AVS PDVR-16100 User Manual

Real time triplex stand alone dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Real Time Triplex Stand Alone DVR
User's Manual
Real Time Triplex Stand Alone DVR
[ TITAN 4 / 8 / 16 Channel DVR ]
V 1.19
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDVR-16100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AVS PDVR-16100

Summary of Contents for AVS PDVR-16100

  • Page 1 Real Time Triplex Stand Alone DVR User's Manual Real Time Triplex Stand Alone DVR [ TITAN 4 / 8 / 16 Channel DVR ] V 1.19...

  • Page 2: Table Of Contents

    Real Time Triplex Stand Alone DVR Contents SAFETY WARNING AND CAUTION ……….…………………..5 CHAP 1. INTRODUCTION ……………………………………….. 11 1. Overview ………...……………………………………………….. 11 2. Common Features ……………………………………………..11 3. Specifications ……..…………………………………………….. 12 4. Contents ………………………………………………………….. 13 5. Front Panel ……..……………………………………………….. 14 6.
  • Page 3 Real Time Triplex Stand Alone DVR Contents 3.5 Sequence …………………...……………………………….. 43 3.6 Boundary …………………………………………………….. 44 3.7 Background ………………………………………………….. 44 3.8 VGA Setup …………………………………………………… 45 4. Event Setup …………………………………………………... 46 4.1 Record Time …………………………………………….. 46 4.2 Sensor In ………………………………………………… 46 4.3 Event Action ……………………………………………... 47 4.4 Motion Setup ……………………………………………..
  • Page 4 Real Time Triplex Stand Alone DVR Contents CHAP 7. PLAYBACK – TRIPLEX FUNCTION ……..……… 61 CHAP 8. PLAYBACK – TRICKPLAY & MULTI CH. DISPLAY .. 62 CHAP 9. CD BURNER BACKUP MODE ...………..……………... 63 CHAP 10. NETWORK VIEWER …………………………………… 66 1.

  • Page 5: Safety Warning And Caution

    Real Time Triplex Stand Alone DVR SAFETY WARNING AND CAUTION TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED S ERVICE PERSONNEL.
  • Page 6 Real Time Triplex Stand Alone DVR SAFETY WARNING AND CAUTION The following are warning and caution statements for the safety of the users and for the prevention of any property damage. Please read below thoroughly. Warning and Caution signs If you are not aware of this If you are not aware of this Warning Caution...
  • Page 7 Real Time Triplex Stand Alone DVR...
  • Page 8 Real Time Triplex Stand Alone DVR...
  • Page 9 Real Time Triplex Stand Alone DVR...
  • Page 10 Real Time Triplex Stand Alone DVR...

  • Page 11: Chap 1. Introduction

    Real Time Triplex Stand Alone DVR CHAP 1. INTRODUCTION 1. Overview Digital Video Recorder (DVR) is the latest in surveillance technology that offers full digital recording, remote surveillance access, remote device control and more. The DVR system is a computerized surveillance system that combines all the features of a traditional videotape system by integrating a color quad processor, motion sensors, multiplexer, pan &...

  • Page 12: Specifications

    Real Time Triplex Stand Alone DVR CHAP 1. INTRODUCTION 3. Specifications Category 4CH DVR 8CH DVR 16CH DVR Input Video NTSC/PAL, 1V 75 Ohm, BNC (4, 8 and 16CH), Auto-loop throughout Signal Output CVBS, S-Video, VGA Input / Output 2 X RCA (1CH Input , 1CH Output) Audio Recording Mode Mono PCB 8KB / sec...

  • Page 13: Contents

    Real Time Triplex Stand Alone DVR CHAP 1. INTRODUCTION 4. Contents Please make sure the following parts are included with the main DVR when you open the product package. Parts Quantity 1 unit DC Power Adaptor 1 pc Power Cable 1 pc Remote Controller 1 pc...

