  • Page 1 IM-HM65 MS-9897 (v1.x) Industrial Computer Board...

  • Page 2: Trademarks

    ▍ Preface Copyright Notice The material in this document is our intellectual property. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice.

  • Page 3: Safety Instructions

    MS-9897 Safety Instructions ￭ Always read the safety instructions carefully. ￭ Keep this User’s Manual for future reference. ￭ Keep this equipment away from humidity. ￭ Lay this equipment on a reliable flat surface before setting it up. ￭ The openings on the enclosure are for air convection hence protects the equipment from overheating.

  • Page 4: Ce Conformity

    ▍ Preface CE Conformity Hereby, we declare that this device is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive. FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 5: Weee Statement

    MS-9897 WEEE Statement ENGLISH Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment, Directive 2002/96/EC, which takes effect on August 13, 2005, products of “electrical and electronic equipment” cannot be discarded as municipal waste anymore and manufactur- ers of covered electronic equipment will be obligated to take back such products at the end of their useful life.
  • Page 6 ▍ Preface meer beschouwd worden als vervuiling. Fabrikanten van dit soort producten worden verplicht om producten retour te nemen aan het eind van hun levenscyclus. SRPSKI Po Direktivi Evropske unije (“EU”) o odbačenoj ekektronskoj i električnoj opremi, Di- rektiva 2002/96/EC, koja stupa na snagu od 13. Avgusta 2005, proizvodi koji spadaju pod “elektronsku i električnu opremu”...

  • Page 7: Table Of Contents

    MS-9897 Contents Copyright Notice ................. ii Trademarks ..................ii Revision History .................. ii Safety Instructions ................iii CE Conformity ..................iv FCC-B Radio Frequency Interference Statement ......iv WEEE Statement ................v Chapter 1 Overview ������������������������������������������������������������������������������� 1-1 Mainboard Specifications ..............1-2 Mainboard Layout ................

  • Page 9: Chapter 1 Overview

    Chapter 1 Overview Thank you for choosing the IM-HM65, an excellent in- dustrial computer board. Based on the innovative Intel HM65 chipset for op- ® timal system efficiency, the IM-HM65 accommodates the Intel Sandy Bridge mobile processor and sup- ®...

  • Page 10: Mainboard Specifications

    ▍ Overview Mainboard Specifications ■ Intel Sandy Bridge mobile processor Chipset ■ Intel HM65 PCH Memory ■ 2 unbuffered non-ECC DDR3 800/ 1066/ 1333 SO- DIMM slots ■ Supports the maximum of 8GB ■ Supports Dual Channel ■ 1 Intel 82574L GbE controller ■...
  • Page 11 MS-9897 Environ- ■ Operating Temperature: 0 C to 60 ■ Storage Temperature: -20 C to 80 mental ■ Humidity: 0% ~ 90% RH, non-condensing...

  • Page 12: Mainboard Layout

    ▍ Overview Mainboard Layout Deep Sleep Fan Power DC Power Mode Jumper Connector Connector Clear CMOS Fan Power Jumper DIMM Slot Connector Back Panel I/O Front Panel Pinheader Front USB Pinheader Port 80 pinheader SATA Power Connector Serial Port Pinheader SATA Connector LVDS Power Jumper Chassis Intrusion...
  • Page 13 MS-9897 DIMM Slot SIM card holder Mini PCIe Slot...

  • Page 15: Chapter 2 Hardware Setup

    Chapter 2 Hardware Setup This chapter provides you with the information on mainboard hardware configurations. Incorrect setting of jumpers and connectors may damage your main- board. Please pay special attention not to connect these headers in wrong direction. DO NOT adjust any jumper while the mainboard is powered on.

  • Page 16: Quick Components Guide

    ▍ Hardware Setup Quick Components Guide JDSW1, p2-15 SYSFAN1, p.2-8 DIMM Slot, p�2-3 JPWR1, p�2-4 JCMOS1, p�2-13 Back Panel I/O, p�2-5 CPUFAN1, p�2-8 JFP1, p�2-8 JUSB1, p�2-9 JDP1, p�2-12 JSATA_PWR1, p�2-4 COM2/1, p�2-10 SATA1/2, p�2-7 J1, p�2-14 JCASE1, p�2-11 JLVDS1, p�2-11 MINI_PCIE1, p�2-16 COM3_1, p�2-10 JAMP1, p�2-9...

  • Page 17: Memory

    MS-9897 Memory ▶ Installing Memory Modules Locate the SO-DIMM slot. Align the notch on the DIMM with the key on the slot and insert the DIMM into the slot. Push the DIMM gently downwards until the slot levers click and lock the DIMM in place.

  • Page 18: Power Supply

    ▍ Hardware Setup Power Supply DC Power Connector: JPWR1 This connector provides 12/19/24V DC power input. SATA Power Connector: JSATA_PWR1 This connector provides power to SATA hard drives.

