Figures in this manual are schematic
and may not match your appliance
exactly.
DANGER
Risk of scalding by hot steam!
Take care when opening the oven
door as steam may escape.
Anti-Tilt mechanism
"A" 1 x Stability chain
"B" 1 x Stability hook with anchor sleeve
"A" is factory fitted at the rear of the stove in the centre. (See overleaf for instructions if the
removable splashback is to be fitted)
Position the stove and move "A" to touch the wall behind the stove.
Mark the hole where "A" touches the wall behind the stove.
Move the stove away from the wall to allow for an area to work in.
Using a 8.0 mm concrete bit, drill a hole at the marked position.
Using the Stability hook and anchor sleeve "B", firmly secure "B" to the wall.
Slide the stove back in position and engage the stability chain "A" onto the Stability hook "B".
The stove is then secured and will not accidentally tilt if downward pressure is applied to the
open oven door.
Safety regulations stipulate that the ANTI-TILT mechanism supplied with the stove,
must be fitted as shown.
Figures in this
manual are
schematic
and may not
match your
stove exactly.
PAGE 5 OF 12
WARNING Hot surfaces may cause
burns! Do not touch the hot surfaces
of the appliance. Use oven gloves.
Keep children away from the
appliance.
DANGER Risk of fire by overheated
oil! When heating oil, do not leave it
unattended. Never try to extinguish a
fire with water! When oil has caught
fire, immediately cover the pot or pan
with a lid. Switch off the hob if safe to
do so and phone the fire service.
