LM929
LM929
19" LCD Monitor
User's
Manual
By Envision Peripherals, Inc.
www.aocmonitor.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LM929 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AOC LM929

Summary of Contents for AOC LM929

  • Page 1 LM929 LM929 19” LCD Monitor User’s Manual By Envision Peripherals, Inc. www.aocmonitor.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Table of Contents For Your Safety Precautions General Notes Before You Operate The Monitor Installation Instructions Operating Instructions Technical Support (FAQ) Appendix LM929 7-13 14-19 19-21 21-25...

  • Page 3: For Your Safety

    Refer servicing to qualified personnel only. SAFETY: Lamp Disposal LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL,STATE OR FEDERAL LAWS.FOR MORE INFORMATION,CONTACT THE ELECTRONIC INDUSTRIES ALLIANCE AT WWW.EIAE.ORG NERGY guidelines for energy efficiency.  LM929...

  • Page 4: Precautions

    ! To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate configured receptacles marked between 100 - 240V AC, Min. 5A. ! The wall socket shall be installed near the equipment and shall be easily accessible. LM929...

  • Page 5: General Notes

    Never use strong solvents such as thinner, benzene, or abrasive cleaners, since these will damage the case & panel. As a safety precaution, always unplug the monitor before cleaning it. These damages are not covered under the LM929...

  • Page 6: General Notes

    LM929 GENERAL NOTES (cont) Plug & Play DDC 2B Feature - This monitor is equipped with VESA DDC 2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.

  • Page 7: Before You Operate The Monitor

    Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE PACKAGE The product package should include the following items: Monitor Warrabty Booklet 24-Pin DVI Cable Base Quick Start Guide (QSG) CD (Manual & Drivers) 15-pin D-Sub Cable Power Cord LM929 PC Stereo Cable...

  • Page 8: Installation Instructions

    Set the monitor standing on a flat firm surface. Remove the height adjustment lock pin. Set the monitor face down on a padded flat surface. Press the four clips inward while pushing the bottom base out. Install Remove Base LM929...

  • Page 9: Power Cord

    The other end terminates with a molded-on type connector body, rated 10A, 250V, having standard CEE-22 Please note that power supply cord needs to use VDE 0602, 0625, 0821 approval power cord in European counties. ) shall be used. As an alternate, a female configuration. LM929...
  • Page 10 Connect the other end to a nearby AC-outlet. 5. Turn on your monitor and computer. If you monitor diplays an image, installation is complete. If not, refer to the FAQ (frequently asked questions) section for troubleshooting. Connecting Cables 24-Pin DVI Cable AC Power Cord LM929...
  • Page 11 Microsoft Windows successfully installed a Plug & Play driver. If you would still like to install the driver included in the floppy diskette or CD that came with the monitor, log-on to our website at http://www.envisionmonitor.com/support/faq.asp. Then look for “Installing the Driver” section. LM929...
  • Page 12 Careful attention is required not to catch your fingers or hands when making the adjustments above. In order to use the Pivot function, the included Pivot Software must be installed. Run D:\PIVOT\START_PIVOT.EXE, where D is the driver letter for your CD ROM Drive. Figure 3 LM929...
  • Page 13 4. Remove the small plastic cover. It is attached to the back of the monitor by hooks. 5. Remove the large plastic cover. It is attached to the back of the monitor by hooks. 6. Remove the 4 screws holding the stand to the back of the monitor. 7. Remove the stand. LM929...
  • Page 14 NOTE The Envision LM929 is in compliance with the most current revision of the VESA 75mm Flat Panel Monitor Physical Mounting Interface (FPMPMI standard). Visit our Monitor Accessories website at www.aocmonitor.com/accessories.html to purchase a wall mount solution...

  • Page 15: Operating Instructions

    This button will activate the volume control when the OSD is OFF or navigate through adjustment icons when OSD is ON or adjust a function when function is activated. 4. < or Volume Button 5. Auto Adjust or Exit Button LM929...
  • Page 16 To lock the OSD, press and hold the MENU button while the monitor is off and then press power button to turn the monitor on. To un-lock the OSD - press and hold the MENU button while the monitor is off and then press power button to turn the monitor on. LM929...
  • Page 17 4. To exit and save, select the exit function. If you want to adjust any other function, repeat steps 2-3. Figure 4 to activate it. If the function < > again to navigate through the The OSD Message LM929...
  • Page 18 Red Gain from Digital-register. Green Gain Digital-register. Blue Gain from Digital-register. Select input signal from analog source (D-Sub) LM929 Reset Value Recall Cool Contrast Value Recall Cool Brightness Value Do Auto Config Do Auto Config Do Auto Config Do Auto Config...
  • Page 19 French. Set OSD display language to Spain. Set OSD display language to Italian. Set OSD display language to Simplified Chinese. Show the resolution, H/V frequency and input port of current iput timing. LM929 The Language will be set to English.
  • Page 20 Reset Exit Clear each old status of Auto- configuration and set the color temperature to Cool. Do not execute reset, return to main menu. Exit OSD LM929...

  • Page 21: Technical Support (Faq)

    *Check if the Video Card is Plug & Play compatible *Check if the D-15 plug pin of Video Cable is bent *Make sure the AOC Monitor Drivers are installed *Adjust the Contrast and Brightness Controls. *Move electrical devices that may cause electrical interference.

  • Page 22: Technical Support (Faq)

    Check the signal -cable connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode. Set the computer to a display mode given in the Preset Display Modes table. LM929...

  • Page 23: Appendix

    VESA DDC 2B ≤ ≤ D-Sub 15pin DVI-D 24pin Analog:0.7Vp-p(standard), 75 OHM, Positive Digital DVI-D Horizontal : 376.32mm Vertical : 301.056mm 100~240VAC,50/60HZ Operating Temp: 0° to 40°C Storage Temp.: -20° to 60°C Operating Humidity: 15% to 90% 438(W)×441.5-551.5(H)×243(D)mm 7.8kg Unit (net) LM929...
  • Page 24 MENU/ Enter Contrast Brightness Focus Clock H.Position V.Position Language Input Select (Analog/DVI) (Warm) Color (Cool)Color RGB Color temperature OSD position, OSD timeout Display input information Reset Exit 55 Watts 3W + 3W UL, FCC, CSA, TÜV/GS, CE, ISO13406-2 Class II LM929...
  • Page 25 1280 × 1024 720 x 400 1024 x 768 1024 × 768 HORIZONTAL VERTICAL FREQUENCY(KHZ) FREQUENCY(HZ) 31.469 37.500 37.879 46.875 48.363 56.476 60.023 64.00 80.00 31.469 48.780 60.241 LM929 59.940 75.000 60.317 75.000 60.004 70.069 75.029 60.000 75.000 70.087 60.001 74.927...
  • Page 26 DDC-Serial Clock PI N NO. DESCRIPTION TMDS Data 3+ +5V Power Ground(for+5V) Hot Plug Detect TMDS Data 0- TMDS Data 0+ TMDS Data 0/5 Shield TMDS Data 5- TMDS Data 5+ TMDS Clock Shield TMDS Clock + TMDS Clock - LM929...
