IP Kamera 9070-
CSWO/CSO

User Manual

Release Date: 9/2010
Firmware Version: 1.2.1.4plus
- 1-
Ref#201008109070CSWO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9070-CSWO and is the answer not in the manual?

Questions and answers

Summary of Contents for Aviosys 9070-CSWO

  • Page 1: User Manual

    IP Kamera 9070- CSWO/CSO User Manual Release Date: 9/2010 Firmware Version: 1.2.1.4plus - 1- Ref#201008109070CSWO...
  • Page 2 IMPORTANT NOTICE 1. IP Kamera 9070-CSWO/CSO was designed for indoor use, the manufacturer responsibility for possible damages caused by outdoor use, especially in the rain. 2. Please use the power adapter provided by the dealer, the manufacturer responsibility for the possible damage from using power adapters not.
  • Page 3: Table Of Contents

    SERS ....................18 ETTING UP IRELESS ETTINGS ): ......................18 TEP BY ECOMMENDED : ..........................19 DVANCE ETUP IP S ..........................22 ERVICE 6.) WEB INTERFACE ......................23 9070-CSWO/CSO ..................23 ONNECTING TO THE ........................25 ONSOLE - 3- Ref#201008109070CSWO...
  • Page 4 ..........................26 IDEO ..........................26 YPE AND .......................... 27 OTION ETECTION EPTZ ............................ 27 OUSE ..........................28 CTIVE ECORD ............................28 ECORD ............................28 NAPSHOT ........................... 29 MAGE ..........................29 MAGE ETTINGS ............................. 32 MAGE ..........................33 ETWORK ............................33 ETWORK ...........................
  • Page 5 9.) USING CNT WITH SURF16 CH ................... 61 MAC A ........................61 DDRESS CNT ......................61 DD DEVICE USING 10.) FREQUENTLY ASKED QUESTIONS (F.A.Q) ................ 62 11.) CUSTOMER FEEDBACK ....................63 - 5- Ref#201008109070CSWO...
  • Page 6: Welcome

    IR switching filter, and other functions makes this small device very powerful and unique. Using innovative IP technology, the built in web server of the IP Kamera 9070-CSWO/CSO will allow you to view your IP Kamera from any remote locations around the world while bringing you world class surveillance and ease of mind.
  • Page 7: Minimum System Requirements

    Compatible with all standard 1/3‖ CS lens Electronic Switching Infrared Filter for Night Vision Wireless N 802.11n connectivity (9070-CSWO only) Tri-Mode Camera (MPG4-1/MPEG4-2/M-Jpeg ) Advance Motion detection trigger AVI /Jpeg save on FTP / SD card or Email 3 layers (Admin, Operator, and User) Password protected Resolution from CIF 352x192 up to HD 1280x720P Supports NTP protocol to get correct time schedule.
  • Page 8: Package Contents

    Package Contents 1.) 9070-CSWO/CSO Unit or 9070-CSO 2.) CS Lens Lens Specifications 1.) Format: 1/3‖ 2.) EFFL: 6MM 3.) Image Space F/#: F1.2 4.) Field Angle: 58 degree 5.) Stop: Fixed 6.) Focus Extension: 20cm--∞ 7.) Mount; CS 8.) Outside dimensions: 30 x 31.7...
  • Page 9: Interface Description

    Plug in the RJ45 Ethernet cable to the Ethernet port DC 5V Power Input: Plug in the Power Adapter to the DC 5V The USB is for the wireless Dongle (9070-CSWO only) Note: Only compatible with assigned Wireless Dongle - 9- Ref#201008109070CSWO...
  • Page 10: Hardware Setup

    2.) Make sure the power adaptor is the correct specification. 3.) Make sure that all the cables are working correctly Internet Accessible Setup The internet connection can be setup in two main ways so that the 9070-CSWO/CSO can be accessed through the internet Router / Firewall Setup...
  • Page 11: Static Ip Setup

