3800W
USB slot
USB slot allows you to
connect external devices.

Included Accessories

As you unpack your digital decoder, please make sure that the following accessories are included:

Rear Panel

1
2
1 - Power plug (12V)
2 - Output to TV
3 - S/PDIF (Digital Audio Output)
4 - USB port
5 - Ethernet port
Function buttons
These buttons perform the same
function as the correspondent
ones on the remote control.
Remote control
3
5
6
4
Getting Started
LEDs and Display
The LED indicators inform
you about the status of
your decoder.
Display presents current
time.
Power Adaptor
Batteries
7
8
6 - HDMI (HD Digital Output)
7 - Component Output (HD Analog Output)
8 - S-VIDEO Output
9 - CVBS VIDEO Output
10 - RCA Stereo Audio Output
9
10
