Aiwa CDC-X707M Service Manual

Stereo car cd receiver
Hide thumbs Also See for CDC-X707M:

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
STEREO CAR CD RECEIVER
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
CDC-X707M/X7070M (YU, YL), (S/M Code No. 09-002-424-3T1).
CDC-X707M
CDC-X7070M
BASIC CD MECHANISM : CDC02AW1
S/M Code No. 09-003-424-3R1
YU
YL

Advertisement

loading

Related Manuals for Aiwa CDC-X707M

Summary of Contents for Aiwa CDC-X707M

  • Page 1 CDC-X707M CDC-X7070M SERVICE MANUAL STEREO CAR CD RECEIVER BASIC CD MECHANISM : CDC02AW1 • This Service Manual is the "Revision Publishing" and replaces "Simple Manual" CDC-X707M/X7070M (YU, YL), (S/M Code No. 09-002-424-3T1). S/M Code No. 09-003-424-3R1...

  • Page 2: Specifications

    SPECIFICATIONS RADIO SECTION AUDIO SECTION (FM) Max. Power Output 45 W x 4 channels Frequency Range 87.5 MHz –108 MHz (100 kHz steps)* 87.5 MHz –108 MHz (50 kHz steps)* TAPE IN input Usable Sensitivity 12.7 dBf Input Sensitivity (load impedance) 50 dB Quieting Sensitivity 17.2 dBf AUX IN 300 mV (10 kΩ)

  • Page 3: Protection Of Eyes From Laser Beam During Servicing

    PROTECTION OF EYES FROM LASER BEAM DURING SERVICING CAUTION This set employs laser. Therefore, be sure to follow carefully the instructions below when servicing. Use of controls or adjustments or performance of proce- dures other than those specified herin may result in WARNING!! hazardous radiation exposure.

  • Page 4: Caution When Servicing

    CAUTION WHEN SERVICING 1. Disassembly Instruction 1) Remove the COVER TOP / COVER BOTTOM. 2) Remove DFP. 3) Remove the four screws (indicated by arrows) from CD mechanism. Screw (a) × 2: VTT 2.6-6 Screw (b) × 2: VTT 2.6-3B (Fig.

  • Page 5: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C122 87-010-220-080 C-CAP,S 0.018-25 B<YL> C122 87-012-365-080 C-CAP,S 0.027-25VBK<YU> 8Z-KT1-622-010 C-IC,LC75374E C123 87-010-178-080 CHIP CAP 1000P-50 87-A21-562-010 IC,LA4743B C125 87-010-197-080 CAP, CHIP 0.01-25 88-KT1-608-010 C-IC,LC75854W C126 87-010-197-080...
  • Page 6 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C461 87-010-450-080 CAPACITOR 0.47-16 C702 87-010-196-080 CHIP CAPACITOR,0.1-25 C462 87-012-358-080 C-CAP,S 0.47-10 F Z C703 87-010-805-080 CAP, S 1-16 C463 87-012-358-080 C-CAP,S 0.47-10 F Z C704 87-010-805-080 CAP, S 1-16 C464 87-010-196-080 CHIP CAPACITOR,0.1-25...
  • Page 7 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C837 87-010-186-080 CHIP CAPACITOR 4700P(K) C887 87-016-669-080 C-CAP,S 0.1-25 K B C838 87-010-194-080 CAP, CHIP 0.047 C888 87-016-669-080 C-CAP,S 0.1-25 K B C839 87-010-880-080 C-CAP,E 47-6.3 MF C889 87-A10-473-080 C-CAP,E 47-10 MF10FC(M) C840...

  • Page 8: Transistor Illustration

    CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Wattage Type Tolerance Symbol Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W 3216 0.55 TRANSISTOR ILLUSTRATION 2SD1758 2SA1037 2SB1197KQ...
  • Page 9 WIRING – 1 (MAIN) – 9 –...
  • Page 10 SCHEMATIC DIAGRAM – 1 (MAIN / EJECT) – 10 –...
  • Page 11 WIRING – 2 (FRONT / CONN / AUX / EJECT) – 11 –...
  • Page 12 SCHEMATIC DIAGRAM – 2 (FRONT / CONN / AUX) – 12 –...

This manual is also suitable for:

Cdc-x7070m
