Remaco MIC-800 Installation Manual

C COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD

Important Notes:

Warning
All products are thoroughly inspected and fully tested operational in factory. We accept no liability whatsoever for any losses due to improper operation, or any unauthorized alternation.
All trademarks contained in this installation guide are the property of their respective owners.

Concept

The MIC-800, Media Interface Controller, is an electronic controller that can be used to link a variety of
audio-visual equipments in classrooms, training rooms & conference rooms. By using the MIC-800, the
selection of equipment will be just within a touch of a button.
Fig. 1
Speakers
Projector
Microphone

Application

The MIC-800 has 3 D-Sub 15pin input ports for connection to 3 different sources, as well as a video and
microphone input port. All these ports will provide the monitor, speaker and projector output ports with the
desired audio and visual signals that is essential for any classroom or office setups.
Item Application
For connection to a 230V power source
Power
Fig. 2

Installation Guide

Front Panal
PROJ MIC PC
VIDEO
ON/OFF ON/OFF
1 2
PC 3
AUDIO IN
6.35 mm
MIC IN
VIDEO
AUDIO
IN
L IN R
Player
Inner Board
( MIC-800 )
MUTE
VOL VOL
BLANK WIRE
UP DOWN
LESS
3 4 5 6 7
PC 2
PC 3 IN AUDIO IN PC 2 IN
PC 1
MONITOR OUT PC 1 IN
AUDIO IN
Monitor
V+ GN
WEBSITE: WWW.REMACOTECH.COM
S: MIC
V: 3.0
Computer 1
Computer 2
Computer 3
230V AC-DC
Adapter