    Static IP Setup Static IP Address provided by the ISP. In this case, the 9070-CSWO/CSO is being connected to the internet through a hub, which is different from a router. The hub does not provide DHCP, and therefore would require that this setup have a static IP Address that is provided by the ISP.
  • Page 12: Software Setup

    5.) Software Setup The software for the device is located on the Media Link-IP Family CD that came with the device. IP Kamera Pack is located on the main page of the CD. Please follow the directions carefully and install the necessary files Software 1.) First place the Media Link-IP Family CD that came with your device into your CD/DVD Rom drive.
  • Page 13: Installing Vlc Codec

    Installing VLC Codec The files that are recorded by the 9070-CSWO/CSO requires this codec so that you are able to view the view. Download the latest version of the VLC codec and install it into your computer. You can find the latest version of the codec from here http://www.videolan.org/...
  • Page 14: Ip Edit

    IP Edit IP Edit is a search tool designed to setup and access the IP Kamera 9070-CSWO/CSO. IP Service is an additional feature which searches for the device easily without having to remember long complicated IP addresses. Instead, this technology allows the user find his or her device through the internet just by device name.
  • Page 15: Quick Easy Setup (Recommend For Beginner Users)

    Quick Easy Setup (Recommend for Beginner Users) 1.) Click on the REF button, and wait a few seconds. IP Edit will automatically detect the network settings and setup the device. 2.) Once settings have been detected hit the apply button to apply the new settings. 3.) Hit yes to confirm and Enter the login and password for the Device to Approve changes 4.) Then hit the rescan button on IP Edit to confirm the changes have been made.
  • Page 16: Custom Setup (Advance Users)

    Custom Setup (Advance Users) 1.) Highlight the device on the local devices section and on the right side of IP Edit all network information on the device will be displayed. If the device is not on the same network a Red Exclamation mark will appear in the IP Network information section 2.) To setup the device, you will need type in the correct Gateway and IP Address.
  • Page 17 4.) Then hit the rescan button on IP Edit to confirm the changes have been made. - 17- Ref#201008109070CSWO...
  • Page 18: Setting Up Wireless Settings

    Setting up Wireless Settings Step by Step (Recommended): 1.) Next go to the network settings on the bottom and select Wireless. A new window should pop up with the wireless settings 2.) Select the Step by Step option on the wireless screen. 3.) Click on the for more information on how to setup the device.
  • Page 19: Advance Setup

    8.) Unplug the RJ45 cable of the device and search on IP Edit for the new wireless settings. You will see a (W) next to your device in IP Edit which means wireless is activated. If the RJ45 cable is not disconnect you will see two IP Address on the device.
  • Page 20 A new window pop and you will be required to enter the necessary network information including the passphrase or password for the wireless internet. Then hit apply to save all settings. Then go back to the Main Wireless page and click on the on link under Advance for more options. Select the Profile link to see the profiles that you have added to the device.
  • Page 21 Click on your newly added profile and hit the activate button to start up the Wireless settings. Then click on Link Status to make sure that your device is connected to the wireless network. Note: If the device is connected it will show some information in the Link Status page. Now that the device is connected to the wireless network.
  • Page 22: Ip Service

    Then the user can connect to IP Service, type in the device name, and connect directly to the device. Note: IP Kamera 9070-CSWO/CSO requires you to select Server 2 on IP Service 1.) Open IP Edit, the device will show up in the Local Device Section. If you have not selected a name for the device, please refer to the section on the manual labeled: ―Naming your device‖.
  • Page 23: Web Interface

    6.) Web Interface Connecting to the 9070-CSWO/CSO Once the 9070-CSWO/CSO has been setup correctly and access your IP Kamera 9070-CSWO/CSO. An Internet Explorer browser screen pop up with the login screen. Default IP: 192.168.1.168 (When 9070 is connected to PC directly)
  • Page 24 Note: If there is no active X controls that are showing up, please go to internet explorer and enable active X controls. - 24- Ref#201008109070CSWO...
  • Page 25: Web Console

