Page 2
RGB video signal at twice the horizontal scan rate of the original input signal. Functions which apply to the IN1222 / IN1422 but not the IN1510 / IN1710 will be designated in this manual as IN1222 / IN1422 only. The chart below indicates the major differences between the four models.
INPUT COMPATIBILITY The IN1222/1422 and IN1510/1710 will operate with NTSC, PAL, or SECAM input signals in composite video or S-video format. For a complete listing of compatible input video standards see page 20. All video and audio input jacks are shown in the diagrams on pages 3, 6 & 7.
Page 4
RGB inputs and will also operate with many LCD projection panels. The IN1222/IN1422 in non-interlaced (doubling) mode output a signal at twice the original scan rate. RGB monitors, data projectors, and LCD panels capable of displaying a 31.5 KHz VGA signal (640 x 480 mode) can be used to display the decoded/doubled output signal.
INSTALLATION This section offers step-by-step instructions for installing an IN1222/1510 or IN1422/1710. Detailed application drawings showing all equipment connections are included on pages 6 & 7. 1. Connect the video, audio, and RGB input signals to the appropriate input connectors: IN1222/IN1510 S-Video signals may be connected directly to Inputs 1, 2 &...
RACK MOUNTING The IN1222 / IN1510 and IN1422 / IN1710 may be mounted in a standard 19" equipment rack using the appropriate mounting hardware and procedure listed below: IN1222 / IN1510 - Use the IN9083 Rack Ears - 1 U high (optional, not included with units). The IN9083 Rack Mounting kit includes two rack ears and four mounting screws which are slightly longer than the original case screws.
Page 7
IN1222 / IN1510 Application Diagram RGB Projector / Monitor Control System IN9045 IN1222 / IN1510 REPLACE WITH .5A 250V FUSE ONLY R G B H & V O U T R G B H & V I N P U T 4...
Page 8
Multimedia PC w/ VGA & Stereo Audio IN2060 VIDEO OUTPUT ® 2060 DISTRIBUTION AMPLIFIER IN8000 Series VGA Cable INPUT 1 INPUT 2 INPUT 3 LEFT RIGHT LEFT RIGHT LEFT RIGHT VIDEO S-VIDEO VIDEO S-VIDEO VIDEO Video Camera Composite Video IN1422 / IN1710 Application Diagram RGB Projector / Monitor IN7600 or IN7700 Series 4-BNC or 5-BNC Cable...
OPERATION The IN1222 / IN1510 / IN1422 / IN1710 may be controlled by the front panel buttons or through the RS-232 port. All switching functions and most video / audio adjustment functions can be accessed using the front panel. A few adjustments are available only through RS-232 control (see pages 16 - 19).
Page 11
GAMMA Button Gamma correction is an effective tool used to compensate for the non-linear response of most display devices. The gamma setting may also be changed as required to accomodate the wide variation of video gain and contrast characterstics found in various video program sources. INLINE scan doublers and decoders offer eight different gamma curve adjustments (seven active gamma curves plus no gamma).
Page 13
If the input video signal is 50 Hz the output signal will still be 50 Hz. LINE DOUBLING TECHNIQUES The IN1222 and IN1422 will allow users to select and store a different line doubling technique for each input as required by the type of input source. The IN1222 / IN1422 offer three choices: Line Doubling, Frame Mode, and Disable Doubling.
Page 14
Hold Down Button Press GAMMA button for three seconds Press GAMMA button for three seconds Press FREEZE button for three seconds Press FREEZE button for three seconds IN1222 / IN1422 / IN1510 / IN1710 OPERATIONS MANUAL - REV. 2 12/04/99...
POWER ON ADJUSTMENTS The IN1222 / IN1510 / IN1422 / IN1710 utilize "Power On" settings to control two setup parameters. In order to access a Power On adjustment, the user must hold down the indicated button continuously while toggling the unit’s power switch to "ON" (if power is already on, the user can hold down the indicated button and switch the power off and then back on).
RGB PIN OUT INFORMATION The following information applies to the 15-pin HD connectors on the IN1222 / IN1510 / IN1422 / IN1710. The IN1422 / IN1710 also include a set of 5 - BNC Female connectors for RGB input and output.
BAUD RATE SELECTION The IN1222 / IN1510 / IN1422 / IN1710 have a factory default baud rate of 1200 and can communicate at baud rates from 1200 up to 19200. Baud rates can only be changed and saved via RS-232 commands (see page 18).
Selects Gamma Correction curve 3 for the current input channel Controlling Multiple INLINE Products INLINE products such as the Pathfinder, V-Net, the IN1222 / IN1240 / IN1422 doublers and the IN1510 / IN1540 / IN1710 decoders use a similar communications protocol and command code structure.
Page 19
RS-232 ASCII CODES The table below lists the ASCII control codes for the IN1222 / IN1510 / IN1422 / IN1710. These are virtually identical to the codes used with the IN1240 / IN1540, and new codes for the current version are indicated by an asterisk (*).
Shipping Weight ACCESSORIES INCLUDED IN1222 / IN1510 1) - IN1222 Scan Doubler or IN1510 Decoder (1) - IN9045 15-Pin HD Male to 5-BNC Male, 12’ long (5) - IN9090 3.5mm Mini Male to 2-RCA Female (3) - IN9091 4-Pin Mini DIN (S-Video) to RCA Female (1) - IN9038 15-Pin HD Male to Male Gender Changer (1) - Power Cord (U.S.
IN9045 Output Adapter Cable - 15 Pin HD Male to 5 Male BNC Cable - 12’ Long IN9083 Rack Mount Kit - For IN1222 / IN1510, includes (2) Rack Ears and (4) Attachment Screws TROUBLESHOOTING The IN1222/IN1422 Scan Doublers and IN1510/IN1710 Universal Decoders are designed to offer problem free operation.
Inline, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. The technical information contained herein regarding IN1222 / IN1422 / IN1510 / IN1710 features and specifications is subject to change without notice.