  • Page 14: Front Panel

    Real Time Triplex Stand Alone DVR CHAP 1. INTRODUCTION 5. Front Panel 1. 1 to 16 Channel Selection / Direction Button • To select a channel to be viewed as full-size screen during live display or playback. • To navigate, press Up(1) / Down(2) / Left(3) / Right(4). 2 ~ 5.
  • Page 15 Real Time Triplex Stand Alone DVR CHAP 1. INTRODUCTION 10. TRI Button • To convert to triplex function like 8 channel live display and 8 channel playback in the screen simultaneously. • Press the button first, you will have CH1 ~ CH 8 live displays and playbacks and press it again, you will do other channels like CH9 ~ CH16 live displays and playbacks.

  • Page 16: Rear Panel

    Real Time Triplex Stand Alone DVR CHAP 1. INTRODUCTION 6. Rear Panel [ 16CH DVR ] 1. Cooling Fan 2. Power Switch 3. AC Power Switch 4. 16 BNC connectors for camera input 5. 16 BNC connectors for monitor output •...

  • Page 17: Remote Controller

    Real Time Triplex Stand Alone DVR CHAP 1. INTRODUCTION 7. Remote Controller 1. REC (Record) 2. Mute 3. CH1~CH10 (Channel selection) 4. MENU 5. INFO (Information) 6. Multi 7. PIP 8. AUTO 9 .Zoom ( 2 x digital zoom) 10 ◀ Left 11 ▲...

  • Page 18: Chap 2. Installation

    Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 1. HDD Installation Unscrew the sides, rear of the DVR and remove the top cover. Fix HDDs to rack mount by screwing as left. Install the HDDs on the HDD plate and screw as left. HDD Jumper Setting Information Before install the Hard Disk Drives, please read the jumper setting information on the label.

  • Page 19: System Diagram

    Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 2. System Diagram ………. 16 Cameras ………. 16 Sensor Inputs 1 Alarm Out BACKUP DISPLAY Monitor CD-RW PC Monitor NETWORK Camcorder Internet Web Browser WebViewer Client Program NetViewer Note Note You can use general home TV or PC Monitor as CCTV monitor.

  • Page 20: Ptzf Camera & Sensor Connection Diagram

    Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 3. PTZF Camera & Sensor Connection Diagram 3) VGA 1) RS-232 2) Alarm In/Out & RS-485 1) RS-232 (9 Pin D-Sub Connector) Description TX 232C RX 232C 6 ~ 9 * N/C : Connection Not Required...
  • Page 21 Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 2) Alarm In/Out & RS-485 (25 Pin D-Sub Connector) 25 24 Description 1 ~ 16 Sensor Input 17 ~ 20 Alarm Out COM Alarm Out NC Alarm Out NO 485B 485A 3) VGA (15 Pin D-Sub Connector) Description RED (Red Video [75ohm, 0.7Vp-p])

  • Page 22: Network Connection

    Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 4. Network Connection 4.1 Using Static (Public) IP Address You can use one of Static IP addresses, Subnet Mask and Gateway provided by your ISP (Internet Service Provider) for network connection between DVR and Net / Web Viewer. And you can connect DVR to your multi-port Broadband Modem directly.

  • Page 23: Router Configuration

    Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 4.3 Router Configuration If your DVR is connected to network through Router, you should configure Router properly. There are 3 steps as follows. 1. WAN Setting 2. DHCP Setting 3. Virtual Server Setting And 3 Routers from D-Link, Net Gear and Linksys are quoted as examples in this manual.
  • Page 24 Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION...
  • Page 25 Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 4.3.2 DHCP Setting To assign DVR an unique private IP address in your intranet environment, please check the Starting and Ending IP address used by DHCP server. You can assign any private IP address to your DVR, if it is out of the DHCP range.
  • Page 26 Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION...
  • Page 27 Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 4.3.3 Virtual Server Setting You should register your DVR as a virtual server to Router. Please type in the private IP address of DVR to IP address field. (e.g. 192.168.0.110) Protocol Type is TCP, and Private/Public Port numbers should be same with the Port numbers in DVR.
  • Page 28 Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 9310 9311 9310..9311...
  • Page 29 Real Time Triplex Stand Alone DVR CHAP 2. INSTALLATION 9310 9311...

