Remaco MPC-851 Installation Manual

C COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD
Installation Guide
Important Notes:
All products are thoroughly inspected and fully tested operational in factory. Warning
We accept no liability whatsoever for any losses due to improper operation, or any unauthorized alternation.
All trademarks contained in this installation guide are the property of their respective owners.
Application
Motor / Power Control, MPC, is an electronic controller that can be used to control a motorized screen, projector lift,
curtains or any other electrical motor powered equipments capable of bi-directional movements. The MPC can also
be configured as a power trigger device to switch on/off the power supply of any A/V equipments, (e.g. Projectors,
Amplifiers, DVD Players) Lights or Down lights, etc.
It can also be used with LCD/DLP Projectors, as an interface to trigger screen Up/Down movements through a 12V DC
output from a projector.
