- Page 1 MODEL G-1 Owner’s Manual … Respect for the past with insight to the future...
-
Page 2: Table Of Contents
Model G-1 Guitar Amplifier Owner’s Manual TABLE OF CONTENTS INTRODUCTION............3 FRONT PANEL ............. 4 REAR PANEL ..............7 FOOTSWITCH CONNECTION DETAILS ....8 SPECS ................9 TUBE PLACEMENT ..........10 WARRANTY..............11 SAFETY INFORMATION ......... 12 Ladner Engineering Group LLC... -
Page 3: Introduction
Each knob has sensitive control in their respective position, bringing forth a wide spectrum of sounds to choose from. Enough of this stuff, go out and play your G-1 for a thousand hours a day! Andrew & D.C. Ladner... -
Page 4: Front Panel
Model G-1 Guitar Amplifier Owner’s Manual FRONT PANEL 1 - INPUT - ¼” jack that delivers the signal from the guitar to the first stage of gain in the amplifier. 2 - GAIN - Controls the level of the first gain... - Page 5 Model G-1 Guitar Amplifier Owner’s Manual amplifier respond in the traditional fashion. The alternate position brings a flatter response, which can benefit certain instruments ( such as lap-steel, pedal steel, electric violin, etc… alternate tone stack also works great for the jazz guitarist, helping to show the true tone of a classic hollow body.
- Page 6 Model G-1 Guitar Amplifier Owner’s Manual tighten and produce a more detailed bottom sound if desired. 9 – OD LEVEL – Sets the output level of the overdrive channel. It provides a way to balance the overdrive signal to the clean signal for a balanced sound or even a boost or cut within the overdrive function.
-
Page 7: Rear Panel
Model G-1 Guitar Amplifier Owner’s Manual 13 – MASTER – Controls the over all volume and output of the amplifier. 12 – PLAY/STANDBY/OFF – An all-inclusive function control - go from Off/Standby/On, with one switch. Rear Panel 1 – FUSE- 3Amp 250V AGC fuse. -
Page 8: Footswitch Connection Details
Model G-1 Guitar Amplifier Owner’s Manual produces more high-end sparkle. The Presence control is very functional and powerful to the overall tone and has more range than most conventional amplifiers. 4 - FOOTSWITCH – Connection for the channel selection footswitch, a standard TRS or Tip Ring NOTE: Sleeve cable is required. -
Page 9: Specs
Model G-1 Guitar Amplifier Owner’s Manual 6 – SLAVE OUTPUT - ¼” jack to deliver signal to a console or to facilitate “re-amping”. 7 – SPEAKER OUT - ¼” jack to deliver signal to a speaker cabinet. 8 – Zout - Impedance selector 4,8,16 ohm –... -
Page 10: Tube Placement
Model G-1 Guitar Amplifier Owner’s Manual TUBE PLACEMENT V1-V4: 12AX7 V5-V8: 6L6 V1: Input stage (Mullard 12AX7A) V2: Tone V3: Overdrive (12AX7LPS) V4: Phase Inverter (12AX7LPS) V5-V8: Output (6L6 WXT+) CAUTION: Tubes are when in use, and for a while after the unit has been turned off, use extreme caution when changing. -
Page 11: Warranty
WARRANTY All Ladner amplifiers sold by authorized Ladner dealers are warranted by Ladner Engineering Group to be free from defects in material or workmanship under normal use and service for a period of five (5) years* on parts and three (3) years* on labor from the original date of purchase. -
Page 12: Safety Information
Model G-1 Guitar Amplifier Owner’s Manual ALWAYS TURN POWER OFF WHEN CHANGING OR REPLACING TUBES SAFETY INFORMATION Do not expose this amplifier to moisture or water (i.e. avoid dropping into swimming pools, most lakes, water ways or use during times of excessive storm surge)** or extreme heat. - Page 13 Model G-1 Guitar Amplifier Owner’s Manual This amplifier produces EXTREME SOUND VOLUMES and can cause PERMANET HEARING DAMAGE, handle with care. THIS MEANS YOU! Common sense is a valuable tool, so use it. Always have this Amplifier serviced by a...
- Page 14 Model G-1 Guitar Amplifier Owner’s Manual Thank you for your purchase, and welcome to the Ladner Engineering family. We wish you many years of great tonal bliss with your hand- built G-1 amplifier. A toast to you and the future, Andrew and D.C Ladner...