  • Page 30: Chap 3. Setup Menu

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU Getting Started First, it is important to make sure that the DVR power is off before connecting all the necessary video, monitor and power cables to the DVR. [ System initializing ] [ HDD detected properly ] You will see the above screen when you power on the DVR system properly.

  • Page 31: System Setup Menu

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU System Setup Menu Before starting full operation of the DVR system, you have to set the desired system configuration using the Setup Menu. Press MENU button to access the Setup Menu. •...

  • Page 32: Language

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 1. Language • When you first call the main menu using the MENU button, you’ll see that the current language is highlighted (see screen shot above). • To exit main menu, press MENU button.

  • Page 33: System Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 2. System Setup 2.1 HDD Setup This menu enables HDD setup. 1) Overwrite ON/OFF To enable (ON) or disable (OFF) to overwrite HDD. 2) Record OSD ON/OFF To show “REC” in green in the right bottom of screen during recording mode. Note Note - “M-REC“...

  • Page 34: Password Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 2.2 Password Setup This menu allows to set system passwords. It supports both Admin and User level passwords. Admin can access and control all information and User can access limited info without the ability to change the setup configuration.
  • Page 35 Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 3) Input of Passwords To input your 4 letter password among 0~9, press numeric buttons of remote control unit. The cursor moves to right when DVR receives each number. Recording start and Playback functions do not require password even though DVR is Password On condition.

  • Page 36: Channel Name Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 2.3 Channel Name Setup To make camera names easy to remember, you can assign names to individual channels up to 8 characters per channel. For example, if your one external camera is located in a factory, you can name it as “factory”.

  • Page 37: Date/Time Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 2.4 Date/ Time Setup Everybody agrees that surveillance digital video recorders must indicate the exact date and time information in which an event took place in order to be used as evidence. Therefore, configuring the DVR to correct time and date is very important.

  • Page 38: Beep & Ptzf Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 2.5 Beep & PTZ Setup This menu enables recording beep and external Pan/ Tilt & Zoom/ Focus cameras setup to communicate with. 1) PAN/ TILT Pelco-D / Pelco-P / LG / Hitron / Dongyang Select a desired protocol which is used for communication between the external Pan/ Tilt camera and the DVR set.

  • Page 39: System Reset

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 2.6 System Reset ON/OFF To reset the system, press Enter button and select YES. • To return to main menu, press MENU button. You have to make sure of it before system reset. Once system reset, all data that you have selected previously, such as password, are converted to the factory default settings.

  • Page 40: Display Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 3. Display Setup 3.1 Blank Channel Setup To enable to make channels hidden on the screen during live display mode as below. CH 1 ~ CH 16 ON/OFF To hide the channels on the monitor even though it is recorded, you can set ON for each channels. To return to main menu, press MENU button.

  • Page 41: Pip Channel Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 3.2 PIP Channel Setup You can select PIP ( Picture In Picture ) options. PIP mode offers a convenient way of monitoring multiple channels while focusing more attention on a specific channel. It has a main video channel and up to 3 sub video channels on the screen.

  • Page 42: Adjust Channel Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 3.3 Adjust Channel Setup This menu allows video adjustment options for individual cameras. 1) Channel CH1 ~ CH 16 - To select your desired channel to adjust video display. 2) CON (Contrast) - To control light and shade of video display.

  • Page 43: Video Signal Type

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 3.4 Video Signal Type NTSC/PAL To select your local video signal type between NTSC and PAL, press Enter button and select it. It reboots the system automatically after your selection. It reboots the system automatically after your selection.

  • Page 44: Boundary

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 3.6 Boundary White/Black/OFF To select the boundary color that is divided into each channel. 3.7 Background Blue/Black To select the background color of no video channels between two colors. • To return to menu, press MENU button.

  • Page 45: Vga Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 3.8 VGA Setup It supports 3 output resolutions, 800x600, 1024x768 and 1280x1024. Output Contrast, Brightness and Color can be adjusted. • To return to menu, press MENU button.

