Summary of Contents for Hisense HL55V89PZ

  • Page 1 User’s manual Please read this manual carefully before operating your TV set and retain it for further reference. HL55V89PZ Model Number: Part Number: ES-G102420 Http://www.hisense.com.au...
  • Page 2 HISENSE WARRANTY TERMS AND CONDITIONS 1. HISENSE Australia will provide parts and labour to you the Customer as set b. costs of attendance and testing where no mechanical or electrical out herein. failure is identified; 2. Nothing in the warranty, limits any rights you may have under the trade c.
  • Page 3 12 MONTHS IN HOME REPLACEMENT LCD WARRANTY* Hisense Australia will provide its nearest service centre for repairs or replacement under warranty. You will need to ensure that you have already called Hisense Warranty Centre and have received a JOB NUMBER.
  • Page 4 This page has been left blank intentionally.
  • Page 5: Table Of Contents

    Table of Contents Table of Contents Hisense Declaration................... Important safety precautions..............Safeguards..................Setting Up....................Accessories..................Installing the Stand................. TV Front..................TV Rear..................Rear TV Connectors............... Connection Instructions..............Using the Remote Control................ Installing batteries................The Remote Control Panel............. Quick starts..................Changing the TV Settings.................
  • Page 6: Hisense Declaration

    Hisense reserves the rights to restrict the use or access of certain content or service. As the content and service are transmitted through third party’s network and transmission facilities, Hisense undertakes no customer...
  • Page 7: Important Safety Precautions

    Important safety precautions Safeguards This symbol alerts user about the presence of ATTENTION a dangerous voltage not isolated inside the product which can be sufficiently powerful to RISK OF SHOCK constitute a risk of electrocution. ELECTRIC This symbol alerts user about the presence of Do not open the back cover important operating instructions and In no case the user is allowed to operate inside the TV set.
  • Page 8 Important safety precautions Safeguards Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. A note about safety and operating instructions Read and follow all safety and operating instructions, and retain them safely for future reference. 2.
  • Page 9 Important safety precautions Safeguards 12.Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. Where installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
  • Page 10: Setting Up

    Setting Up Accessories/Installing the Stand Accessories list ALCD101 Batteries Remote Manual Book Installing the Stand pedestal screws 1. Place the TV faced down on a soft cloth or cushion on a table. 2. Attach the stand to the TV set as shown in the picture. 3.
  • Page 11: Tv Front

    Setting Up TV Front TV Front No. Component Component Description Press to turn the main power ON or OFF. POWER Switch Blue indicates standby mode. The light will flicker after POWER Indicator pressing the power standby button,and disappear until the TV is on. You can also control it by yourself. Remote sensor Receives signals from the remote control.
  • Page 12: Tv Rear

    Setting Up TV Rear TV Rear AC INPUT HDMI2 HDMI3 HDMI4 SERVICE HEADPHONE COMP1 AV OUT VIDEO VIDEO S- VIDEO...
  • Page 13: Rear Tv Connectors

    Setting Up Rear TV Connectors Connectors Brief Description Cables ANT 75Ω Connect an outdoor VHF/UHF antenna Yellow Video Connect a composite video cable and left-right audio cables from optical equipment. Video White (Audio connectors are shared with S-Video.) (AV1 AV2) Input Yellow Video...
  • Page 14: Connection Instructions

    Setting Up Connection Instructions ■ Connecting an Aerial (For analogue and Digital signals) To view television channels correctly, a signal must be received by the set from the following source: - An outdoor VHF/UHF antenna ■ Connecting External A/V Devices - Connect a Video RCA or S-VIDEO cable to an appropriate external A/V device such as a VCR, DVD or Camcorder.
  • Page 15 Setting Up Connection Instructions ■ Connecting AUDIO - Connect RCA audio cables to “R -AUDIO - L” on the rear of your set and the other ends to corresponding audio in connectors on the Amplifier or DVD Home Theater. ■ Connecting USB data Devices - Connect a USB device for browsing photos,listening to music, watching movies, reading text files and PVR function.
  • Page 16: Using The Remote Control

    Using the remote Control Installing batteries Installing the remote control batteries 1. Slide open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the “+” and “-” signs on the batteries to the signs on the battery compartment.
  • Page 17: The Remote Control Panel

    Using the Remote Control The Remote Control Panel The Remote Control Panel Buttons instructions(from up to down) (1) Remote sensing Window. (2) Indicator glows from white to orange when buttons are pressed. (3) D/A: Digital /Analog TV. (4) Power Standby: Power button(The red big button). (5) Source: Available source selection.
  • Page 18: Quick Starts

