Related Manuals for ADB ADB 5810 Box
Summary of Contents for ADB ADB 5810 Box
- Page 1 Cable in the Country PVR Manual Record Order Pay-Per-View Fast Forward Rewind Tune us in..Providing tomorrow’s technology today...
- Page 2 ADB Universal Remote Instructions Manual About Your UNIVERSAL REMOTE TCC has chosen the Universal Remote Control opting for the friendly remote control solution, made made according to the highest quality. Please read these enclosed instructions carefully before putting your to use.
- Page 3 9. Channel Up / Down Control: These keys will allow you to move through the channels. 10. CC or TXT: The Closed Caption key mutes the volume and allows for closed captioning. 11. Volume Up / Down Control: These keys will adjust the volume level of your device. 12.
-
Page 4: Fast Forward
Playback Controls (Control Live TV) Rewind You can use the REWIND button to make sure you don’t miss a thing. Programs you are watching live can be rewound. Press the REWIND button up to 4 times to increase rewind speed. Remember the rewind feature only works on the channel you are currently on or on a program that has been recorded. - Page 5 ADB 5810 Box Box Navigation Buttons MENU-The menu button on the box is the same as the remote EPG-Will take you to the Guide RES-Will change the resolution from/between digital and HD Arrow Buttons and OK Button-Used to navigate and select...
- Page 6 How to use the Guide feature on your PVR Simply press the GUIDE button or press the MENU button and select GUIDE. Scroll up and down or side to side with arrow buttons to find the program you want to watch and press the OK button once for a preview in the corner or twice for the full screen.
- Page 7 How to record with your PVR There are two ways you can set a recording on your PVR. First, you can go to GUIDE. Select the program you want to record and press the OK button. Select SET RECORDING and press the OK button.
- Page 8 How to record with your PVR (continued) Highlight the show you would like to record and press the OK button. Scroll down with your arrow buttons and highlight SCHEDULE EVENT and press the OK button Next you will see the schedule screen. To enter in your recording information simply use the arrow buttons to select the box you would like to change and...
- Page 9 How to Record on your PVR (continued) When you are finished you will see the program on the guide listings will have a red dot. When you have that program selected you will see it says RECORD in the right hand corner.
- Page 10 How to find the programs you Recorded? Go to MENU and select PVR and press the OK button. Select RECORDINGS and press the OK button. On the right hand side of the Menu you will see all of the programs you have recorded.
- Page 11 How to find the programs you Recorded? (continued) Now you can select PLAY RECORDING and press the OK button to watch your recorded program, you can select LOCK and press the OK button to keep the program from being deleted, you can select DELETE RECORDING and press the OK button to delete the current recording, or cancel and...
- Page 12 How to see what programs will be recorded in the future Go to MENU and select PVR and press the OK button Select TO RECORD press the OK button On the right hand side of the Menu you will see all of the programs you have set to record in the future.
- Page 13 How to see what you have recorded in the past Go to MENU and select PVR and press the OK button. Select RECORD HISTORY press the OK button. On the right hand side of the Menu you will see all of the programs you have recorded in the past.
- Page 14 How to see what programs you have deleted in the past Go to MENU and select PVR and press the OK button. Select DELETE HISTORY press the OK button. On the right hand side of the Menu you will see all of the programs you have deleted in the past.
- Page 15 Recording Guidlines When setting current or future recordings, you must remember you can only record one program at a time. If you have two programs set at the same time it will ask you if you want to stop recording one of the programs. You can watch a different program than you are recording, but you cannot record two programs at the same time.
- Page 16 How to set up your PIN number for PPV Enter in 0 (zero) for the password. Press the MENU Button, use the arrows to Select OK and press the OK Button. select SETTINGS and press the OK button. Arrow over to the USER Tab. Then Arrow to the bottom box labeled USER select OK and press the OK Button.
- Page 17 How to Buy a Pay-Per-View Movie Select a Pay-Per-View program from the guide press the OK button. Select BUY PPV press the OK button. You will be asked for a pin number enter 0 or the pin number you have previously set up.
- Page 18 Remote Control Programming Instructions Main Set Up -- You can set-up the remote to control other devices (television, dvd, vcr, etc) 1. Make sure the device you wish to operate is switched on (not in standby). 2. Find the code for the device in the Code List. If your brand is not listed, skip to Search Method. 3.
- Page 19 TV’S Toshiba 0695 Sharp 0093, 0039, 0165, 0157 Aiwa 0701 Siemens 0037, 0191, 0157, 0195, 0535, Akai 0702, 0030, 0672 0554, 0200, 0327, 0328, 0032, 0146, TV/VCR/DVD Devices 0556, 0361 Apex 0748, 0765 Emerson 0821 Signature 0016 Audiovox 0451, 0180, 0092, 0623, 0003 Panasonic 1362 Sony 0000, 0111, 0080 Curtis Mathes 0016, 0047, 0466, 0030,...
- Page 20 Volume Punch Through You may be able to use some functions of your Television, DVD player or the set top box at the same time. For example: if you are watching a program on your DVD player, you can adjust the volume (a TV function) without pressing the TV mode key on your Remote.
- Page 21 1-800-831-0610 www.tcc.coop Located in Strum and Independence...