  • Page 46: Event Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 4. Event Setup This screen enables simple set up of DVR motion detection, alarm and external sensor configurations 4.1 REC Time 30 sec ~ 30 min Once event recording is triggered, the video is recorded for that period. 4.2 Sensor In N.O/N.C The Sensor-in terminals of the DVR are used to connect external motion sensors or door/window...

  • Page 47: Event Action

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 4.3 Event Action To select notice method in order to make users get more attention when event recording occurs. 1) Alarm Out ON/OFF You can set to enable (ON) or disable (OFF) the outbound signal from the DVR. 2) Sensor ON/OFF When DVR detects signals from external sensors, DVR will beep or OSD to get your attention.

  • Page 48: Motion Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 4.4 Motion Setup This menu enables users to set motion functions. 1) Channel CH1~CH16 You must manually set each channel for the motion detection area. Select a channel for this motion detection.

  • Page 49: Record Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 5. Record Setup Here you can set recording options. 5.1 Record Type 720 / 360 There are two recording modes: 720x240 and 360x240. If you set it to 720 mode, DVR records the full size videos of 16 different channels. If you set it to 360 mode, DVR records the half size videos of 16 different channels.

  • Page 50: Record Format

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 5.4 REC Format 4:2:2 / 4:2:0 You can select color recording format. 4:2:2 supports better color, but 4:2:0 supports less HDD space for recording. 5.5 PB Speed AUTO, 1~60 F/S, 120F/S (Only available in 360 mode) You can select various playback speed in field per second (F/S).

  • Page 51: Audio Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 5.7 Audio Setup 1) Channel CH1~CH16 It is to select one audio channel among 16 channels. 2) Icon Display ON/OFF To enable icon of audio function in right top of screen as below. 5.8 Schedule Setup 1) Schedule ON/OFF...

  • Page 52: Network Setup

    Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU 6. Network Setup To monitor and control videos remotely through network, you need to input the correct values. 6.1 IP Address *000.000.000.000 Set IP address of your DVR using arrow buttons. To move to other sub-menu, move cursor to position first, then press up or down button.
  • Page 53 Real Time Triplex Stand Alone DVR CHAP 3. SETUP MENU To check and change Mac. Address, Network Server IP and Port number of Note Note your DVR, press CH6 button in network setup mode. The main reason of hidden menu of Mac. Address, Network Server IP and Port number is to prevent accidental changes by the user.

  • Page 54: Chap 4. Display Mode

    Real Time Triplex Stand Alone DVR CHAP 4. DISPLAY MODE You can enjoy this “live mode” functions in display mode. 1. Live Mode It converts to 16 channel live display on the screen as below by pressing Multi button. You can surf 13 CH / 9 CH / 8 CH / 6 CH / 4 CH / 1 CH display by pressing Multi button repeatedly. [ 9 CH display Mode] [ 13 CH display Mode] [ 8 CH display Mode]...

  • Page 55: Pip Mode

    Real Time Triplex Stand Alone DVR CHAP 4. DISPLAY MODE [ 1 CH display Mode] [ 4 CH display Mode] 2. PIP Mode You can select PIP ( Picture In Picture ) options by pressing PIP button repeatedly. PIP mode offers a convenient way of monitoring multiple channels while focusing more attention on a particular channel.

  • Page 56: Ptzf Camera Control

    Real Time Triplex Stand Alone DVR CHAP 4. DISPLAY MODE 4. Pan/ Tilt/ Zoom/Focus Camera Control Controlling an external Pan/ Tilt/ Zoom/Focus camera Indicates Pan/Tilt function. 4.1 Pan/ Tilt Function 1) 16 channel display mode 1. First press P/ T button in the remote controller. 2.
  • Page 57 Real Time Triplex Stand Alone DVR CHAP 4. DISPLAY MODE 4.2 Zoom/ Focus Function 1) 16 channel display mode Indicates Zoom Focus function. 1. First press Z/ F button in the remote controller. 2. Select your desired channel by pressing Z/F button repeatedly. 3.