    The IP Kamera 9070-CSWO/CSO Control Console starts in the Section of the webpage. In this section navigate to the other options and settings of the 9070-CSWO/CSO Live Video: The Live Video section allows the user to view the camera, change resolution views, Image: The Image section allows you to edit the image settings, including recording / viewing codec, frame rate, image tuning, brightness, contrast, saturation, and etc.
  • Page 26: Live Video

    Media Player: The Media player can directly access the files in the built in memory. Each video file & picture can be accessed here and streamed through the internet. Logout: After using the 9070, the user can click on the Logout feature to ensure that no one else can see the IP Kamera without a login or password.
  • Page 27: Motion Detection

    2X zoom: This 2X zoom is 2 times the normal view for that type. Scaled 720: Is a resolution only available in MPEG-4-1, which sets the picture at 720P. Screen Size: Will enlarge the image to the whole size of the screen. This function is very useful when trying to display on larger monitors.
  • Page 28: Active Record

    When the active recording function is activated it will light up in red. Record Record: The record button on the 9070-CSWO/CSO when pressed will record the live video feed and save the video into the computer viewing. To record follow the following steps: 1.) Select the recording path that you would like to store the file under in the applications tab...
  • Page 29: Image

    Image The image section allows you to change the Image settings for the device and tune the image of the IP Kamera 9070-CSWO/CSO Image Settings The Image settings section allows you to change the video settings and the Name of the Kamera.
  • Page 30 Camera Name: Select a camera name for the device and then hit submit Video Codec: The Video Codec sections allows you to select different the types of codec you would like to set your IP Kamera, By selecting different resolutions your Resolution: In the resolution section you can select from the following options.
  • Page 31 Rate Control: Select the Bit Rate Control that fits your needs. CVBR: Constrained Variable Bit Rate CBR: Constant Bit Rate Internet Speed: The Internet Speed settings allows you to choose some preset settings to best fit your current internet speeds. From here you can select from the following options: Cable / ADSL: Most high speed internet users today use Cable / ADSL as the main internet provider line.
  • Page 32: Tune Image

    Tune Image The tune image settings section allows you to control and tune the picture quality of the image. Keep in mind, the quality of the picture will also be affected by the quality of the lens that is being used. White Balance: Select from the following options auto, indoor, or outdoor Day and Night: Select the mode Day or Night TV Output: Select the mode enable or disable to output to a T.V...
  • Page 33: Network

    Network The Network settings section allows the user to setup their network information for the IP Kamera. Network The network section allows you to setup the network information for the IP Kamera 9070. Enable DHCP: This function will enable the DHCP for the 9070CSWO. If this is enabled the IP Address of the device will be automatically provided by the router of the device.
  • Page 34: Wireless Settings

    Wireless Settings The wireless settings section will allow you to setup the wireless feature of the 9070-CSWO. Please refer to page 18 or Setting up wireless section for more details. The FTP section of the IP Kamera 9070 allows you to save video clips FTP Server: The FTP server address is where the IP Address of the FTP server will be entered.
  • Page 35: Sntp

    My Server Requires Authentication: Some servers require SMTP Authentication for security purposes. If your email server requires this option, make sure to have this section checked. Account Name: Enter then login of the mail account Password: Enter the password of the E-mail account Use SSL Connect: If the email server requires SSL (Secure Sockets Layer) this option need Sender Email: Enter the Sender Email Address SMTP Server: Enter the SMTP Outgoing mail address...
  • Page 36: Ip Service

    Power and Video Server: This is the server where most IP Power products and IP Video server products can be found. Kamera Server: This is the IP server where most IP Kamera products from Aviosys will be found on. CNT Server: Cross Network Technology Sever. CNT allows user to connect to their IP Kamera without having to Port Forward to the device.
  • Page 37: Rtsp

    Once this section has been made you can come here to verify that Note: This function is for IP Surf Pop software. Please refer to the IP Surf Pop manual for more information at www.Aviosys.com RTSP Real Time Streaming Protocol (RTSP) gives the device another way to stream live video. Using programs that support RTSP, you can broadcast the videos from the 9070 live.
  • Page 38: Date And Time

