Remaco MPC-851 Installation Manual & Manual

C COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD
Installation Guide / Manual ( MPC-851 Bundle )
Important Notes:
All products are thoroughly inspected and fully tested operational in factory. Warning
We accept no liability whatsoever for any losses due to improper operation, or any unauthorized alternation.
All trademarks contained in this installation guide are the property of their respective owners.

Application

Motor / Power Control, MPC, is an electronic controller that can be used to control a motorized screen,
projector lift, curtains or any other electrical motor powered equipments capable of bi-directional movements.
The MPC can also be configured as a power trigger device to switch on/off the power supply of any A/V
equipments, (e.g. Projectors, Amplifiers, DVD Players) Lights or Down lights, etc.
It can also be used with LCD/DLP Projectors, as an interface to trigger screen Up/Down movements through
a 12V DC output from a projector.
VCC
GND IR
(VDD) 2D
IR
12V-TRIG
-12V
CH2
+12V
-12V
CH1
+12V
+12V
Projector
A/V Control System
(e.g. AMX / Creston)
AVA-200
AVA-200
Wall Switch
C o n t a c t C l o s u r e
D r y C o n t a c t
CH2 CH1
2S 2U COM 1D 1S
GND
GND
N
L
POW-IN
AC Input
Learning
Button
CH1(DRY)
1U COM
LED
MOT2
L N
N DN2
Power Supply Motor 2
Projector Lift
Website: www.remacotech.com
AVA-316
15-Channel
RF Remote
B (Rx)
RS-485
(RS-232)
A (Gnd)
N
UP2 DN1 UP1
Motor 1
Projector Screen
V: 6.0
MPC
485-IN
MOT1
Computer
