  • Page 9: Chapter 1 Overview

    Chapter 1 Overview Thank you for choosing the IM-QM67, an excellent in- dustrial computer board from MSI. Based on the innovative Intel QM67 chipsets for ® optimal system efficiency, the IM-QM67 accommo- dates the Intel Core™i7 / i5 / i3 or Celeron proces- ®...
  • Page 10: Mainboard Specifications

    ▍ Overview ainboard pecificationS ■ Intel Core™i7 / i5 / i3 or Celeron processor in ® ® rPGA-989 (Socket G2) ■ Chipset Intel QM67 Chipset ® ■ Memory 2 unbuffered non-ECC DDR3 1067/1333 DIMM slots ■ Supports the maximum of 16GB ■...
  • Page 11 MS-9887 Slot ■ 1 CFast slot ■ 1 Mini PCI Express x 1 slot ■ 1 32-bit 33/66MHz 3.3v PCI slot ■ Form Fac- Mini-ITX: 17.0cm x 17.0cm Environ- ■ Operating Temperature: -10 C to 60 ■ Storage Temperature: -20 C to 80 mental ■...
  • Page 12: Mainboard Layout

    ▍ Overview ainboard ayout Back Panel GPIO Connector Power Connector Audio power am- plifier Connector Chassis Intru- sion Connector PCI Slot DIMM Slots LVDS Power Connector JSPI1 Connector Connector COM2~4 Power- System Fan & CPU Connector Connectors LVDS Connector Mini PCI Express Slot SATA Power Connectors USB Con-...
  • Page 13 MS-9887 CFast Slot...
  • Page 14: Chapter 2 Hardware Setup

    Chapter 2 Hardware Setup This chapter provides you with the information on mainboard hardware configurations. Incorrect setting of jumpers and connectors may damage your main- board. Please pay special attention not to connect these headers in wrong direction. DO NOT adjust any jumper while the mainboard is powered on.
  • Page 15 ▍ Hardware Setup uick oMponentS uide Back Panel I/O, p.2-7 JGPIO1, p2-12 JPWR1, p.2-6 JAMP1, p.2-15 CPU, p.2-3 JCASE1, p.2-9 PCI Slot, p.2-17 DIMM Slot, p.2-5 JDSW1 p.2-16 JSPI1, p.2-14 J_ME1, p.2-14 CPUFAN1/SYSFAN1, p.2-16 p.2-10 JLVDS1, p.2-11 Mini PCI Express Slot, p.2-17 JSATA_PWR1/2, p.2-10...
  • Page 16: Cpu (Central Processing Unit)

    MS-9887 cpu (c entraL roceSSinG When you are installing the CPU, make sure that you install the cooler to prevent overheating. If you do not have the CPU cooler, consult your dealer before turning on the computer. Important Overheating Overheating will seriously damage the CPU and system. Always make sure the cooling fan can work properly to protect the CPU from overheat- ing.
  • Page 17 ▍ Hardware Setup CPU Installation Locate the CPU socket on the mainboard. On the upper end of the CPU socket is a socket actuator in the form of a slotted screw head. Make sure that you open or close the socket with a flathead screw- driver before and after installing the CPU.
  • Page 18: Memory

    MS-9887 eMory These DIMM slots are intended for memory modules. DDR3 SO-DIMM Slot 204-pin Installing Memory Modules Locate the DIMM1 SO-DIMM slot. Align the notch on the DIMM with the key on the slot and insert the DIMM into the slot at 45-degree angle.
  • Page 19: Power Supply

    ▍ Hardware Setup ower uppLy Power Connector: JPWR1 This connector provides power to the mainboard.
  • Page 20: Back Panel I/O

    MS-9887 aneL Keyboard LAN Ports Port D-Sub Port DVI-D Port Line-In Line-Out HDMI Port DVI-D Port Mouse USB 2�0 Ports Port ▶ Keyboard Port The standard PS/2 keyboard DIN connector is for a PS/2 keyboard. ▶ Mouse Port The standard PS/2 mouse DIN connector is for a PS/2 mouse. ▶...
  • Page 21 ▍ Hardware Setup ▶ LAN Port The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN). You can connect a network cable to it. Activity Indicator Speed Indicator Left LED Right LED Active LED 100M/1000M Speed LED LED Color Yellow Green/Orange...
  • Page 22: Connector

    MS-9887 onnector Chassis Intrusion Connector: JCASE1 This connector is provided to connect the chassis intrusion switch cable. If the chassis is opened, the chassis intrusion mechanism will be acti- vated. The system will record this status and show a warning message on the screen.
  • Page 23 ▍ Hardware Setup Fan Power Connector: CPUFAN1 / SYSFAN1 The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND.
  • Page 24 MS-9887 LVDS Flat Panel Connector: JLVDS1 The LVDS (Low Voltage Differential Signal) connector provides a digital interface typically used with flat panels. After connecting an LVDS inter- faced flat panel to the JLVDS1, be sure to check the panel datasheet and set the J2 jumper for proper power voltage.
  • Page 25 ▍ Hardware Setup Front USB Connector: JUSB1 / JUSB2 This connector, compliant with Intel I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Important Note that the pins of VCC and GND must be connected correctly to avoid possible damage.
  • Page 26 MS-9887 Serial Port Connector: COM1 (RS-232/-422/-485) Serial Port Connector: COM2~4 (RS-232) This connector is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs. You can attach a serial device to it through an optional serial port bracket. RS-232 RS-232 SIGNAL...
  • Page 27 ▍ Hardware Setup JSPI1 Connector: JSPI1 This connector is provided for engineer debug only. J_ME1 Connector: J_ME1 This connector is provided for setting ME firmware update. J_ME1 Disable Enable 2-14...
  • Page 28: Jumper

    MS-9887 uMper Audio Amplifier Connector: JAMP1 The JAMP1 is used to connect audio amplifiers to enhance audio per- formance. SIGNAL AMP_L- AMP_L+ AMP_R- AMP_R+ 2-15...
  • Page 29 ▍ Hardware Setup Serial Port Power Jumper: J2 This jumper specifies the operation voltage of the onboard serial ports. Important Avoid adjusting the jumper when the system is on; it will damage the mainboard. LVDS Power Jumper: JDSW1 Use this jumper to specify the LVDS power. 3.3V Important Avoid adjusting the jumper when the system is on;...
  • Page 30: Slot

    MS-9887 Mini PCI (Peripheral Component Interconnect) Ex- press Slot The mini PCI Express slot supports the mini PCI Express interface expan- sion card such as wireless LAN, TV tuner, and Robson NAND Flash . Mini PCI-E Slot PCI (Peripheral Component Interconnect) Slot The PCI slot supports LAN card, SCSI card, USB card, and other add-on cards that comply with PCI specifications.