    Using the Remote Control Quick starts ■ Turning your TV on and off To turn your TV on: Connect the TV to an AC power outlet and an external antenna, then turn on the power via switch located below the front right hand side of unit. A few seconds later an image will appear on the screen. Setup wizard-select your state and press OK, Then press OK again to start the Tuning process.
  • Page 19 Using the Remote Control Quick starts ■ Selecting the picture mode ● To select a picture mode: Press the [Picture] button to select between 4 different pre-adjusted picture modes: Bright, Standard, Soft and User (configurable mode). The User mode automatically preserves your personal settings after adjusting brightness, colour and contrast etc.
  • Page 20: Changing The Tv Settings

    Changing the TV Settings Using the Channel Menu ● Press [Menu] to open the main menu. ● Press [▲/▼] to select Channel, then press [►/OK] to enter the Channel menu. ● Press [▲/▼] to select an option. Auto Install DTV Manual Install ●...
  • Page 21 Changing the TV Settings Using the Channel Menu ■ Program Edit After you scan for channels, you can delete a channel from memory if you want to skip the channel when you press [▲/▼]. You can still select the skipped channels using the number buttons. You can also rename the channels, lock or unlock the channels from memory.
  • Page 22: Using The Picture Menu

    Changing the TV Settings Using the Picture Menu ● Press [Menu] to open the main menu. ● Press [▲/▼] to select Picture, then press [►/OK] to enter the Picture menu. ● Press [▲/▼] to select an option. ● Press [◄/►] to adjust the option or press [►/OK] to enter the submenu.
  • Page 23: Using The Sound Menu

    Changing the TV Settings Using the Sound Menu ● Press [Menu] to open the main menu. ● Press [▲/▼] to select Sound, then press [►/OK] to enter the Sound menu. ● Press [▲/▼] to select an option. ● Press [◄/►] to adjust the option or press [►/OK] to enter the submenu.
  • Page 24: Using The Function Menu And Setting The Pvr Hdd

    Changing the TV Settings Using the Function Menu Function ● Press [Menu] to open the main menu. ● Press [▲/▼] to select Function, then press [►/OK] to enter the Function menu. ● Press [▲/▼] to select an option. ● Press [◄/►] to adjust the option or press [►/OK] to enter the submenu.
  • Page 25: Using The Lock Menu

    Changing the TV Settings Using the Lock Menu ● Press [Menu] to open the main menu. ● Press [▲/▼] to select Lock, then press [►/OK] to enter the Lock menu. ● Press [▲/▼] to select an option. ● Press [◄/►] to adjust the option or press [►/OK] to Change Password Block Program enter the submenu.
  • Page 26: Using The Screen Menu

    Changing the TV Settings Using the Screen Menu ● Press [Menu] to open the main menu. ● Press [▲/▼] to select Screen, then press [►/OK] to enter the Screen menu. ● Press [▲/▼] to select an option. ● Press [◄/►] to adjust the option or press [►/OK] to enter the submenu.
  • Page 27: Pc Setting

    Changing the TV Settings PC Setting PC Setting Set the PC Software properly to match one of the below options. Supported VGA Modes: VGA____ (640×480 60Hz) SVGA___ (800×600 60Hz) XGA____ (1024×768 60Hz) SXGA___ (1280×1024 60Hz) Note: Your PC/Notebook may not be able to display some of these resolutions. Take Windows XP as an example, and the Windows system display setting is as illustrated: 1.
  • Page 28: Using The Dmp/Pvr Menu

    Changing the TV Settings Using the DMP/PVR Menu ● Press [Source] to open Source menu. ● Press [▲/▼] to select DMP, then press PHOTO MOVIE MUSIC TEXT [►/OK] to enter the DMP menu.(or press \ DMP~ Up Folder [D/EMP] to enter the DMP menu.) flower.jpg ●...
  • Page 29 NOTEÿ Images, music and video files which were modified and or damaged by computer virus' or corrupted by disk data may affect proper play. Hisense Australia cannot guarantee compatibility (operational and/or bus power) with all USB mass storage devices and assume no responsibility for any loss of data that may occur when...
  • Page 30: Appendix

    Appendix Trouble shooting When there is something wrong with your TV, you can try turning off the TV and then restart it. You can also operate according to the following remedy chart. If the problem still cannot be solved,please contact our service centre. Remedy Symptom 1.
  • Page 31: Specifications

    Weight without base(kg) Wall Mount size: 400mm x 200mm Environmental Temperature 5˚C~35˚C Conditions Humidity : 20%-80%RH Humidity : 20%-80%RH Atmospheric pressure: 86kPa-106kPa Note: Hisense is committed to continued product improvement which may result in changes to specifications and appearance without previous notice.
  • Page 32 HL55V89PZ Http://www.hisense.com.au...