  • Page 19: Back Panel I/O

    MS-9897 Back Panel I/O Mic-In Jack HDMI Port DVI-I Port Line-Out Jack USB 2�0 USB 2�0 Port Port ▶ HDMI Port The High-Definition Multimedia Interface (HDMI) is an all-digital audio-video interface that is capable of transmitting uncompressed streams. HDMI supports all types of TV formats, including standard, enhanced, or high- definition video, plus multi-channel digital audio on a single cable.
  • Page 20 ▍ Hardware Setup ▶ The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN). You can connect a network cable to it. Activity Indicator Speed Indicator Left LED Right LED (Active LED) (100M/1000M Speed LED) LED Color Yellow Green/Orange No Transmission...

  • Page 21: Connector

    MS-9897 Connector Serial ATA Connector: SATA1 ~ SATA2 This connector is a high-speed Serial ATA interface port. Each connector can connect one Serial ATA device. Important Please do not fold the Serial ATA cable into a 90-degree angle. Otherwise, data loss may occur during transmission.
  • Page 22 ▍ Hardware Setup Front Panel Pinheader: JFP1 This front panel connector is provided for electrical connection to the front panel switches & LEDs and is compliant with Intel Front Panel I/O Con- nectivity Design Guide. Fan Power Connectors: CPUFAN1 & SYSFAN1 These fan power connectors support system cooling fan with +12V.
  • Page 23 MS-9897 Audio Amplifier Pinheader: JAMP1 The JAMP1 is used to connect audio amplifiers to enhance audio perfor- mance. Front USB Pinheader: JUSB1 This connector, compliant with Intel I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like.
  • Page 24 ▍ Hardware Setup Serial Port Pinheader: COM1, COM2, COM3_1 This connector is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs. You can attach serial devices to it through the optional serial port bracket. COM1/ COM2 COM3_1 2-10...
  • Page 25 MS-9897 LVDS Connector: JLVDS1 The LVDS (Low Voltage Differential Signal) connector provides a digital in- terface typically used with flat panels. After connecting an LVDS interface flat panel to this connector, be sure to check the panel datasheet and set the JVDD1 jumper to proper power voltage.
  • Page 26 ▍ Hardware Setup Port 80 Pinheader: JDP1 This pinheader is intended for Transport Control Protocol (TCP) port 80. 2-12...

  • Page 27: Jumper

    MS-9897 Jumper Clear CMOS Jumper: JCMOS1 There is a CMOS RAM onboard that has a power supply from an external battery to keep the data of system configuration. With the CMOS RAM, the system can automatically boot OS every time it is turned on. If you want to clear the system configuration, set the jumper to clear data.
  • Page 28 ▍ Hardware Setup Serial Port Power Jumper: JCOMP1 This jumper specify the operation voltage of the onboard serial ports. +12V JCOMP1 LVDS Power Jumper: J1 Use this jumper to specify the LVDS power. +12V 2-14...
  • Page 29 MS-9897 Deep Sleep Mode Jumper: JDSW1 Use this jumper to specify the deep sleep mode (S4/S5). Enable Disable JDSW1 (default) Important Avoid adjusting the jumper when the system is on; it will damage the main- board. 2-15...

  • Page 30: Slot

    ▍ Hardware Setup Slot Mini PCI-E (Peripheral Component Interconnect Ex- press) Slot The Mini PCI-E slot is provided for wireless LAN card, and Robson NAND Flash card . Important When adding or removing expansion cards, make sure that you unplug the power supply first.

  • Page 31: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup This chapter provides information on the BIOS Setup program and allows you to configure the system for optimum use. You may need to run the Setup program when: ■ An error message appears on the screen during the system booting up, and requests you to run SETUP.

  • Page 32: Entering Setup

    ▍ BIOS Setup Entering Setup Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press <DEL> key to enter Setup. Press DEL to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On or pressing the RESET button.

  • Page 33: Control Keys

    MS-9897 Control Keys ← → Select Screen ↑ ↓ Select Item Enter Select Change Option General Help Previous Values Optimized Defaults Save & Exit Exit Getting Help After entering the Setup menu, the first menu you will see is the Main Menu.

  • Page 34: The Menu Bar

    ▍ BIOS Setup The Menu Bar ▶ Main Use this menu for basic system configurations, such as time, date, etc. ▶ Advanced Use this menu to set up the items of special enhanced features. ▶ Boot Use this menu to specify the priority of boot devices. ▶...

  • Page 35: Main

    MS-9897 Main ▶ System Date This setting allows you to set the system date. The date format is <Day>, <Month> <Date> <Year>. ▶ System Time This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>. ▶...
  • Page 36 ▍ BIOS Setup [LBA/Large Enabling LBA causes Logical Block Address- Mode] ing to be used in place of Cylinders, Heads and Sectors [Block Any selection except Disabled determines the (Multi-Sector number of sectors transferred per block Transfer)] [PIO Mode] Indicates the type of PIO (Programmed Input/Output) [DMA Mode] Indicates the type of Ultra DMA...