    Date and Time Set the date and Time of the device here. The Local Time: The local time corresponds to the current time of the IP Kamera 9070. Time Setup: Setup the current time of the device here 1.) Set Manually: Set the time manually 2.) Synchronize with Computer Time: Synchronize the time with the current computers time 3.) Synchronize with SNTP: Synchronize with SNTP Time Stamp...
  • Page 39: User

    User In this section, you can create different user access rights for different types of users. Authority: Select one of the following options: Admin: You can operate all functions in Web interface. Also, you can add or delete any user’s account. Operator: You can operate all functions in Web interface except user Add/Delete.
  • Page 40: Device Tune Up

    Device Tune Up The device tune up resets the 9070 to make sure that the device is running smoothly. This resets the internal memory of the device by restarting the 9070. You can set the Device tune up to reset each hour, day Month, or Week Language Settings The language setting section is where you can select the language that you would like to use to use the...
  • Page 41: Update

    Update The Update Firmware section is where information on the 9070 is displayed. The Kernel Version, Uboot Version, Firmware Version, and other technical information on the device is displayed here. Updating the Device To update the device go to the update section. Here you will find the Current Version description. To update the device: 1.) Browse for the correct update file.
  • Page 42: Event Log

    4.) Please wait for the loading circle to finish, and wait for an update confirmation page. 5.) Once the device is updated you will see a update confirmation and click okay. Warning: Before you go to the next step make sure you have all your setting information written down.
  • Page 43: Application

    Application The Application Section allows you to setup the Video File information, FTP, Memory Management, SMTP Settings Snapshot Path The Snapshot path is the location where the snapshot pictures will be saved onto your computer. The default snapshot path will be set to C:\. To select the snapshot path click on the button and select the folder where the snapshots will be saved.
  • Page 44 Recording Format Select the Video File format that the device will record in. 1.) Avi Format: MPEG4 (720) & MPEG4 (CIF) 2.) Avi Duration: From the drop-down list, select the length of an AVI file, then press submit The FTP section allows you to view your current FTP settings. From here you may have to un-mount the SD memory so that you can record in MPEG4 format.
  • Page 45 Note: 1.) Before you use the FTP function, you will need to set the FTP server information. You can click on the link to take you to the FTP setup section. 2.) If the SD Card is inserted into the device, the 9070 will only be able to record in M-Jpeg mode to the FTP.
  • Page 46 In the settings section, you can find the SMTP information by clicking on the SMTP tab. Here you can see the current SMTP Server information and email address. Storage Settings You can also select the file format in which you would like the IP Kamera 9070-CSWO/CSO to send. Select from MPEG4 or MJPEG. - 46-...
  • Page 47 EZ-Blog Note: To use the Ez Blog functionality, please make sure that your device has been port forwarded so that it can be accessed through the internet. EZ Blog allows you to easily integrate code into your blog which will let you directly stream into your blog, website, and any compatible site.
  • Page 48 Media Player The media player allows you to view your recordings on the SD card directly through the internet without requiring downloading the file first. This feature makes it very convenient for live streaming. View in Full Screen To view the IP Kamera in full screen model you will need to press the Full Screen mode. - 48- Ref#201008109070CSWO...
  • Page 49 My Web The My-Web functionality will make your IP Kamera more than just a surveillance tool. Now you can use it to promote your company, restaurant, business, school, and etc. With some basic website skills or tools any can make a My Web site. Turning On My Web Enable my web button: The enable My Web button will activate the My Web functionality.
  • Page 50 How to use my WEB 1. Download sample. 2. Save the zip file to the location . Press browse, and select the zip file you download. 4. Press upload and send the zip file to 9070 web. 5. Confirm setting . *** If familiar with webpage langrage, you can change the webpage in zip file to your own webpage.
  • Page 51: Schedule Record

    Then on the web browser type in the following http://192.168.12.111:8080/index.htm Use can get 9070-CSWO/CSO message by RSS as Snapshot, Motion detection , Record as motion ***Notice: User need to register in DDNS *** In the Dyndns section, type in the Dyndns that you register from www.dyndns.com and add a /rss20.
  • Page 52: Schedule Recording

