LEGACY
• Important operating
and maintenance
instructions included.
WARNING: If the information in
these instructions is not followed
exactly, a fire or explosion may result
causing property damage, personal in-
jury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
FOR YOUR SAFETY
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, immediately call your
gas supplier or your fire department.
CONVECTION RANGE
OPERATING
AND ASSEMBLY
INSTRUCTIONS
Models: LG24i
CAUTION
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Fire Stone Home Products • Legacy Gas Grill • Rev. C

LG36i (shown)
• Leave this manual with
party responsible for
use and operation.
Read the following instructions careful-
ly and be sure your grill is properly in-
stalled, assembled and maintained.
Failure to follow these instructions may
result in serious bodily injury and/or
property damage. If you have questions
concerning assembly or operation, con-
sult your dealer, gas appliance service
person or your LP gas company.
This outdoor cooking gas appliance is
not intended to be installed in or on recre-
ational vehicles and/or boats.
Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier. In the Commonwealth of
Massachusetts installation must be per-
formed by a licensed plumber or gas fitter.
GAS-FIRED
LISTED
760-920C
6/07

Advertisement

loading

Summary of Contents for Fire Stone Legacy LG24i

  • Page 1 In the Commonwealth of • If odor continues, immediately call your Massachusetts installation must be per- gas supplier or your fire department. formed by a licensed plumber or gas fitter. Fire Stone Home Products • Legacy Gas Grill • Rev. C 760-920C 6/07...
  • Page 2: Table Of Contents

    SERVICE PARTS LIST ..............6 CONNECTING GAS CYLINDER ..........0 LIGHTING AND OPERATING INSTRUCTIONS ...... COOKING INSTRUCTIONS ............3 CLEANING AND MAINTENANCE INSTRUCTIONS ....4 CONTACT INFORMATION ............6 Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 3: Warranty

    Legacy-24i/36i Gas Grills Limited Lifetime Warranty Fire Stone extends the following warranty for Legacy-24i/36i Gas Grills used in the United States of America or Canada. Dealers and employees of Fire Stone have no authority to make any warranty or authorize any remedies in addition to or inconsistent with the terms of this warranty.
  • Page 4 LPG cylinder, regulator the grill being used again. and/or grill. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 5: Safety Instructions

    /2 psi (3.5kpa). Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 6 Ending Manufacturing Date: ______ Remove all components from the packing carton and place within easy reach. Do not throw the shipping carton away; in- stead use it as an elevated assembly surface. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 7 Battery Pack 593-594A 24 in. Valve 760-9 24 in. Wire Harness JL-24-760-93 Probe 760-44 Searing Plate 760-108 SS Grill 760-09 Hose and Regulator 760-182 Ignitor JL-76-303 Ignition Wire JL-76-304 Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 8: Service Parts List

    Ending Manufacturing Date: ______ Remove all components from the packing carton and place within easy reach. Do not throw the shipping carton away; in- stead use it as an elevated assembly surface. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 9 Battery Pack 593-594A 36 in. Valve 76-9 36 in. Wire Harness JL-760-93 Probe 760-44 Searing Plate 760-108 SS Grill 760-09 Hose and Regulator 760-182 Ignitor JL-76-303 Ignition Wire JL-76-304 Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 10: Connecting Gas Cylinder

    If a leak is found, turn the cylinder valve off and do not use the grill until repairs are made. Figure 1 Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 11 18 inches) from the lighting hole or property damage, serious bodily injury or death. burners, when lighting the grill by match. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 12 1/8 inch. Adjust if necessary. With the gas supply closed press and turn control knob counterclockwise and check for presence of spark. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 13: Cooking Instructions

    Insert probe into meat and close lid. Each light will turn red once that temperature is reached, and an alarm will sound once the desired tem- perature is achieved. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 14: Cleaning And Maintenance Instructions

    After installation, check to insure that the gas valve orifices are correctly placed inside the ends of the burner tubes. Also check the position of the spark electrode. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 15 Never use abrasive cleaners or scrubbers—they will scratch and damage the stainless steel. 3. Wipe with a soft cloth and allow to air dry before start- ing the grill. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
  • Page 16: Contact Information

    This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322; 4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia) 543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending. Fire Stone Home Products • Legacy Gas Grill • Rev. C...