  • Page 37: Advanced

    MS-9897 Advanced ▶ Full Screen Logo Display This BIOS feature determines if the BIOS should hide the normal POST messages with the motherboard or system manufacturer’s full-screen logo. When it is enabled, the BIOS will display the full-screen logo during the boot-up sequence, hiding normal POST messages.
  • Page 38 ▍ BIOS Setup ▶ Option ROM Messages This item is used to determine the display mode when an optional ROM is initialized during POST. When set to [Force BIOS], the display mode used by AMI BIOS is used. Select [Keep Current] if you want to use the display mode of optional ROM.
  • Page 39 MS-9897 ▶ Launch Intel 82579/ 82574 OpROM These settings enable/disable the initialization of the onboard PXE Boot ROM during bootup. Selecting [Disabled] will speed up the boot process. ▶ Mini-PCIe Slot This setting determines the operation mode of the Mini PCIe slot. ▶...
  • Page 40 ▍ BIOS Setup ▶ Super IO Configuration ▶ Serial Port 1/ 2/ 3/ 4/ 5/ 6 This setting enables/disables the specified serial port. ▶ Change Settings This setting is used to change the address & IRQ settings of the speci- fied serial port.
  • Page 41 MS-9897 ▶ Smart Fan Configuration ▶ Smart FAN1/ FAN2 Function These settings enable/disable the Smart Fan function. Smart Fan is an excellent feature which will adjust the CPU/system fan speed automatically depending on the current CPU/system temperature, avoiding the overheating to damage your system. 3-11...

  • Page 42: Boot

    ▍ BIOS Setup Boot ▶ Boot Option #1 / #2 / #3 This setting allows users to set the sequence of boot devices where BIOS attempts to load the disk operating system. ▶ Hard Drive BBS Priorities This setting allows users to set the priority of the specified devices. First press <Enter>...

  • Page 43: Security

    MS-9897 Security ▶ Administrator Password Administrator Password controls access to the BIOS Setup utility. ▶ User Password User Password controls access to the system at boot and to the BIOS Setup utility. 3-13...
  • Page 44 ▍ BIOS Setup ▶ Trusted Computing ▶ TPM SUPPORT This setting controls the Trusted Platform Module (TPM) designed by the Trusted Computing Group (TCG). TPMs are special-purpose inte- grated circuits (ICs) built into a variety of platforms to enable strong user authentication and machine attestation - essential to prevent inap- propriate access to confidential and sensitive information and to protect against compromised networks.
  • Page 45 MS-9897 ▶ Serial Port Console Redirection ▶ Console Redirection Console Redirection operates in host systems that do not have a monitor and keyboard attached. This setting enables/disables the operation of console redirection. When set to [Enabled], BIOS redirects and sends all contents that should be displayed on the screen to the serial COM port for display on the terminal screen.

  • Page 46: Chipset

    ▍ BIOS Setup Chipset ▶ Primary Display This setting specifies which is your primary graphics adapter. ▶ Internal Graphics The setting enables/ disables the internal graphics. ▶ GTT Size The Graphics Translation Table (GTT) is a Translation Lookaside Buffer (TLB) used to map the virtual memory space of the graphics aperture to that of the physical address space.
  • Page 47 MS-9897 ▶ DVMT Pre-Allocated This setting defines the DVMT pre-allocated memory. Pre-allocated memory is the small amount of system memory made available at boot time by the system BIOS for video. Pre-allocated memory is also known as locked memory. This is because it is "locked" for video use only and as such, is invisible and unable to be used by the operating system.

  • Page 48: Power

    ▍ BIOS Setup Power ▶ ACPI Sleep State This item specifies the power saving modes for ACPI function. If your oper- ating system supports ACPI, you can choose to enter the Standby mode in S1 (POS) or S3 (STR) fashion through the setting of this field. ▶...
  • Page 49 MS-9897 ▶ Deep S5 The setting enables/disables the Deep S5 power saving mode. S5 is almost the same as G3 Mechanical Off, except that the PSU still supplies power, at a minimum, to the power button to allow return to S0. A full reboot is required.

  • Page 50: Save & Exit

    ▍ BIOS Setup Save & Exit ▶ Save Changes and Exit Save changes to CMOS and exit the Setup Utility. ▶ Discard Changes and Exit Abandon all changes and exit the Setup Utility. ▶ Save Changes and Reset Save changes to CMOS and reset the system. ▶...

  • Page 51: Chapter 4 System Resources

    Chapter 4 System Resources This chapter provides information on system re- sources.
  • Page 52 ▍ System Resources esouRce SIO : 4Eh TPM : 2Eh PCH GPIO...
  • Page 53 MS-9897...
  • Page 54 ▍ System Resources...
  • Page 55 MS-9897 SIO F81866D...
