near vertical motor Quarterly (or as needed) A . -
Page 11: Annually
PrintMaster Monet. Maintenance. Annually ( or as needed ) A . Printer Head replacement a. If nozzle check is continuously bad after printer head cleaning & capping station replacement,you may need to replace your printer head: 1. Power off printer 2. -
Page 12: Control Panel And Printer Operation
PrintMaster Monet. Control Panel and Printer Operation. Control panel operation Button “1” Power Button “2” Forward Button “3” Backward Button “4” Head up Button “5” Head down Button “6” Auto height adjust Button “7” Ready to print/ Repeat print Printer Mode Test mode function When unit is switched on, printer will start in Test mode. - Page 13 PrintMaster Monet. Control Panel and Printer Operation. Flatbed moves backward at one touch and stop at second touch Print head moves up away from flatbed Print head moves down towards flatbed Push button for 3 seconds to start a head clean (flatbed must be...
-
Page 14: Troubleshooting
PrintMaster Monet. Troubleshooting. Problem: Nozzle check pattern is not complete. Solutions: Ÿ Are the ink supply bottles correctly positioned on the side of the printer? Ÿ Is the shipping tape removed from the ink bottle lids? Ÿ Are the ink bottle lids open? Ÿ... - Page 15 PrintMaster Monet. Troubleshooting. Problem: How do I perform an ink charge? Solution: Ÿ Using the initial charge function from the SSC Service Utility included on the CD-ROM. Problem: My print has lines in. Solution: Ÿ Perform a head clean. Ÿ...
-
Page 16: Workflow For Ink Flow Problems
PrintMaster Monet. Troubleshooting. Workflow for Ink Flow Problems. Ink flow problems can be confirmed by being unable to print a complete nozzle check pattern. If no solution is found from this workflow please contact your supplier for more assistance. Key:... -
Page 17: Name Of Parts
PrintMaster Monet. Name of Parts. Overall view A. Control panel B. Power connector, USB port & Control panel cable connector C. Flatbed D. Printer cover E. Ink bottles set and waste ink bottles Components << Front view >> < <B a c k s i d e v i e w> >... -
Page 18: Warranty & Support
Warranty & Support. COPYRIGHT © Copytrax Technologies UK Ltd. 2008. All rights reserved. This manual and the software described in it are copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without the written permission of Copytrax Technologies UK Ltd.
