  • Page 1 Wine Guardian reserves the right, without notice, to make changes to this document at its sole discretion. Please visit out web site for the most current version of the Wine Guardian manual and other literature. Wine Guardian is a registered trademark (2,972,262) of Air Innovations, Inc.

  • Page 2: Table Of Contents

    Safety ......................9 Pre-Installation Check ....................9 Free Standing Installation with Stand-Alone Model ........10 Stand-Alone Installation ................10 Wine Guardian-Mounted (Integrated Installation) ........12 Mounting the Humidistat ................12 Start-Up and Operation ................13 Inspection and Start-Up Checklist................14 Maintenance .....................

  • Page 3: Introduction

    Your Wine Guardian Humidifier has a humidistat that gets wired to the terminal strip on the Wine Guardian unit and a drain line that requires piping to an open floor drain or condensate pump. Inspect all equipment for any sign of damage or loose parts caused during transit.

  • Page 4: General Description

    When the unit turns on, the water solenoid valve opens and the fan turns on. When mounted and connected to a Wine Guardian cooling unit, the humidistat also controls the main fan to circulate air to and from the cellar.

  • Page 5: Size And Capacity

    GUIDE FOR FUTURE REFERENCE. Size and Capacity The Wine Guardian Humidifier uses a 10” wide x 11” high x 2” thick expanded coated aluminum pad. Its rated output capacity for wine cellars is 60°F and 50%RH is 1.6 gallons per day (gpd) with 60°F water supply, 3.3 gpd with 90°F water, and 5.1 gpd with 120°F water.

  • Page 6: Dimensional Drawing (All Dimensions In Inches)

    Strainer – conical shaped stainless steel screen in a plastic frame to capture any sediment in the water and keep it from plugging the orifice. Water solenoid valve – opens and closes to control the flow of water into the distribution trough on signal from the humidistat.

  • Page 7: Component Parts Cutaway Drawing

    Component Parts Cutaway Drawing Figure 2.0...

  • Page 8: Wiring Diagram

    Wiring Diagram Figure 3.0...

  • Page 9: Safety

    Safety The Wine Guardian Humidifier uses only 24-volt power. However, that power comes from a transformer, which uses 120-volt power. Therefore, before servicing the humidifier, be sure to disconnect the main power to the cooling unit or to the humidifier.

  • Page 10: Free Standing Installation With Stand-Alone Model

    Free Standing Installation with Stand-Alone Model Figure 4.0 Stand-Alone Installation 1) Mount the face grille onto the humidifier box so that the separation plate slides in on top of the fan and between the insulation on the sides. The two metal tabs (top and bottom) should slide in between the insulation and the metal wall.
  • Page 11 NOTE: In all mounting arrangements make sure the humidifier is level and plumb in all directions. 3) Install a ¼”water line from the water supply into the opening on the top of the humidifier. Use flexible tubing to allow the unit to be rotated. A shut-off valve (not provided) is recommended to isolate the humidifier from the water system when needed.

  • Page 12: Wine Guardian-Mounted (Integrated Installation)

    The unit also comes with 5 feet of 3-wire, 24-volt power cable that connects to the terminal on the side strip of the Wine Guardian Unit. (See Step 3 next page.) If you need to remove the wires, please note the color-coding and replace the wires in the correct location.

  • Page 13: Start-Up And Operation

    THE HUMIDISTAT. WE RECOMMEND YOU FOLLOW WINE GUARDIAN’S HUMIDISTAT INSTRUCTIONS AND SIMPLY RETAIN THE HUMIDIFSTAT MANUFACTURER’S INSTRUCTIONS IN A FOLDER ALONG WITH THE WINE GUARDIAN OPERATION AND MAINTENANCE MANUAL FOR FUTURE REFERENCE. 1) Disregard the wiring diagrams shown within the manufacturer’s instructions. Refer to the wiring diagram shown in this guide on page 8.

  • Page 14: Inspection And Start-Up Checklist

    NOTE: The humidifier can only add moisture, not remove it. Removal, or dehumidification, is a function of the cooling system as it lowers the temperature of the air below its dew point at which moisture condenses out onto the cooling coil and into the condensate drain.

  • Page 15: Maintenance

    BEFORE PERFORMING MAINTENANCE ON THE UNIT, READ AND UNDERSTAND THE SAFETY INFORMATION CONTAINED IN THIS GUIDE. The Wine Guardian Humidifier is designed for minimal maintenance. Never oil any part of the humidifier. Always disconnect the electrical power to the humidifier and the cooling unit if used.

  • Page 16: Humidifier Water Line Maintenance

    CAUTION BEFORE STARTING WORK, BE SURE THE POWER TO THE WINE GUARDIAN COOLING UNIT AND HUMIDIFIER ARE TURNED OFF. MAKE SURE THE POWER CORD IS DISCONNECTED FROM THE POWER SOURCE. 1) Start by disconnecting the electrical power and shutting off the water supply.
  • Page 17 5) Reinstall the strainer in the valve inlet and replace the tubing and tighten the compression nut. Double wrench to prevent damage and leaks. 6) Disconnect the water line on the outlet of the solenoid valve. 7) Remove the orifice from the copper tube and make sure this small opening is unplugged. 8) Replace the orifice and reconnect the outlet water line.

  • Page 18: Directory Of Terms

    Heat Gain/Loss – the amount of cooling or heating expressed in BTU/H that is gained or lost into or out of the wine cellar to the ambient space. It is this load that the Wine Guardian must be able to offset.

  • Page 19: Wine Guardian Warranty

    LIABILITY Wine Guardian liability shall be limited to the repair or replacement (at its option) of any part, which, at our sole discretion, is determined to be defective. The purchaser shall pay all transportation costs. Additionally, if a malfunction occurs within the first year from the date of invoice, Wine Guardian will reimburse the reasonable cost of labor required for the repair or replacement provided authorization is obtained from one of our authorized representatives prior to incurring any labor charges.