  • Page 58: Digital Zoom

    Real Time Triplex Stand Alone DVR CHAP 4. DISPLAY MODE 5. Digital Zoom You can magnify a certain part of the full size screen two times digitally when you use this function as described below. This function can be applied to all display and search modes. You can operate this function with only remote controller.

  • Page 59: Chap 5. Recording Mode

    Real Time Triplex Stand Alone DVR CHAP 5. RECORDING MODE 1. If you press REC button, you will see REC in green on the right bottom of the screen. It means the DVR is in the recording process. - M-REC : It records videos in Master HDD. - S-REC : It records videos in Slave HDD.

  • Page 60: Chap 6. Playback - Search Mode

    Real Time Triplex Stand Alone DVR CHAP 6. PLAYBACK - SEARCH MODE [ Search Menu ] With Triplex function, you can enter search mode while the DVR is in live or recording mode. S o yo u d o n ’ t need t o s t op record i ng t o i n it iat e Playback mode.

  • Page 61: Chap 7. Playback - Triplex Function

    Real Time Triplex Stand Alone DVR CHAP 7. PLAYBACK - TRIPLEX FUNCTION You can now experience triplex function (simultaneous recording, playback and network transmission) with our new line of Digital Video Recorders. - Press TRI button in live or recording mode, then you will see 1~8 live channels and 1~8 PB channels.

  • Page 62: Chap 8. Playback - Trickplay & Multi Ch. Display

    Real Time Triplex Stand Alone DVR CHAP 8. PLAYBACK – TRICKPLAY & MULTI CH. DISPLAY You can get FF, REW and Pause during Playback mode. It supports 5 steps of FF and 4 steps of REW. To change the FF/REW speeds, press FF/REW buttons repeatedly. In Playback mode, there are two display mode.

  • Page 63: Chap 9. Cd Burner Backup Mode

    Real Time Triplex Stand Alone DVR CHAP 9. CD BURNER BACKUP MODE You can copy video stored in DVR into CD in Playback mode. During CD backup, all other operation are prohibited. You can retrieve video from CD using our Net Viewer easily. You can burn whole 700MB or stop burning in the middle of burning process.
  • Page 64 Real Time Triplex Stand Alone DVR CHAP 9. CD-BURNER BACKUP MODE 4. Press Left button and of the remote controller, then DVR checks the CD burner and blank CD available. 5. If DVR is ready to burn CD, you will see the READY condition. - Ready : shows that it is ready for CD backup.
  • Page 65 Real Time Triplex Stand Alone DVR CHAP 9. CD-BURNER BACKUP MODE 8. Take out the CD. If you want to see the video stored in CD, put it into PC which Net Viewer is installed in. 9. To return to live display mode, press MENU button.

  • Page 66: Chap 10. Network Viewer

    Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER 1. System Requirement - Pentium III or above recommended - O/S : Microsoft Windows - 256MB RAM or above recommended - Super VGA 16M or above recommended - 10/100 Base T network card for LAN operation 2.

  • Page 67: Functions And Network Setup

    Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER 4. Functions and Network Setup Names Description Get video after connection to DVR or change operation mode Play (Get Video) Reverse frame Advance Reverse Step Play Forward Step Play Forward frame advance Go to Start Move to the start point of video Go to End...
  • Page 68 Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER Show that the DVR is controlled by Network viewer Show that video is stored in by AVI file format Local Show that video is stored in MJPEG format Connect Show that Network viewer is connected Disconnect Show that Network viewer is not connected Read...
  • Page 69 Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER Note Note NETWOK ID Registration When you press Log In button, you will see Connect Manager. If you are installing DVR and Network Viewer now, please press Setting. Press Create NETWORK ID and type in your desired Network ID and E-MAIL address.
  • Page 70 Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER Note Note 3. Dynamic IP Connection Our DDVRLS (Dynamic DVR Locator Service) enables you connecting to DVR only with your registered Network ID and password 4. Direct (Static) IP Connection Also you can use Direct IP connection with type in DVR IP address and Password.