    The schedule allows you to select days and times that you would like to schedule automatic recording. You can pick a day from (Sunday – Saturday) and also a option for Everyday. To schedule automatic recording: 1.) Select the day that you would want to start recording. 2.) Select the From time and the To time.
  • Page 53: Alarm

    SMTP When motion is detected, the IP Kamera 9070 will send the video file to in a E-mail format. Recording Time: Set the duration of time you would like the IP Kamera 9070-CSWO/CSO to record when alarm is set off.
  • Page 54 Motion Detection To enable motion detection: 1.) Select Enable in the motion detection option. 2.) Select the sensitivity of your choice You can pick from Lowest, Low, Medium, High, Highest You can also customize your own threshold from (1-99) 3.) Once you have set your settings on the window screen click on the picture where you want the motion to be detected.
  • Page 55: Media Player

    Media Player The media player allows you to view your recordings on the SD card directly through the internet without requiring downloading the file first. This feature makes it very convenient for live streaming. View in Full Screen To view the IP Kamera in full screen model you will need to press the Full Screen mode. Logout When you are done use the IP Kamera 9070 CSWO/CSO the logout function allows you to easily logout of your device.
  • Page 56: Controlling The Device

    7.) Controlling the Device CGI HTTP Commands Http commands allow you to control the device with commands. The basic commands are provided below. There are two ways to input http commands with authorization required Password in http: http://login:password@ipaddress:port/command Password not in http: http://ipaddress:port/command Note: If you use the password not in http: command you will need to enter it when the browser asks for the password.
  • Page 57: Change Name

    This command allows you to change the name of the IP Kamera 9070-CSWO/CSO http://ipaddress:port/vb.htm?cameratitle=name Ex. http command: http://192.168.1.192/vb.htm?cameratitle=test_907011 Change IP Address: This command allows you to change the IP Address of the IP Kamera 9070-CSWO/CSO http://ipaddress:port/vb.htm?internetip=ipaddress Ex. http command: http://192.168.1.192/vb.htm?internetip=192.168.1.191 Change Port: This command allows you to change the Port of the IP Kamera 9070-CSWO/CSO http://ipaddress:port/vb.htm?httpport=portnumber...
  • Page 58: Mjpeg Streaming

    8.) Using RTSP with VLC Before Setting up VLC: Make sure that the 9070-CSWO/CSO is set to be the DMZ host on the router that you are using, please refer to the routers manual on how to accomplish this.
  • Page 59 Check the Cache value. For low latency, it should be 70~80 based on PC’s performance. Note: If the video is not smooth, set the caching value from 150~1200. This problem could be due to too much congestion, busy pc, and etc. 7.) Save the new settings 8.) Then go back to the VLC media player and go to Media >...
  • Page 60 10.) Type in the RTSP address of your device For Mpeg4 Stream1 : rtsp://<IP Address>/mpeg4 For Mpeg4 Stream2 : rtsp://<IP Address>:8554/mpeg4 rtsp://122.116.137.123/mpeg4 Example: 11.) Hit the play button and wait a few seconds for the program to start streaming. - 60- Ref#201008109070CSWO...
  • Page 61: Using Cnt With Surf16 Ch

    9.) Using CNT with Surf16 CH CNT makes connecting to the IP Kamera 9070 a very simple task. Using Surf 16 CH and multi device DVR monitoring software, you can easily view your 9070-CSWO/CSO. Follow these simple steps: MAC Address There are two ways to find the MAC address in IP Edit .
  • Page 62: Frequently Asked Questions (F.a.q)

    Ans: On the back of the device there is a reset button, hold down the reset button for more than 7 seconds. Then give the 9070-CSWO/CSO a 1 minute to restart. Once the device has restarted it will be set back to manufacturer default settings.
  • Page 63: Customer Feedback

    Your Feedback is definitely important for us to continue providing the great quality products and service that Aviosys has to offer. We definitely would like to know what you think about our products and how we can we can make your Aviosys experience even better.