  • Page 71: Operation

    Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER 5. Operation This network viewer program has 5 types of operation modes. [ Live View / Playback / Drive Scan / File Play / CD Play ] Each operation mode is designed for its own purpose. Please refer to the details for your use.

  • Page 72: Playback Mode

    Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER 5.2 Playback Mode This mode enables you to access the recording list in the remote DVR. When this function is on, “DVR” LED below is activated. Names Description HDD Selection Select HDD between master and slave Event List Access event list in the remote DVR...

  • Page 73: Drive Scan Mode

    Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER 5.3 Drive Scan Mode You can take out HDD from DVR and plug it into your PC. And you can see the video from that HDD using this function. Names Description Playback Speed Select playback speed...

  • Page 74: File Playback Mode

    Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER 5.4 File Playback Mode This mode enables you to access all recording lists that is stored in the HDD of your PC. Names Description Click and drag to go to any point of the file Track Bar File open and time Click Open button to select file then Start/stop time will be displayed...

  • Page 75: Cd Playback Mode

    Real Time Triplex Stand Alone DVR CHAP 10. NETWORK VIEWER 5.5 CD Playback Mode This mode enables you to play video back up CD. Names Description Click and drag to go to any point of the file Track Bar Start / Stop Start/Stop of file copy from CD to local hard drive (c:\) •...

  • Page 76: Chap 11. Web Viewer

    Real Time Triplex Stand Alone DVR CHAP 11. WEB VIEWER - CONNECT DVR VIA WEB BROWSER 1. System Requirement - Pentium III or above recommended - O/S : Microsoft Windows - 256MB RAM or above recommended - Super VGA 16M or above recommended - 10/100 Base T network card for LAN operation 2.

  • Page 77: Web Browser Setup To Enable Web Viewer

    Real Time Triplex Stand Alone DVR CHAP 11. WEB VIEWER - CONNECT DVR VIA WEB BROWSER 4. Web Browser setup to enable Web Viewer Note Note If you experience that your web browser protect Web Viewer, 1. Enable all option regarding ActiveX controls. 2.

  • Page 78: Functions And Network Setup

    Real Time Triplex Stand Alone DVR CHAP 11. WEB VIEWER - CONNECT DVR VIA WEB BROWSER 5. Functions and Network Setup Names Description Log In Connect to DVR Record Start DVR record start Record Stop DVR record stop Record into PC Record coming video from DVR, Record Start/Stop toggle Image Capture Still image capture in JPEG format...

  • Page 79: Log In

    Real Time Triplex Stand Alone DVR CHAP 11. WEB VIEWER - CONNECT DVR VIA WEB BROWSER 6. Log In To connect to DVR, 1. Press Log In button and type in your Network ID and password. Please remember that Network ID and Password should be authenticated during installation of DVR and Network Viewer.

  • Page 80: Playback

    Real Time Triplex Stand Alone DVR CHAP 11. WEB VIEWER - CONNECT DVR VIA WEB BROWSER 7. Playback To retrieve video from DVR or local PC, 1. Press Playback button, then you will see sub window. 2. You can retrieve video from DVR in 3 different ways. - Select master or slave HDD of DVR.

  • Page 81: Chap 12. System Information

    Real Time Triplex Stand Alone DVR CHAP 12. SYSTEM INFORMATION It shows all information about the DVR system like HDD, CD-burner and software version. You can access system information easily just by pressing INFO (Information) button. 1) MASTER - Model : It shows the model no. of Master HDD. - Size : It shows the size of Master HDD.

  • Page 82: Chap 13. Q & A

    Real Time Triplex Stand Alone DVR CHAP 13. Q & A The system power does not turn on. ☞ Check if the power cable is connected correctly. ☞ Check if the input voltage is correct. ☞ If the system power does not turn on when the power cable is connected correctly, please contact the local distributor or manufacturer.
  • Page 83 Real Time Triplex Stand Alone DVR CHAP 12. Q & A Audio data recorded with video data is not playing. ☞ Check if the audio recording option is correctly set to the camera you wish to record audio. ☞ Check if the audio mute is enabled. ☞...
